3500/40M 140734-01
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
This image is for reference only product style, specific date of manufacture and product version, please refer to the actual product delivery!
Product Information
Product Describe
350040M
PROXIMITOR MONITOR
4-CHANNEL
INTERNAL BARRIERS AND
INTERNAL TERMINATIONS
CSA/NRTL/C (CLASS 1 DIV 2)
PROXIMITOR MONITOR
4-CHANNEL
INTERNAL BARRIERS AND
INTERNAL TERMINATIONS
CSA/NRTL/C (CLASS 1 DIV 2)
Specifications
-
Product Model3500/40M 140734-01
-
Spare Model140734-01
-
Product ParametersProximitor Monitor 3500 Series PWA
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size2.6x25.8x24cm
-
ManufacturerBently Nevada
-
weight0.8 kg
-
Operating Temperature-30°C to +65°C(-22°F to +150°F)
-
Storage Temperature-40°C to +85°C(-40°F to +185°F)
-
Powerconsumption7.7 Watts, typical
-
Standard I/O10 kΩ
-
Signal Accepts from1 to 4 proximitytransducer signals
-
Output Impedance550 Ω
-
Transducer Power Supply-24 Vdc
-
Smax Within±5% maximum
-
Direct filter-3 dB at 1.2 Hz
-
Gap filter-3 dB at 0.41 Hz
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the 3500/40M 140734-01？+The Bently Nevada 3500/40M (140734-01) Proximitor Monitor is a 4-channel module designed for critical machine protection, providing continuous monitoring of radial vibration, position, and thrust. It uses proximity transducers to measure gaps, converting them into actionable data via 3500 Rack Configuration Software to drive alarms for improved uptime.
-
3500/40M How does the Proximitor Monitor work?+It uses the eddy current principle to measure the distance between the probe tip and the shaft surface, converting it into voltage signals.
-
3500/40M How does the Proximitor Monitor work?+It uses the eddy current principle to measure the distance between the probe tip and the shaft surface, converting it into voltage signals.
-
What 3500/40M typical input/output specifications?+The monitor accepts input from proximity transducers and provides conditioned signals for monitoring, typically with a sensitivity of 7.87 mV/mil for some models.
