330192-00-20-10-00
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
330192 3300 XL 8 mm ETR Probe
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in
Minimum case length:2.0 in
10 1.0 meter (3.3 feet)
00 Not required
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in
Minimum case length:2.0 in
10 1.0 meter (3.3 feet)
00 Not required
Technical specifications for 330192-00-20-10-00
-
Product Model330192-00-20-10-00
-
Product Parameters3300 XL 8 mm Extended TemperatureRange (ETR) Proximity Probes
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size1.8x1.6x110cm
-
ManufacturerBently Nevada
-
Weight0.1 kg
-
Unthreaded Length Option0.0 in
-
Overall Case Length Option2.0 in
-
Total Length Option1.0 meter (3.3 feet)
-
Agency Approval OptionNot required
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is 330192-00-20-10-00?+The Bently Nevada 330192-00-20-10-00 is a 3300 XL 8 mm Extended Temperature Range (ETR) Proximity Probe, designed for harsh, high-temperature environments. It is part of a transducer system used to measure vibration and position on turbo machinery.
-
What is the primary application for this probe?+It is used for non-contact vibration and position measurements on rotating machinery with fluid-film bearings, such as turbines and compressors. It can also serve as a Keyphasor reference for speed measurements.
-
What are the temperature limits for the ETR version?+The probe tip is rated for temperatures ranging from -52°C to +218°C (-60°F to +425°F). The probe cable and connector can withstand up to +260°C (+500°F).
-
What target material is this system calibrated for?+By default, the 3300 XL system is factory-calibrated for AISI 4140 steel. Using other target materials will change the scale factor unless the Proximitor sensor is specifically recalibrated.
Get a quick price fo 330192-00-20-10-00
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Mechanical Mounting
Features:
- 3300 XL 8 mm Extended TemperatureRange (ETR) Proximity Probes
- Gold-Plated ClickLoc™ Connectors
- High-Performance Polyphenylene Sulfide (PPS) Tip
- Seamless 3300 XL System Integration
The 330192-00-20-10-00 Bently Nevada 3300 XL 8 mm Extended TemperatureRange (ETR) Proximity Probes may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330192-00-20-10-00 ETR Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The probe operates on the eddy current principle, providing non-contacting measurements of shaft vibration and axial position with sub-micron precision. Its internal construction features a high-purity copper wire coil encased in a chemically inert PPS tip, ensuring that the sensor maintains its calibration even after years of exposure to hot lubricating oils and synthetic fluids.
- Gas Turbines: Used inside the high-heat turbine environment to monitor radial vibration and thrust position
- Steam Turbines: Monitoring rotor position and bearing housing struts in power generation applications.
- Centrifugal Compressors: Measuring shaft movement in air, refrigeration, and process gas compressors
- Large Pumps: Monitoring critical boiler feed pumps or high-pressure process pumps
- Electric Motors: Specifically large industrial motors that utilize fluid-film bearings
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Gap Setting: The recommended physical gap between the probe tip and the target surface is 1.27 mm (50 mils).
Case Torque: For 3/8-24 threaded probes, the recommended installation torque is 68 N•m (50 ft•lb), with a maximum rated limit of 163 N•m (120 ft•lb).
Side Clearance: Ensure a minimum side clearance of 16.0 mm (0.63 in) from any metal other than the target to prevent "side-viewing" interference.
Cable Bend Radius: Maintain a minimum bend radius of 25.4 mm (1.0 in) for the armored probe cable to prevent internal damage.
