General Electric

Base Expansion 10 Slots

Series:PACSystem RX3i
Product Type:Serial Expansion Backplane
Product Description:10-slot serial expansion baseplate
Number of Slots:10
Maximum Cable Length:50 Feet
Slot 1-10 assignment:I/O modules; Option modules
Front Mounting:Supported
P/S Slot:Power Supply Module

Power Supply 120/240 Vac 125 Vdc High Capacity

QuickPanel+ View Control, 7" Color TFT Widescreen with Multi-touch Projected Capacitive Screen, GE Monogram Bezel, 24 VDC Powered

6 channel Analog expansion. (4) Analog inputs & (2) Analog outputs. 120/240 VAC Power Supply (includes IC200CBL501)

PROFIBUS Slave Module

Series:RX3i PacSystem
Part Number:IC695PBS301
Product Line:RX3i
Catalog:IC695
Product Type:PROFIBUS Slave Module
Backplane Support:Universal
Number of Slots:1 (single slot)
Ports:9-pin connector
Backplane Compatibility:RX3i PCI

Drive Control Card

Series: Mark V
Operating Temperature: 0°C to +60°C.
Storage Temperature: -40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Control Functions:
Manages motor control processes.
Monitors system parameters such as voltage, current, and speed

Relay Output module

Series:Series 90-70
Manufacturer:GE Fanuc
Part number:IC697MDL940
Current draw:750 mA
Switching frequency:20 Cycles per minute
Response time:10 ms
Number of outputs:16
No. of groups:Two (2) Groups of Form A
No of Channels:Sixteen (16) Relay outputs
Required current:750 milliAmps
Minimum load:10 mA
Isolation voltage:1500 Volts

FEEDBACK I/O PACK

POWER DISTRIBUTION SYSTEM
FEEDBACK I/O PACK
PDM DIAGNOSTICS TYPE
FOR MARK VIE
TURBINE CONTROL SYSTEMS
AMBIENT TEMPERATURE:
-30 TO 65 DEGREES C

Mixed 24VDC POS LOG input group 16 point / output 24VDC 0.5 amp with ESCPoutput 16 point.

Output 24VDC POS LOGIC 0.5 amp per point(1 group of 16) with ESCP 16 points
