- 3300 XL 8mm Proximity Transducer
- 330106-05-30-10-02-05
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330106-05-30-10-02-05
-
Product Model330106-05-30-10-02-05
-
Product Parameters3300 XL 8 mm Reverse Mount Probes
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size1x0.9x114cm
-
ManufacturerBently Nevada
-
Weight0.05 kg
-
Total Length Option1.0 meter (3.3 feet)
-
Connector and Cable-Type OptionMiniature ClickLoc coaxialconnector
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
-
Output Resistance50 Ω
-
Extension Cable Capacitance69.9 pF/m (21.3 pF/ft)typical
Description
330106-05-30-CC-DD-EE M10 x 1 threads
10 1.0 meter (3.3 feet)
02 Miniature ClickLoc coaxialconnector
05 CSA, ATEX, IECEx Approvals
10 1.0 meter (3.3 feet)
02 Miniature ClickLoc coaxialconnector
05 CSA, ATEX, IECEx Approvals
Information
Overview
Manuals
Technical notes
Product Applications
Comparison with Related Models
Features:
- Armored and Unarmored Options
- Multiple Connector Options
- Complete Interchangeability of Units and Cabling
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
The 330106-05-30-10-02-05 Bently Nevada 3300 XL 8mm Reverse Mount Probes may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330106-05-30-10-02-05 3300 XL 8mm Reverse Mount Probes Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Each 3300 XL 8 mm Transducer System component isbackward compatible and interchangeable4 with other nonXL 3300 series 5 mm and 8 mm transducer systemcomponents5. This compatibility includes the 3300 5 mmprobe, for applications in which an 8 mm probe is too largefor the available mounting space
The 3300 XL probe and extension cable alsoreflect improvements over previous designs. Apatented TipLoc molding method provides amore robust bond between the probe tip andthe probe body. The probe’s cable incorporatesa patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attachthe probe cable and probe tip.
- Gas and Steam Turbines: Used to monitor thrust position, vibration, and differential expansion
- Centrifugal and Axial Compressors: Essential for monitoring axial (thrust) position and radial vibration
- Electric Motors and Generators: Used for shaft vibration and position measurements
- Pumps and Gearboxes: Often used in high-speed or critical service units to detect early signs of mechanical failure
- Power Generation: Ensures operational stability and efficiency in generators and large turbines.
- Marine Propulsion: Utilized in monitoring propulsion systems and key marine engine components.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The primary difference between these two Bently Nevada 3300 XL 8 mm probes is the thread type. While both are Reverse Mount Probes with identical performance specs, the 330106 uses Metric threads, while the 330105 uses Imperial (English) threads.
330106-05-30: This defines a Metric M10 x 1 thread with a 30 mm case length.
330105-02-12: This defines an Imperial 3/8-24 UNF thread with a 12 mm case length
330106 vs. 330105 Compatibility: These probes are functionally identical in terms of electrical output (200 mV/mil) and are both compatible with the 3300 XL 8 mm Proximitor Sensor. The choice between them depends entirely on the mechanical tapping of your machine's mounting hole.
FAQs
-
What is 330106-05-30-10-02-05 ?
+The Bently Nevada 330106-05-30-10-02-05 is a 3300 XL 8 mm reverse mount proximity probe for high-accuracy vibration monitoring in industrial machinery. -
What is the thread type of 330106-05-30-10-02-05?
+It uses an M10 x 1 thread for secure mounting on mechanical equipment. -
What is the material of the probe tip of 330106-05-30-10-02-05
+It is made of polyphenylene sulfide (PPS), a durable, high-temperature resistant, and robust material. -
Is it suitable for high-pressure environments?
+It is designed to seal differential pressure between the probe tip and case, but it is not pressure tested prior to shipment. -
What is the standard gap voltage for 330106-05-30-10-02-05?
+For the 3300 XL series, the normal gap voltage is typically -9 V to -11 V DC when the gap is correct and centered within its linear range.
