Technical specifications for 330104-00-09-10-01-05
-
Product Model330104-00-09-10-01-05
-
Product Parameters3300 XL 8 mm Proximity Probe
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size32x30x2 cm
-
ManufacturerBently Nevada
-
Weight0.2 kg
-
Unthreaded Length Option00 mm
-
Overall Case Length Option90 mm
-
Total Length Option1.0 metre (3.3 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector with connectorprotector, standard cable
-
Agency Approval OptionCSA, ATEX, IECEx Certifications
Description
330104 3300 XL 8 mm Probe
M10 x 1 Thread, with Armor
Minimum Unthreaded Length: 00 mm
Minimum Length: 90 mm
1 0 1.0 metre (3.3 feet)
0 1 Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
0 5 CSA, ATEX, IECEx Certifications
M10 x 1 Thread, with Armor
Minimum Unthreaded Length: 00 mm
Minimum Length: 90 mm
1 0 1.0 metre (3.3 feet)
0 1 Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
0 5 CSA, ATEX, IECEx Certifications
Information
Overview
Manuals
Technical notes
Product Applications
Pre-Installation Setup
Features:
- Armored and Unarmored Options
- Multiple Connector Options
- Complete Interchangeability of Units and Cabling
The 3300 XL 8 mm system delivers the most advanced performance in our eddycurrent proximity transducer systems. The standard 3300 XL 8 mm 5-metresystem also fully complies with the American Petroleum Institute’s (API) 670Standard (4th Edition) for mechanical configuration, linear range, accuracy, andtemperature stability. All 3300 XL 8 mm proximity transducer systems providethis level of performance and support complete interchangeability of probes,extension cables, and Proximitor sensors, eliminating the need to match orbench calibrate individual components.
The 330104-00-09-10-01-05 Bently Nevada 3300 XL 8 mm Proximity Probe may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330104-00-09-10-01-05 3300 XL 8 mm Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL probe and extension cable also reflectimprovements over previous designs. A patentedTipLoc molding method provides a more robustbond between the probe tip and the probe body.The probe’s cable incorporates a patented CableLoc design that provides 330 N (75 lbf) pull strength tomore securely attach the probe cable and probe tip.You can also order 3300 XL 8 mm probes andextension cables with an optional FluidLoc* cableoption. This option prevents oil and other liquidsfrom leaking out of the machine through the cable’sinterior.
- Oil & Gas:Monitors critical equipment in hazardous offshore/refinery environments
- Power Generation:Tracks shaft vibration/position for turbines & generators
- Petrochemical Processing:Protects probes in corrosive atmospheres; monitors reactor pumps/compressors
- Heavy Manufacturing:Protects instrumentation from impact/debris in mills & plants
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Verify Components: Ensure the assembly includes the aluminum housing body, dome cover, 3300 XL 8 mm probe (reverse mount), 0.5m cable, and the 2.0-inch standoff adapter.
Standoff Mounting: Thread the standoff adapter into the machine case first using the 3/4-14 NPT mounting thread.
Sleeve Preparation: This model has a 6.5-inch penetration. Ensure the total length (standoff + penetration) is clear of internal obstructions.
FAQs
-
What is the typical gap voltage for this probe?
+When the probe is correctly mounted and centered within its linear range, the normal gap voltage range is typically -9 V to -11 V DC. -
What is the linear range of this probe?
+The 3300 XL 8 mm probes provide a 2 mm (80 mils) linear range, which is standard for measuring vibration and position -
What materials are used to construct the 330104 probe?
+The probe tip is made of Polyphenylene sulfide (PPS), and the probe case is made of AISI 303 or 304 stainless steel. -
Can this probe be used with older Bently Nevada systems?
+The 3300 XL 8mm system is generally compatible with other 3300XL system components, but not with older 3300 RAM or 7000-series systems without component upgrades. -
What is the maximum pull strength of the cable?
+The probe cable features a 330 N (75 lbf) pull strength at the connection between the probe case and probe lead.
