PRODUCT DESCRIPTION
Twelve-inch PanelView Plus 6 visualization for existing control systems
Allen-Bradley 2711P-T12C4A8 is a PanelView Plus 6 1250 terminal with a 12.1-inch color TFT display and analog resistive touchscreen. Its standard Ethernet and RS-232 interfaces connect the configured operator application to compatible industrial control equipment.
This AC-powered catalog uses Windows CE 6.0 without the optional Extended Features package. When maintaining an existing installation, preserve the HMI project, logic-module configuration and communications, and verify the panel cutout, supply and software requirements before selecting replacement hardware.
This AC-powered catalog uses Windows CE 6.0 without the optional Extended Features package. When maintaining an existing installation, preserve the HMI project, logic-module configuration and communications, and verify the panel cutout, supply and software requirements before selecting replacement hardware.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Touchscreen visualization for machine and process equipment
Rockwell Automation describes PanelView Plus 6 as a graphical monitoring and operator-control platform. The following roles depend on the configured HMI project and connected controller; no specific factory installation is asserted.
-
01 · Equipment operation
Touch-based machine interface
The twelve-inch screen presents configured equipment states and operator controls. The application must define the correct command paths, user access and controller tags; replacing the display alone does not recreate that application. -
02 · Process supervision
Graphical process status pages
A supported controller connection supplies the values displayed on process graphics. Engineers must preserve display scaling, tag references and navigation so that operators interpret the process information correctly after maintenance. -
03 · Maintenance workstations
Equipment troubleshooting screens
The terminal can present diagnostic information provided by the controller and HMI project. Its Ethernet or serial connection and the relevant application settings must be restored before those screens can be relied on.
Technical specifications for 2711P-T12C4A8
-
Product Model2711P-T12C4A8
-
Product ParametersAC resistive touchscreen operator terminal
-
In stock1 unit
-
ManufacturerAllen-Bradley
-
Display size12.1 inches diagonal
-
Display resolution800 by 600 pixels; 18-bit color graphics
-
Active viewing area246 by 184 mm
-
Touch inputEight-wire analog resistive touchscreen
-
Touchscreen enduranceOne million actuations
-
Typical display luminance300 cd/m2
-
Power input100 to 240 V AC; 50 to 60 Hz
-
AC power demand160 VA maximum; 65 VA typical
-
Memory512 MB RAM and 512 MB nonvolatile; approximately 79 MB free user memory
-
Standard network interfaces10/100 Ethernet and RS-232
-
USB host connectionsTwo ports for supported peripherals and flash storage
-
Operating systemWindows CE 6.0 without Extended Features
-
HMI platformFactoryTalk View Machine Edition; verify runtime compatibility
-
Panel cutout257 mm high by 338 mm wide
-
Operating environment0 to 55 degrees C; 5 to 95 percent noncondensing humidity
View all additional
Alternative Names
Allen-Bradley 2711P-T12C4A8 terminal
PanelView Plus 6 1250 2711P-T12C4A8
2711P-T12C4A8 AC touch HMI
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
PANELVIEW PLUS 6 1250
Preserve the touch application and AC-powered assembly
Match the 1250 touch display, logic module and optional communication module against the installed labels. The final 8 is the non-extended software configuration and must not be silently changed in the product description.
Verify the 257 by 338 mm panel opening and the documented AC supply. Preserve the mounting, grounding and enclosure requirements when replacing either a module or the complete terminal.
Restore the approved FactoryTalk View ME application and controller connections. Verify touchscreen operation, process graphics, communication status and permitted operator actions before returning the equipment to service.
Features:
- Touch display and modular hardware
- AC supply and cutout verification
- Non-extended software compatibility
The Allen-Bradley 2711P-T12C4A8 requires configuration checks before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
The official record states that 2711P-T12C4A8 was discontinued on December 30, 2021. The listed 2711P-T12W22A9P replacement belongs to the Engineering Replacement category, so identical fit and functionality are not assumed.
The T12W22A9P record also shows discontinuation on November 30, 2021 and identifies T12W22D9P as its engineering replacement. Treat this as a migration chain requiring current catalog and application review.
A widescreen DC terminal can require a different power arrangement, mechanical adaptation and communication changes. Retain the source project and validate the complete operator interface after conversion.
Features:
- Discontinued December 30, 2021
- Engineering migration to widescreen hardware
- Power and application changes require review
The Allen-Bradley 2711P-T12C4A8 requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: Amikon is an independent supplier. Consult the applicable Rockwell Automation documentation and installed configuration before selection, installation or replacement.Features:
- Exact-model reference documents
- Hardware and system compatibility checks
- Accessories are supplied only when listed in the quotation
Documentation for the Allen-Bradley 2711P-T12C4A8 supports document applicability checks before installation or replacement.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed sizePacked dimensions unconfirmed
-
Shipping weightGross weight unconfirmed
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS referenceClassification unconfirmed
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 2711P-T12C4A8
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Does T12C4A8 include a physical function-key keypad?
No. The T identifies the touch-only terminal. A keypad or combined keypad-and-touch configuration is a different assembly and may have a different panel opening. -
Is its twelve-inch screen widescreen?
This Plus 6 1250 model uses an 800 by 600 display. Do not assume the same aspect ratio or mechanical fit as the later T12W widescreen successor family. -
Can an Extended Features application be assumed to work on this terminal?
No. The final 8 identifies Windows CE 6.0 without Extended Features. Check whether the application relies on extended desktop or file-viewing capabilities before substitution. -
What must be checked when converting this AC terminal to a DC successor?
Verify the required external DC supply, protective grounding, wiring and power budget, as well as panel fit, communications and HMI runtime compatibility. An AC source must not be connected directly to a DC-input terminal. -
Why should the display and logic-module labels both be recorded?
The Plus 6 platform uses modular display and logic components, with optional communication modules. Record the actual combination to choose compatible service parts and preserve the installed application. -
Can I transfer the old serial connection to a newer PanelView unchanged?
A newer model may have a different interface arrangement. Review the driver, cable and controller communication requirements and use the manufacturer migration guidance before modifying the system. -
Which replacement path does the official catalog identify?
The discontinued T12C4A8 points to T12W22A9P as an engineering replacement. That AC successor is also discontinued and points to T12W22D9P; the full migration therefore needs power, mechanical and application review.
