- 3300 XL 8mm Proximity Transducer
- 330102-00-72-10-01-05
In Stock
Ships by Sunday, July 19
Fast Shipping Available
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330102-00-72-10-01-05
-
Product Model330102-00-72-10-01-05
-
Product Parameters3300 XL 8 mm Probe, 3/8-24 UNFthread, with armor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size20.5x22.4x3.3cm
-
ManufacturerBently Nevada
-
Weight0.25 kg
-
Unthreaded Length Option0.0 in
-
Overall Case Length Option7.2in
-
Total Length Option1.0 meter (3.3 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector with connectorprotector, standard cable
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
-
Operating Temperature (Probe)-52°C to +177°C (-62°F to +350°F)
Description
The Bently Nevada 330102-00-72-10-01-05 is a 3300XL 8mm Proximity Probe with 3/8-24 UNF thread and with armor, as a core component of the 3300XL 8mm Proximity Transducer System. The 330102-00-72-10-01-05 provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface, and can measure both static (position) and dynamic (vibration) values. The primary applications of the 330102-00-72-10-01-05 include vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurement.
The 330102-00-72-10-01-05 incorporates a patented TipLoc molding method that provides a more robust bond between the probe tip and the probe body, enhancing mechanical durability in demanding industrial environments. The probe cable of the 330102-00-72-10-01-05 incorporates a patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attach the probe cable and probe body, ensuring reliable connection integrity during installation and operation.
The 330102-00-72-10-01-05 incorporates a patented TipLoc molding method that provides a more robust bond between the probe tip and the probe body, enhancing mechanical durability in demanding industrial environments. The probe cable of the 330102-00-72-10-01-05 incorporates a patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attach the probe cable and probe body, ensuring reliable connection integrity during installation and operation.
Alternative Names
330102-00-72-10-01-O5
330102-00-72-10-0I-05
330102-00-72-10-O1-05
330102-00-72-1O-01-05
330102-00-72-I0-01-05
330102-00-7Z-10-01-05
330102-OO-72-10-01-05
33010Z-00-72-10-01-05
3301O2-00-72-10-01-05
330I02-00-72-10-01-05
33O102-00-72-10-01-05
330102 00 72 10 01 05
330102 00 72 10 01 O5
330102 00 72 10 0I 05
330102 00 72 10 O1 05
330102 00 72 I0 01 05
330102 00 72 1O 01 05
330102 00 7Z 10 01 05
330102 OO 72 10 01 05
33010Z 00 72 10 01 05
3301O2 00 72 10 01 05
330I02 00 72 10 01 05
33O102 00 72 10 01 05
330102-00-72-10-01-00
330102-00-72-10-01-CN
Information
Overview
Manuals
Application Note
Product Applications
Cable Connection & Wiring
Features:
- 3/8-24 UNF Thread with Armored Construction
- Patented TipLoc Molding for Robust Probe Tip Bond
- Patented CableLoc Design with 330N (75 lbf) Pull Strength
- Corrosion-Resistant Gold-Plated ClickLoc Connectors
- Wide Operating Temperature Range (-52°C to +177°C)
This probe features a 3/8-24 UNF imperial mounting thread with a 0.0-inch unthreaded length and an overall case length of 7.2 inches (182.88 mm). The probe tip diameter is 8.0 mm, constructed from Polyphenylene Sulfide (PPS), while the probe case is made from AISI 303 or 304 stainless steel. This variant is supplied with armor (base model 330102).
The armor consists of a flexible AISI 302 or 304 stainless steel braid with a protective outer jacket, providing mechanical protection for the cable in harsh industrial environments where abrasion, crushing, or rodent damage may occur. The armor covers the entire cable length except for the terminal 300 mm (11.8 in) at each end to allow connector access. The armored cable has an outside diameter of 7.67 mm (0.302 in) maximum, with armor ferrules measuring 10.2 mm (0.40 in) maximum in diameter. The armored cable weighs 64 g/m (0.7 oz/ft).
The 330102-00-72-10-01-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330102-00-72-10-01-05 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The probe is equipped with a 1.0-metre 75 Ω triaxial cable using Fluoroethylene Propylene (FEP) insulation. The cable terminates in a miniature coaxial ClickLoc connector with a connector protector, featuring gold-plated brass contacts. The connector protector provides a seal against contamination and moisture ingress at the probe-to-extension cable connection point. Silicone tape is included as a supplementary sealing method, though it is not recommended for applications where the connection will be exposed to turbine oil.
The 3300 XL 8 mm system delivers an output voltage directly proportional to the distance between the probe tip and the observed conductive surface. The linear range is 2.0 mm (80 mils), spanning from approximately 0.25 mm to 2.3 mm, with an output voltage range of approximately -1 Vdc to -17 Vdc. The Incremental Sensitivity Factor (ISF) is 7.87 V/mm (200 mV/mil) with a ±5% tolerance (including interchangeability error) from 0°C to +45°C. The recommended radial vibration gap setting is -9 Vdc, corresponding to approximately 1.27 mm (50 mils).
- Centrifugal Compressors: Provides early warning of shaft imbalances, misalignments, or bearing failures
- Turbo-Expanders: Tracks high-speed rotor stability in cryogenic/gas-processing facilities
- Pipeline Pumps: Safeguards crude/product transport pumps from catastrophic damage
- Fans/Blowers: Monitors massive air handlers in steel mills, cement plants, and mining
- Gearboxes: Tracks high-load shaft displacements to prevent gear meshing disasters
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
ClickLoc Connectors: The probe features a miniature coaxial ClickLoc connector. Firmly push and twist the ClickLoc connection until it locks into place to prevent accidental disconnection.
Extension Cable: If using an extension cable, make sure the connections are clean and dry. Securely connect the probe's ClickLoc connector to the extension cable and run it to the Proximitor Sensor.
SpringLoc Terminals: The Bently Nevada Proximitor Sensor uses SpringLoc terminal strips for field wiring. Use a small flathead screwdriver to press the spring mechanism and insert your stripped wires.
Shielding: Terminate the three-conductor shielded triad cable properly to the monitor to minimize Electromagnetic (EMI) and Radio Frequency Interference (RFI).
Technical notes
The 330102-00-72-10-01-05 operates over a standard temperature range of -52°C to +177°C (-62°F to +350°F). For applications in which the probe lead may exceed the standard 177°C (350°F) temperature specification, an Extended Temperature Range (ETR) probe option is available with an extended temperature rating up to 218°C (425°F) at the probe tip. The 330102-00-72-10-01-05 is designed to seal differential pressure between the probe tip and case using a Viton® O ring sealing material.
FAQs
-
What is the 330102-00-72-10-01-05?
+The Bently Nevada 330102-00-72-10-01-05 is an 8 mm proximity probe from the 3300 XL series.. -
What is the normal gap voltage for this proximity probe?
+When correctly gapped in the linear range (usually targeting a -1.27 mm gap) and the shaft is centered, the normal gap voltage is roughly -9 V to -11 V DC. -
Does this probe require an extension cable and Proximitor?
+Yes. The 72-foot total system length represents the combined length of the probe's lead, an extension cable, and the Proximitor sensor. All three components must be matched to ensure the system remains within API 670 standards. -
What is the operating temperature range for this model?
+This transducer system is rugged and can operate reliably in temperatures ranging from -34°C to +177°C (-29°F to +351°F).
