- 3300 XL NSV Proximity Transducer
- 330905-00-11-05-02-00
In Stock
Ships by Wednesday, July 8
Fast Shipping Available
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330905-00-11-05-02-00
-
Product Model330905-00-11-05-02-00
-
Product Parameters3300 NSv Probe, M10X1 thread,without armor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size1.8x1.6x66cm
-
ManufacturerBently Nevada
-
Weight0.05 kg
-
Unthreaded Length Option0 mm
-
Overall Case Length Option110 mm
-
Total Length Option0.5 meter (20 in)
-
Connector and Cable-Type OptionMiniature coaxial ClickLoc connector,standard cable
-
Agency Approval OptionNot required
-
Sensitivity7.87 V/mm (200 mV/mil) ± 5%
-
AccuracyWithin ±0.5% of full scale (at 25°C)
-
Resolution0.1 µm (4 µin) typical
-
Frequency Response0 to 10 kHz (-3 dB)
Description
The 330905-00-11-05-02-00 is an eddy current proximity probe from the Bently Nevada 3300 NSv (Narrow Side View) series. It is configured with an M10 × 1 metric thread, 0.0 mm unthreaded length, 11 mm overall case length, and 0.5 meter total unarmored cable length.
The probe operates as the sensing element of the 3300 NSv eddy current transducer system, detecting the distance between the probe tip and a conductive target surface through electromagnetic induction. The 5.0 mm probe tip diameter provides a linear measurement range of 1.0 mm (40 mils) with a standard gap setpoint of 0.5 mm (20 mils). System sensitivity is 7.87 V/mm (200 mV/mil) with ±5% tolerance, delivering an output voltage of -10 VDC to -24 VDC proportional to the probe-to-target gap.
The probe operates as the sensing element of the 3300 NSv eddy current transducer system, detecting the distance between the probe tip and a conductive target surface through electromagnetic induction. The 5.0 mm probe tip diameter provides a linear measurement range of 1.0 mm (40 mils) with a standard gap setpoint of 0.5 mm (20 mils). System sensitivity is 7.87 V/mm (200 mV/mil) with ±5% tolerance, delivering an output voltage of -10 VDC to -24 VDC proportional to the probe-to-target gap.
Alternative Names
330905-00-11-05-02-0O
330905-00-11-05-O2-00
330905-00-11-O5-02-00
330905-00-1I-05-02-00
330905-0O-11-05-02-00
3309O5-00-11-05-02-00
33O905-00-11-05-02-00
330905 00 11 05 02 00
330905 00 11 05 02 0O
330905 00 11 05 O2 00
330905 00 11 O5 02 00
330905 00 1I 05 02 00
330905 0O 11 05 02 00
3309O5 00 11 05 02 00
33O905 00 11 05 02 00
Information
Overview
Manuals
Application Notes
Product Applications
Connection & Wiring
Features:
- 3300 NSv eddy current proximity probe
- M10 × 1 threaded mounting
- 1.5 mm linear measurement range
- Non-contact shaft vibration and position measurement
- Integrated coaxial ClickLoc® connector
This probe uses eddy current sensing technology, where the electromagnetic field generated at the probe tip interacts with the conductive shaft surface. Changes in distance between the probe and target are converted into a proportional DC voltage output, typically ranging from -1 V to -13 V across its linear measurement range. This signal is then processed by the Proximitor® system for vibration and position monitoring.
The 330905-00-11-05-02-00 Bently Nevada 3300 NSv Probe, M10X1 thread,without armor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330905-00-11-05-02-00 3300 NSv Probe, M10X1 thread,without armor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The M10 × 1 metric thread enables direct mounting into metric threaded bosses or adapters. The 0.0 mm unthreaded length indicates the probe tip is flush with the end of the threaded section, suitable for installations where the probe mounts directly against the target surface or through a thin mounting plate. The 11 mm overall case length is an extremely compact configuration, providing minimal probe extension for installations with severe space constraints. The 0.5 meter total length includes a short integral probe cable with a standard miniature coaxial connector, designed for connection to extension cables that route to the proximitor.
- Power Generation: Deployed in thermal/nuclear/combined-cycle stations to safeguard generator sets
- Oil & Gas: Implemented across upstream/downstream machinery to mitigate catastrophe risks
- Petrochemical Refining: Protects continuous-duty process compressors from severe structural cross-contact
- Steam Turbines: Tracks differential growth between fast-heating rotor and slower-expanding stator casing
- Gas Compressors: Monitors axial changes and heavy shaft displacements in industrial compressors
- Fluid-Film Bearings: Provides long-range non-contact positioning for massive rotating assemblies
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Connectors: The specific part number ends in -02-00, meaning it features standard ClickLoc connectors with gold-plated brass contacts. ClickLoc connectors mechanically lock into place to prevent loosening from machine vibration
.Extension Cable: You must use the matching 3300 NSv extension cable.Field Wiring: Connect the Proximitor to your monitor using a 3-conductor, braided shielded triad cable (0.2 to 1.5 mm² or 16-24 AWG).
Cable Length: The maximum allowed distance between the Proximitor sensor and the monitor is 305 meters (1,000 feet)
Technical notes
The NSv designation indicates a narrow side-view probe design, featuring a reduced tip diameter of 5.0 mm compared to the standard 8.0 mm 3300 XL probes. This smaller tip diameter is suited for installations with limited radial clearance, such as in small bearing housings, between closely spaced shafts, or in applications where multiple probes must be installed in close proximity. The reduced tip size requires a smaller minimum target diameter of 12.7 mm (0.5 in) compared to 15 mm for 8 mm probes.
FAQs
-
What target material is the probe calibrated for?
+By default, the 3300 XL NSv system is factory-calibrated to AISI 4140 steel. If your machinery uses a different target material, the system's accuracy and interchangeability specifications will not apply unless you request a custom calibration. -
What is the 330905-00-11-05-02-00?
+The Bently Nevada 330905-00-11-05-02-00 is a 3300 XL NSv Proximity Probe designed to track radial and axial machine vibrations, particularly in chemical plants and compressors. -
What is the recommended gap distance for installation?
+To function correctly, the probe must maintain a standard gap of 1.0 mm from the target surface. When installing, it should be tightened to roughly 7.5 N⋅m (hand-tight) and care should be taken to avoid sharp bends in the cable. -
Can this model replace older Bently Nevada systems?
+Yes. The 3300 NSv system is designed to directly replace obsolete 3300 RAM systems, as well as 3000 and 7000-series 190 Transducer Systems.
