Technical specifications for 107770-03-03
-
Product Model107770-03-03
-
Product ParametersVelocity Transducer Housing –CENELEC approved
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size10x4x4cm
-
ManufacturerBently Nevada
-
Weight0.38 kg
-
Mounting Thread Option1/2 - 14 NPT
-
Cable Exit Fitting Option1/2 - 14 NPT explosion-proof withcable gland seal
-
Housing Material303 Stainless steel
-
Sensor Case Material316L Stainless steel
-
Connector2-pin Mil-C-5015 hermetically sealed, 316L stainless steel shell
-
Protection ClassIP65 / NEMA 4X
Description
The Bently Nevada 107770-03-03 is a CENELEC-approved Velocity Transducer Housing Assembly that combines a 330500 Velomitor® Piezo-velocity Sensor pre-installed inside a 21128 stainless steel housing at the factory. This integrated design is specifically rated for Zone 1, Group IIC hazardous area applications, providing a rugged, explosion-proof solution for absolute vibration monitoring on bearing housings, machine casings, or structural surfaces in explosive atmospheres.
The housing is specifically designed to provide mechanical protection and hazardous-area certification for velocity transducers installed on rotating equipment. petrochemical facilities, and power plants. or resonance. gases or vapors may be present. machinery protection applications. Compatible with velocity transducer assemblies
The housing is specifically designed to provide mechanical protection and hazardous-area certification for velocity transducers installed on rotating equipment. petrochemical facilities, and power plants. or resonance. gases or vapors may be present. machinery protection applications. Compatible with velocity transducer assemblies
Alternative Names
1O777O-O3-O3
107770 03 03
I07770-03-03
107770-03-02
107770-03-01
1O777O-O3-O1
1O777O-O3-O2
Information
Overview
Manuals
Cross-Talk & Electrical Isolation
Product Applications
Mechanical Mounting
Features:
- Factory-assembled combination
- CENELEC Zone 1, Group IIC hazardous area rating
- Flexible mounting orientation
- Requires cable part number 89477-AA
- Measures absolute vibration relative to free space
The assembly measures absolute vibration relative to free space for bearing housing, casing, or structural vibration. The 330500 sensor incorporated in this housing is a piezoelectric accelerometer with embedded integrated electronics. It has no moving parts and does not suffer from mechanical degradation or wear. The transducer can be mounted vertically, horizontally, or at any other angle of orientation.
When using the 21128 Housing, cable part number 89477-AA is necessary to connect the Velomitor Sensor to the monitoring system. The output is 100 mV/in/s (4 mV/mm/s). The sensor operates with a 2-pin MIL-C-5015 receptacle connector. The case has a 15/16 inch hexagonal section and a 3/8-24 UNF-2B mounting thread with a minimum threaded depth of 6.4 mm (0.250 in).
The 107770-03-03 Bently Nevada Velocity Transducer Housing Assembly may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 107770-03-03 Velocity Transducer Housing Assembly Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Minimum Probe Spacing: When installing multiple proximity probes near the same bearing, maintain a minimum physical distance between probe tips of at least 40 mm (1.6 inches) for 8 mm probes. Placing them too close causes electromagnetic cross-talk, which appears as a false low-frequency beat signal on your vibration monitors.
Structural Ground Loops: The integrated mounting base provides 500 Vrms of galvanic isolation from the mechanical enclosure frame [3]. Never bridge the terminal COM to the local junction box chassis, or you will defeat this isolation and introduce parasitic plant electrical noise into the vibration readings
- Steam Turbine Generators:Rotor-casing differential expansion
- Gas Turbines:Axial/structural expansion near heat zones
- Hydroelectric Turbines:Shaft wobble & thrust from hydraulic loads
- Marine Propulsion Systems:Thermal expansion for shafts & gearboxes.
- Steel Rolling Mills:Roll-gap/thrust under cyclic peak loads
- Large Cooling Tower Fans:Alignment & vibration across long couplings
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Isolate the Base: The integrated mounting base provides 500 Vrms of electrical isolation. Mount it directly to the panel or DIN rail without adding separate isolation plates.Orientation: Position the unit inside an enclosure with the terminal strips facing forward or upward to allow easy wire access and viewing.Spacing: Leave at least 25.4 mm (1.0 inch) of clearance on all sides of the coaxial connectors to prevent bending strain on the cables.
Technical notes
The Bently Nevada 107770-03-03 is a specialized industrial piezo-velocity sensor housing unit designed to protect internal vibration sensors and safely measure absolute bearing housing and structural casing vibration in heavy machinery
FAQs
-
What is the 107770-03-03？
+The Bently Nevada 107770-03-03 is a specialized industrial piezo-velocity sensor housing unit designed to protect internal vibration sensors and safely measure absolute bearing housing and structural casing vibration in heavy machinery -
What is the difference between 107770-03-03 and 107770-03-01?
+The core difference lies entirely in the cable exit option. While both feature the same 1/2-14 NPT mounting threads, the -01 variant features a basic 1/2-14 NPT plug, whereas the -03 option provides a specialized explosion-proof cable gland seal meant for direct hazardous area wiring -
What is the proper mounting torque for the internal sensor?
+When servicing or installing adapters, the sensor housing assembly should be tightened to a maximum torque range of 32 to 46 kg-cm (24 to 40 in-lb). Exceeding this can damage the internal piezoelectric element, while undertorquing causes false, attenuated, or noisy high-frequency vibration signals.
