- Braun
- E1667.011
In Stock
Ships by Sunday, June 28
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for E1667.011
-
Product ModelE1667.011
-
Product ParametersProtection Monitoring Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size4x18.8x12.8cm
-
ManufacturerBraun
-
Weight0.45 kg
-
Operating Temperature-20°C to +70°C (-4°F to +158°F)
-
Storage Temperature-40°C to +85°C (-40°F to +185°F)
-
Humidity≤95% RH (non-condensing)
-
Relay Outputs2× SPDT relays (5 A, 250 V AC) for alarms/trip signals
-
Speed Range0–20,000 RPM
-
Frequency Input0.1 Hz to 10 kHz
-
Sensor Excitation8–24 V DC for powered probes
-
Analog Output4–20 mA or 0–10 V
-
Voltage24 V DC (±10%) or 100–240 V AC (±15%, 50/60 Hz).
-
Power Consumption≤15 W
Description
The E1667 is a Braun Protection Monitoring Module designed as part of the E16x346 protection system for overspeed protection and external trip release conditions in critical rotating machinery. The E1667 is certified by TÜV NORD for IEC 61508:2010 SIL3, DIN EN ISO 13849-1:2008 Cat.3 PL e, and IEC 62061:2005 SILCL 3, ensuring the highest level of safety integrity for demanding industrial applications.
The E1667 operates in a Triple Modular Redundancy (TMR) configuration with three independent monitors (A, B, C), where each monitor performs triple speed measurement and evaluation to ensure maximum safety and availability. The E1667 achieves a total response time to trip conditions of less than 15 milliseconds, providing rapid protection response for turbines, compressors, and other critical rotating equipment.
The E1667 features variable overspeed alarm settings that can be configured depending on acceleration, with monitoring versus low speed serving as protection against incorrect sensor mounting or sensor malfunction. The E1667 performs permanent monitoring of speed sensors and continuous self-testing of monitor functions, with cyclic full automatic tests or externally triggered tests via the Test-Generator E1697.
The E1667 operates in a Triple Modular Redundancy (TMR) configuration with three independent monitors (A, B, C), where each monitor performs triple speed measurement and evaluation to ensure maximum safety and availability. The E1667 achieves a total response time to trip conditions of less than 15 milliseconds, providing rapid protection response for turbines, compressors, and other critical rotating equipment.
The E1667 features variable overspeed alarm settings that can be configured depending on acceleration, with monitoring versus low speed serving as protection against incorrect sensor mounting or sensor malfunction. The E1667 performs permanent monitoring of speed sensors and continuous self-testing of monitor functions, with cyclic full automatic tests or externally triggered tests via the Test-Generator E1697.
Alternative Names
E1667-011
E1667-01I
E1667-0I1
E1667-O11
EI667-011
E1667.01I
E1667.0II
E1667.O1I
EI667.O1I
Information
Overview
Manuals
Application Notes
Product Applications
Operational Highlights
Features:
- 9pole Sub-D for PROFIBUS and RS232
- 5-digit display
- 4 LEDs for status indication
The E1667.011 BRAUN PROTECTION MONITORING MODULE may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
BRAUN E1667.011 PROTECTION MONITORING MODULE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Each Monitor receives the signal from the three sensors and calculates the speed from eachsignal. For the further evaluation it selects (depending on parameter settings) the calculatedspeed value derived of its own sensor or the median value of all three speed values.Speed calculation is done by measuring the time in between the pulses. The minimum measurement time is 5 milliseconds.To compensate for an imperfect gear, a predivider may be introduced to reduce the signal frequency to 1 pulse per revolution.
- Turbine Safety Systems:API 670 speed monitoring & ESD for steam/gas/hydro turbines
- Industrial Compressors & Pumps:Prevents overspeed failures in large centrifugal compressors/pumps
- Rotating Machinery Protection:Protects oil/gas, power & petrochemical critical equipment
- Safety Critical Systems:IEC 61508 SIL3 certified for safety management applications
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Speed Calculation: The module measures the time between pulses with a minimum measurement time of 5 milliseconds.
Fault Monitoring: It permanently monitors speed sensors for circuit faults and signal nonconformity.
Programming: Settings like setpoints (SP1, SP2, SP3) and sensor parameters are adjustable via specialized software or profibus interfaces in some versions.
Technical notes
Speed calculation is performed by measuring the time between pulses. The minimum measurement time is 5 milliseconds. To compensate for an imperfect gear, a predivider may be introduced to reduce the signal frequency to 1 pulse per revolution.
The E1667.011 is typically used as part of Braun E16x3 series protection systems. It works in conjunction with Braun A5S series speed sensors and other system components to provide comprehensive overspeed and rotational protection for critical machinery.
FAQs
-
What is the E1667.011?
+It is a component of a Braun overspeed protection system designed to monitor speed and trigger safety actions, often used in high-risk turbine applications. -
What is the response time?
+The trip release function in these systems is often fast, with a response time of less than 15 milliseconds. -
How do I troubleshoot Monitor Warning alarms?
+Warnings are often triggered by sensor deviations or internal nonconformities. For example, if the measured speed is lower than the starter condition set in step P02.06, a warning may be issued. -
What triggers a Sensor Circuit Fault?
+This alarm occurs if the system detects a failure in the supply or signal lead monitor. These settings are typically configured in steps P02.04 and P02.05 of the E1667 programming.
