- 3300 XL 8mm Proximity Transducer
- 330103-00-05-10-02-00
In Stock
Ships by Wednesday, July 15
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330103-00-05-10-02-00
-
Product Model330103-00-05-10-02-00
-
Product Parameters330103 3300 XL 8 mm Probe
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size108x1.8x1.5cm
-
ManufacturerBently Nevada
-
Weight0.06 kg
-
Unthreaded Length Option0 mm
-
Overall Case Length Option50 mm
-
Total Length Option1.0 meter (3.3 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector with connectorprotector, standard cable
-
Agency Approval OptionNot required
Description
The Bently Nevada 330103-00-05-10-02-00 3300 XL 8 mm Proximity Probe, Metric is a precision proximity probe designed for the Bently Nevada 3300 XL 8mm Proximity Transducer System. 330103 serves as the sensing element that detects the distance between the probe tip and a conductive target surface, converting this mechanical gap into an electrical voltage signal proportional to the displacement for machinery condition monitoring applications.
330103-00-05-10-02-00 features an M10 × 1 metric thread configuration with an 8 mm probe tip diameter. The ordering configuration 330103-00-05-10-02-00 decodes as follows: 330103 indicates the 3300XL 8mm Probe with M10 × 1 thread and without armor; 00 indicates 0 mm unthreaded length; 05 indicates 50 mm overall case length; 10 indicates 1.0 meter (3.3 feet) total cable length; 02 indicates a miniature coaxial ClickLoc connector with connector protector and standard cable; and 00 indicates no agency approval required. The unthreaded length of 330103 must be at least 20 mm less than the case length, with maximum unthreaded length of 230 mm and minimum of 0 mm. The overall case length of 330103 is ordered in increments of 10 mm, with maximum case length of 250 mm and minimum of 20 mm.
330103-00-05-10-02-00 features an M10 × 1 metric thread configuration with an 8 mm probe tip diameter. The ordering configuration 330103-00-05-10-02-00 decodes as follows: 330103 indicates the 3300XL 8mm Probe with M10 × 1 thread and without armor; 00 indicates 0 mm unthreaded length; 05 indicates 50 mm overall case length; 10 indicates 1.0 meter (3.3 feet) total cable length; 02 indicates a miniature coaxial ClickLoc connector with connector protector and standard cable; and 00 indicates no agency approval required. The unthreaded length of 330103 must be at least 20 mm less than the case length, with maximum unthreaded length of 230 mm and minimum of 0 mm. The overall case length of 330103 is ordered in increments of 10 mm, with maximum case length of 250 mm and minimum of 20 mm.
Alternative Names
330103-00-05-10-02-OO
330103-00-05-10-0Z-00
330103-00-05-IO-02-00
330103-00-O5-10-02-00
330103-OO-05-10-02-00
3301O3-00-05-10-02-00
330I03-00-05-10-02-00
33O103-00-05-10-02-00
330103 00 05 10 02 00
330103 00 05 10 02 OO
330103 00 05 IO OZ 00
330103 00 O5 10 02 00
330103-00-05-10-02-05
330103-00-05-10-02-CN
330103-00-05-10-02-BR
330103-00-05-10-02-RU
Information
Overview
Manuals
Application Notes
Product Applications
Cable & Sensor Connections
Features:
- M10 × 1 Metric Thread with 8 mm Tip Diameter
- Patented TipLoc Molding for Robust Probe Tip Bond
- 2.0 mm (80 mil) Linear Measuring Range
- Wide Temperature Range (-51°C to +177°C)
- Complete Interchangeability with 3300XL System Components
The 3300 XL 8 mm system delivers an output voltage directly proportional to the distance between the probe tip and the observed conductive surface. The linear range is 2.0 mm (80 mils), spanning from approximately 0.25 mm to 2.3 mm, with an output voltage range of approximately -1 Vdc to -17 Vdc. The Incremental Sensitivity Factor (ISF) is 7.87 V/mm (200 mV/mil) with a ±5% tolerance (including interchangeability error) from 0°C to +45°C. The recommended radial vibration gap setting is -9 Vdc, corresponding to approximately 1.27 mm (50 mils).
The 330103-00-05-10-02-00 Bently Nevada 3300 XL 8 mm Proximity Probes, Metric may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330103-00-05-10-02-00 3300 XL 8 mm Proximity Probes, Metric Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL 8 mm system delivers an output voltage directly proportional to the distance between the probe tip and the observed conductive surface. The linear range is 2.0 mm (80 mils), spanning from approximately 0.25 mm to 2.3 mm, with an output voltage range of approximately -1 Vdc to -17 Vdc. The Incremental Sensitivity Factor (ISF) is 7.87 V/mm (200 mV/mil) with a ±5% tolerance (including interchangeability error) from 0°C to +45°C. The recommended radial vibration gap setting is -9 Vdc, corresponding to approximately 1.27 mm (50 mils).
The nominal DC resistance for the 1.0-metre probe is 7.59 ± 0.50 Ω. The probe operates over a temperature range of -52°C to +177°C (-62°F to +350°F) and maintains humidity tolerance with less than 3% ISF change after 56 days of 93% relative humidity exposure. The probe tip-to-case seal uses a Viton® O-ring; probes are not pressure tested prior to shipment.
- Oil/Gas/Petrochemical: Monitors critical machinery processing volatile hydrocarbons in hazardous explosive zones
- Power Generation: Tracks turbine/generator shaft movements in thermal, nuclear, and hydro plants
- Chemical Processing: Resists corrosive vapors with PPS thermoplastic housing
- Water/Wastewater: Operates reliably in moisture/humidity/outdoor spaces with IP66 washdown protection
- Mining/Heavy: Withstands dust, abrasive particles, and extreme mechanical vibration
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The 330103 probe features an integral cable that connects to a 3300 XL Proximitor Sensor.
Probe to Extension Cable: Ensure the coaxial connectors are clean and free of debris. Finger-tighten the connectors until snug. Do not over-tighten with pliers or wrenches.
CableLoc Design: The probe cable features a connector that locks securely and provides a 330 N (75 lb) pull strength.Extension Cable to Proximitor: Connect the other end of the extension cable to the Proximitor Sensor.
Technical notes
330103-00-05-10-02-00 incorporates a patented TipLoc molding method that provides a more robust bond between the probe tip and the probe body. This TipLoc technology of 330103 improves mechanical durability and long-term reliability in harsh industrial environments where vibration, thermal cycling, and mechanical stress are present. The probe cable of 330103 also incorporates a patented CableLoc design that provides 330 N (75 lbf) pull strength to more securely attach the probe cable and probe body.
FAQs
-
What is the 330103-00-05-10-02-00?
+The Bently Nevada 330103-00-05-10-02-00 is a standard 3300 XL 8mm Proximity Probe to measure vibration and position in industrial rotating machinery. -
Does it require matching with specific cables or proximitors?
+No. The 3300 XL 8mm system components are completely interchangeable. You can swap probes, extension cables, or Proximitor sensors without requiring individual component matching or bench recalibration. -
Is this probe pressure-sealed?
+The probes are designed to seal differential pressure between the probe tip and case using a Viton O-ring. However, they are not pressure-tested before shipment. Custom tests for the pressure seal must be requested separately. -
What is the measurement range?
+The system has a dynamic measurement range of up to ± 100 mils (± 2.5 mm) and operates at a frequency response of up to 10 kHz.
