- 3300 XL 8mm Proximity Transducer
- 330104-01-09-10-11-05
In Stock
Ships by Monday, August 17
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330104-01-09-10-11-05
-
Product Model330104-01-09-10-11-05
-
Product Parameters3300 XL 8 mm Probe, M10 x 1 thread,with armor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size1.7x1.5x116cm
-
ManufacturerBently Nevada
-
Weight0.15 kg
-
Unthreaded Length Option0 mm
-
Overall Case Length Option50 mm
-
Total Length Option9.0 meters (29.5 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector standard cable
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
Description
The BENTLY NEVADA 330104-01-09-10-11-05 3300 XL 8 mm Proximity Probe is a non-contact eddy-current displacement sensor used to monitor the position and movement of conductive machine components, typically rotating shafts. It is part of the Bently Nevada 3300 XL 8 mm Proximity Transducer System, which consists of a compatible probe, extension cable, and Proximitor Sensor. The system can provide measurements for both static shaft position and dynamic shaft vibration.
This probe uses an M10 × 1 threaded mounting configuration and is identified as the 330104 probe family, which corresponds to a 3300 XL 8 mm probe with M10 × 1 thread and armor. The 01 option specifies a 10 mm unthreaded length, while the 09 option specifies a 90 mm overall case length. The 10 option specifies a 1.0 m / 3.3 ft probe length.
The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position) and dynamic (vibration) values. The system’sprimary applications are vibration and positionmeasurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements
This probe uses an M10 × 1 threaded mounting configuration and is identified as the 330104 probe family, which corresponds to a 3300 XL 8 mm probe with M10 × 1 thread and armor. The 01 option specifies a 10 mm unthreaded length, while the 09 option specifies a 90 mm overall case length. The 10 option specifies a 1.0 m / 3.3 ft probe length.
The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position) and dynamic (vibration) values. The system’sprimary applications are vibration and positionmeasurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements
Information
Overview
Manuals
Technical notes
Product Applications
Gap Setting Procedure
Features:
- Armored and Unarmored Options
- Multiple Connector Options
- Complete Interchangeability of Units and Cabling
The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components
The 330104-01-09-10-11-05 Bently Nevada 3300 XL 8 mm proximity probe may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330104-01-09-10-11-05 3300 XL 8 mm proximity probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position) and dynamic (vibration) values. The system’sprimary applications are vibration and positionmeasurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements.
- Centrifugal Air Compressors: High-speed rotating equipment where space for sensors is limited
- Refrigeration Compressors: Specialized industrial cooling units
- Process Gas Compressors: Systems handling various industrial gases; the probe's chemical resistance makes it ideal for these environments
- Turbo Expanders: High-speed turbines used in gas processing
- Electric Motors & Generators: Specifically those with tight internal clearances or small fluid-film bearings
- Pumps & Fans: Centrifugal or positive displacement pumps where mounting between bearing pads is required
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Target Voltage: For the 3300 XL 8 mm system, the standard field setting is between -9.5 Vdc and -10.0 Vdc.
Physical Gap: A gap voltage of -9.0 Vdc typically corresponds to a physical distance of 1.27 mm (50 mils) from the target.
Verification: Use a voltmeter at the Proximitor sensor's "OUT" and "COM" terminals to monitor the DC voltage while slowly threading the probe toward the shaft.
Alternative Names
330104-01-09-10-11-O5
330104-01-09-10-II-05
330104-01-09-1O-11-05
330104-01-09-I0-11-05
330104-01-O9-10-11-05
330104-0I-09-10-11-05
330104-O1-09-10-11-05
3301O4-01-09-10-11-05
330I04-01-09-10-11-05
33O104-01-09-10-11-05
330104 01 09 10 11 05
330104 01 09 10 11 O5
330104 01 09 10 II 05
330104 01 09 1O 11 05
330104 01 09 I0 11 05
330104 01 O9 10 11 05
330104 0I 09 10 11 05
330104 O1 09 10 11 05
3301O4 01 09 10 11 05
330I04 01 09 10 11 05
33O104 01 09 10 11 05
330104-01-09-10-11-00
330104-01-09-10-11-CN
Technical notes
The 1.0 m probe length is used as part of the complete transducer system and must be matched with the correct extension cable and Proximitor Sensor. Bently Nevada specifies system configurations based on the total system length, and the probe, extension cable, and Proximitor Sensor should be selected as a compatible combination. The M10 × 1 thread engagement should also remain within the specified maximum engagement limits during installation.
FAQs
-
What is the 330104-01-09-10-11-05 model?
+This is a 3300 XL 8 mm Proximity Probe, a key component in vibration monitoring systems. -
What is the linear range of 330101-00-25-05-01-05?
+The linear range of the 3300 XL 8 mm sensor system is 2 mm (80 mils), with a typical measurement range of 0.25 mm to 2.3 mm (10 to 90 mils). -
What is the sensitivity?
+The system provides a nominal sensitivity of 7.87 V/mm (200 mV/mil). -
What are the typical application environments?
+The probes are to be used in hazardous environments. They comply with IECEx/ATEX regulations and can operate in temperatures ranging from -51 °C to +100 °C for standard models, with higher options available
