PR6423/010-040 CON021
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product image is representative; revision or series may vary. Contact us to request a specific version.
Product Information
Product Describe
PR6423/010-040 CON021
Eddy Current Sensor
2 mm (80 mils)
ISO: 8 V/mm (203.2 mV/mil) ± 5%@
temperature range 0 to 45°C(+32 to +113°F)
Eddy Current Sensor
2 mm (80 mils)
ISO: 8 V/mm (203.2 mV/mil) ± 5%@
temperature range 0 to 45°C(+32 to +113°F)
Technical specifications for PR6423/010-040 CON021
-
Product ModelPR6423/010-040 CON021
-
Spare ModelPR6423/010-040
-
Product Parameters8mm Eddy Current Sensor
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
Estimated Shipping Size26x21x4cm
-
ManufacturerEpro
-
Weight0.7 kg
-
Linear Measurement Range2 mm (80 mils)
-
Initial Air Gap0.5 mm (20 mils)
-
Incremental Scale Factor (ISF) ISO8 V/mm (203.2 mV/mil) ± 5%@ temperature range 0 to 45°C(+32 to +113°F)
-
Deviation from best fit straight line± 0.025 mm (± 1 mil)@ temperature range 0 to 45°C(+32 to +113°F)
-
Minimum Shaft Diameter25 mm (0.79”)
-
Sensor incl. 1m Cable-35 to +180°C (-31 to 356°F)
-
Cable & Connector-35 to +150°C (-31 to 302°F)
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the linear measurement range of the PR6423/010-040 CON021 8 mm Eddy Current Sensor?+The linear measurement range of the PR6423/010-040 CON021 is 2 mm (80 mils).
-
What is the initial air gap of the PR6423/010-040 CON021 sensor?+The initial air gap of the PR6423/010-040 CON021 is 0.5 mm (20 mils).
-
What is the maximum error (DSL) of the PR6423/010-040 CON021 deviating from the optimal straight line?+The error of the PR6423/010-040 CON021 deviating from the optimal straight line is ± 0.025 mm (± 1 mil).
-
What is the PR6423/010-040?+It is an 8mm Eddy Current Sensor/Probe, typically part of a sensor-converter assembly (often paired with the CON021 converter) manufactured by Emerson/Epro for machine protection and condition monitoring.
-
What is the PR6423/010-040 primary use?+It is used for contactless measurement of shaft displacement, vibration, and position in rotating machinery such as turbines, compressors, and pumps.
Get a quick price fo PR6423/010-040 CON021
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Mechanical Mounting
Features:
- 8mm Eddy Current Sensor
- Non-contact sensor
- High-Precision Displacement Measurement
The PR6423/010-040 Epro 8mm Eddy Current Sensor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
PR6423/010-040 8mm Eddy Current Sensor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Emerson EPRO PR6423/010-040 is an 8mm Eddy Current Sensor designed for high-precision, non-contact measurement of radial and axial shaft displacement, vibration, and position in rotating machinery (such as turbines, compressors, and pumps). The /040 designation typically signifies specific armor or connector configurations; some models are designed with armored cables for enhanced protection.
- Turbines: Steam, gas, and hydro turbines
- Compressors: Both centrifugal and axial types
- Pumps: Critical process pumps, including reactor coolant pumps
- Fans & Blowers: Large industrial draft fans and blowers
- Gearboxes: High-speed industrial gear units
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Determine Nominal Gap: The standard nominal gap for the PR6423 8mm sensor is approximately 1.5 mm (0.06 in).
Target Requirements: The target surface should be ferromagnetic steel (standard: 42 Cr Mo 4) and have a diameter of at least 25 mm (0.98 in) to minimize measurement errors.
Thread & Sleeve: Use the M10x1 or 3/8"-24-UNF threads to secure the sensor into the machine housing or bearing cap.
Locking: Once the air gap is set (verified by voltage output from the converter), use the lock nuts to secure the sensor in place
