Centum CS-Centum VP

Power Supply Module

Input Voltage: 100-120V or 200-240V
Output Voltage: 24V
Output Current :5A
Power Output: Up to 120W
Operating Temperature: -10°C to +55°C
Storage Temperature: -20°C to +70°C

Yokogawa Power Module

Central Processor

Current Voltage Input Module

Transceiver Control Module

CPU Module

Operation 0° to 55°C
Transportation/storage  40° to 85°C (*1)
Dust 0.3 mg/m3 or less
Resistance to corrosive gases
ANSI/ISA S71.04 Class G2 (Standard)
(ANSI/ISA S71.04 Class G3, option)
Resistance to vibration

RS-422/485 Communication Module

Digital Input Module

Processor Module

Processor Module

PROCESSOR MODULE
FOR AFV30S AFV30D AFV40S AFV40D
STANDARD TYPE
NO EXPLOSION PROTECTION
19 INCH RACK MOUNTABLE
REPLACES CP461-10 PROC MOD

16 Point Analog Input Module - HART

Bus Interface Module

Voltage Input Multiplexer Module

I/O Module

Bus Interface Module

Star type connection
Maximum two
5 km to 50 km
0.5 A

Bus Interface Module

Digital Output Module

8-channel, module isolation
24 V DC
1 V maximum
24 V DC, 3.4 A minimum
24 V DC + 20 % / -10 %
1.6 mA
0.2 A/output line (3.2 A in total output line) (*3) (*5)
120 to 685 Ω (*6
2 kV AC between output signal lines and system for 1 minute, 16-point input linescollectively connected (negative lines)

Digital Input Module

Number of inputs 16-channel, module isolation
Input current 6 mA ± 20 %
Contact rating 24 V DC +20 % / -10 %
External power supply 24 V DC +20 % / -10 %
Input response time 40 ms maximum
Withstand voltage (*1) (*2) 2 kV AC
between input signal and system for 1 minute
16-input line collectivelyconnected

Digital Input Module

Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum

Power Supply Module

Power Supply Module

Power Supply Module

Yokogawa Power Module

CPU Module

CPU Module

Processor Module

PROCESSOR MODULE
FOR AFV30S AFV30D AFV40S AFV40D
STANDARD TYPE
NO EXPLOSION PROTECTION
19 INCH RACK MOUNTABLE
REPLACES CP461-10 PROC MOD
