- 3300 XL 8mm Proximity Transducer
- 330103-00-03-05-02-05
In Stock
Ships by Sunday, August 30
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330103-00-03-05-02-05
-
Product Model330103-00-03-05-02-05
-
Product ParametersProximitor Probe
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size1.7x1.5x65.5cm
-
ManufacturerBently Nevada
-
Weight0.05 kg
-
Unthreaded Length Option00mm
-
Overall Case Length Option30mm
-
Total Length Option0.5 metre (1.6 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocTM connector
Description
The BENTLY NEVADA 330103-00-03-05-02-05 is designed for non-contact measurement of shaft displacement in rotating machinery. The 8 mm probe is used with compatible 3300 XL Proximitor Sensors and extension cables to form a complete proximity transducer system for machinery vibration and position monitoring.
The BENTLY NEVADA 330103-00-03-05-02-05 uses an M10 x 1 metric mounting thread and has a standard-mount, unarmored configuration. The 330103 product family is specifically identified as the 3300 XL 8 mm Probe, M10 x 1 thread, without armor.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
The BENTLY NEVADA 330103-00-03-05-02-05 uses an M10 x 1 metric mounting thread and has a standard-mount, unarmored configuration. The 330103 product family is specifically identified as the 3300 XL 8 mm Probe, M10 x 1 thread, without armor.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
Information
Overview
Manuals
Application Notes
Product Applications
Probe Insertion
Features:
- M10 x 1 Metric Thread without Armor
- 0.0 Inch Unthreaded Length with 0.3 Inch Overall Case Length
- 0.5 Meter (1.6 Feet) Total Cable Length
- Complete Interchangeability of Components
- API 670 Standard Compliance
- Backward Compatibility with Non-XL 3300 Series
The 330103-00-03-05-02-05 is part of the 3300 XL 8mm system that delivers the most advanced performance in Bently Nevada's eddy current proximity transducer systems. The 330103-00-03-05-02-05 supports complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
The 330103-00-03-05-02-05 Bently Nevada 3300 XL 8 mm Probe, M10 x 1 thread,without armor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330103-00-03-05-02-05 3300 XL 8 mm Probe, M10 x 1 thread,without armor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 330103-00-03-05-02-05 has a maximum tensile strength of 330N (75 lbf) from probe case to probe lead. The 330103-00-03-05-02-05 is approved with multiple agency approvals including CSA, ATEX, and IECEx.
The 330103-00-03-05-02-05 operates over a temperature range of -52°C to +177°C (-62°F to +350°F). The 330103-00-03-05-02-05 is designed to seal differential pressure between the probe tip and case using a Viton O-ring seal.
The 330103-00-03-05-02-05 is compliant with FCC part 15 rules, EN 61000-6-2 and EN 61000-6-4 EMC Directive 2014/30/EU, RoHS Directive 2011/65/EU, and carries ABS 2019 Steel Vessels Rules maritime certification. The 330103-00-03-05-02-05 is also certified for Functional Safety SIL 2 (HFT = 0) and SIL 3 (HFT = 1).
- Gas & Steam Turbines: Tracks radial vibration and casing expansion under high temperatures
- Centrifugal & Axial Compressors: Monitors shaft alignment and surge conditions
- Electric Motors & Generators: Detects bearing wear and rotor imbalances to prevent failure
- Pumps & Gearboxes: Continuously maps distance to fluid-film bearings
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Thread alignment: Screw the M10x1 probe body carefully into the mounting hole or bracket to avoid damaging the threads.
Gap setting: Adjust the distance (gap) between the probe tip and the shaft using a multitester or readout device until the target gap voltage reaches approximately -10 VDC (linear range typically spans -9 VDC to -11 VDC).
Locking: Tighten the locknut firmly against the mounting bracket once the correct gap is set to prevent shifting during machine operation.
Alternative Names
330103-00-03-05-02-O5
330103-00-03-05-0Z-05
330103-00-03-05-O2-05
330103-00-03-O5-02-05
330103-00-O3-05-02-05
330103-O0-03-05-02-05
3301O3-00-03-05-02-05
330I03-00-03-05-02-05
33O103-00-03-05-02-05
330103 00 03 05 02 05
330103 00 03 05 02 O5
330103 00 03 05 O2 05
330103 00 03 O5 02 05
330103 00 O3 05 02 05
330103 OO 03 05 02 05
3301O3 00 03 05 02 05
330I03 00 03 05 02 05
33O103 00 03 05 02 05
330103-00-03-05-02-00
330103-00-03-05-02-CN
330103-00-03-05-02-BR
330103-00-03-05-02-RU
Technical notes
The 330103-00-03-05-02-05 has a maximum tensile strength of 330N (75 lbf) from probe case to probe lead. The 330103-00-03-05-02-05 is approved with multiple agency approvals including CSA, ATEX, and IECEx.The 330103-00-03-05-02-05 operates over a temperature range of -52°C to +177°C (-62°F to +350°F). The 330103-00-03-05-02-05 is designed to seal differential pressure between the probe tip and case using a Viton O-ring seal.
FAQs
-
What target material is it calibrated for?
+By default, the 3300 XL system is factory calibrated to AISI 4140 steel Scribd. If your target machine features a different shaft material, custom calibration must be specified or adjusted on the Proximitor sensor. -
Can components be swapped?
+Yes. Complete interchangeability between probes, extension cables, and Proximitor sensors is supported without bench calibration. -
Is it backward compatible?
+Yes, components work with older non-XL 3300 series 5 mm and 8 mm systems.. -
What do the part number codes mean?
+Model 330103 specifies an 8 mm probe with M10 x 1 threads and no armor. Suffix -00-03-05-02-05 defines unthreaded length, a 30 mm case length, a 0.5-meter total cable length, a miniature ClickLoc coaxial connector, and specific hazardous area approvals.
