Technical specifications for 1785-ENET
-
Product Model1785-ENET
-
Spare Model1785ENET
-
Product ParametersEthernet Interface Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size3.3x14.8x27.4cm
-
ManufacturerAllen-Bradley
-
Weight0.96 kg
-
Backplane Current1.0 A @ 5V dc
-
Power Dissipation5 W
-
Heat Dissipation17.06 BTU/hr
-
IEC Temp CodeT5
-
North American TempCode T5
-
Isolation Voltage50V
-
Wiring Category2 - on communications ports
-
CommunicationEthernet TCP/IP protocol 8-pin RJ45 port
Description
1785ENET
DISCONTINUED BY MANUFACTURER
COMMUNICATION EXPANSION MODULE
ETHERNET/IP
PLC 5
2.2 AMP
5 VDC
Country of Origin: United States
DISCONTINUED BY MANUFACTURER
COMMUNICATION EXPANSION MODULE
ETHERNET/IP
PLC 5
2.2 AMP
5 VDC
Country of Origin: United States
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Hardware Installation Steps
Features:
- PLC-5 EtherNet/IP Interface Module
- Communication Module
- Direct Connection to Channel 3 of PLC-5 Processor
This Ethernet interface module has One (1) RJ45 Port supporting Ethernet TCP I/P protocol. It supports data transmission speed of 10/100 Mbps with auto-negotiation capability. It has built-in status indicators such as STAT, 100M and 10M. The STAT indicator display the module’s Ethernet link activity. 100M depicts connection to a 100 Mbps network while 10M pertain to link activity in 10Mbps network.
The 1785-ENET Allen-Bradley Ethernet Interface module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1785-ENET Ethernet Interface module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Ethernet communication interface directly attaches to the 1785 backplane via a 1771 PLC5 chassis. It is compatible for use with Enhanced PLC5 controllers, PLC5 controller with ControlNet communication port, and PLC5 controller with Ethernet communication port as well. Installing this Ethernet interface module together with a PLC5 Ethernet controller enables dual link capability. The 1785-ENET is available in multiple series and revisions. Series A with Revision K module is compatible with PLC-5/11, PLC-5/20, PLC-5/26; Series A revision L is compatible with PLC-5/30. Series B revision L is compatible with PLC-5/40, PLC-5/40L, PLC-5/46, PLC-5/60, PLC-5/60L. Series C revision K is compatible with PLC-5/11, PLC-5/20, PLC-5/26, PLC-5/30, PLC-5/40, PLC-5/40L, PLC-5/46, PLC-5/60, PLC-5/60L, PLC-5/80, PLC-5/86 PLC-5/20E, PLC-5/40E, PLC-5/80E PLC-5/20C, PLC-5/40C, PLC-5/80C. Series D revision B is compatible with PLC-5/11, PLC-5/20, PLC-5/26, PLC-5/30, PLC-5/40, PLC-5/40L, PLC-5/46, PLC-5/60, PLC-5/60L, PLC-5/80, PLC-5/86 PLC-5/20E, PLC-5/40E, PLC-5/80E PLC-5/20C, PLC-5/40C, PLC-5/80C. Finally, Series E and later, regardless of the revision, is compatible with All Enhanced, Ethernet, and ControlNet PLC-5 controllers.
- Automotive Production Equipment:Powertrain/paint: high-speed multi-controller coordination
- Paper Mill Machinery:Wet/dry end hydraulic control; integrates with 1771 modules
- Material Handling Systems:Airport/distribution: routing/tracking for baggage/cargo/parcels
- Semiconductor Fabrication Tools:Integrates motion, vision & barcode for critical fab processes
- Food & Beverage Processing:Brewhouse: yeast/fermentation monitoring for large-scale breweries
- Metals Production:Real-time control for metal forming/casting to meet diverse demands
- Water Treatment Infrastructure:SCADA comms link for municipal water/wastewater facilities
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Power Down: Turn off all power to the 1771 I/O chassis and the PLC-5 controller to prevent memory loss or processor faults.Attach Connector Header: Remove the processor from the chassis. Snap the 62-pin connector header (often called a "comb") into the connector on the right side of the 1785-ENET module.Mate Module to Processor: Align the connector header with the mating connector on the left side of the PLC-5 processor. Firmly press them together and secure the assembly using the provided mounting screws.
FAQs
-
What is the 1785-ENET?
+The Allen-Bradley 1785-ENET is a sidecar module designed to provide Ethernet communication capabilities to "Enhanced" PLC-5 processors (Series B or later, or specific late-model Classic processors). -
What is the 1785-ENET Connection Type?
+The 1785-ENET is a single-slot sidecar module that physically mounts directly to the left side of a PLC-5 processor, connecting via a 62-pin header. It features an RJ45 connector for 10/100 Mbps Ethernet communications -
What indicates a faulty 1785-ENET setup?
+The module status LED (STAT) will flash an error code 37 if the attached PLC-5 processor is not compatible. -
Can I use two cards in one PLC?
+No, Rockwell Automation typically supports only one 1785-ENET card per processor. For dual-subnet needs, consider a processor with built-in Ethernet like the PLC-5/40E
