General Electric

Single Board Computer

Network: Dual Gigabit Ethernet ports.
USB: USB 2.0/3.0 ports for peripheral connectivity.
Serial: RS-232/422/485 interfaces.
Graphics: VGA, DVI, or DisplayPort for display output
Operating Temperature: -40°C to +85°C (ruggedized variants).
Certifications: MIL-STD-810 (shock/vibration), CE, RoHS.
Power Input: 5V or 12V DC

Bus Interface Unit

Series:Field Control
Manufacturer:GE Fanuc
Part Number:IC670GBI002D
Series:Field I/O control
Type:Bus interface unit
Part Number:IC670GBI002
CPU Redundancy:Supported
Supply Voltage range:18-30 VDC
Nominal supply voltage:24 VDC
Frequency:47 to 63 Hertz
Power consumption:16.8 Watts
Power Supply Output:6.5 VDC ±5%

CPU module

Series:RX3i PacSystem
Part Number:IC695CPE330-AFAT
Product Type:CPU module
Processor Clock Speed:1.0 Ghz
RAM:64 MB
NVRAM:64MB
I/O Points:up to 32 K I/O
Controller Redundancy:Supported
Maximum Program Blocks:512
Maximum Block Size:128 kilobytes

I/O PACK

I/O PACK
SPEEDTRONIC GAS TURBINE CONTROL
MARK VI SERIES
TURBINE INPUT / OUTPUT
PRIMARY TURBINE PROTECTION
REGULATES HRSG (BOILER)

PROFINET Controller Gateway Module

Series:Mark VIe/Mark VIeS
Product Type:PROFINET Gateway Module
Processor Type:1066 MHz EP80579 Intel
Operating Temperature:22 to 149°F
Manufacturer:General Electric

op Box A Module Board

Series: Mark VIe
Channels: Configurable for 16–32 analog/digital channels
Analog: 4–20 mA, 0–10 V, RTD
Digital: 24 VDC dry/wet contacts
Supply Voltage: 24 VDC nominal
Power Consumption: Typically ≤ 8 W
Operating Temperature: -40°C to +70°C (-40°F to +158°F)

Top Box B Module

Series: Mark VI
Supply Voltage: Typically 24 VDC
Power Consumption: Varies by load
Operating Temperature: -40°C to +70°C
Humidity: 0–95% non-condensing

Analog Input Module

Series:Versamax
Part Number:IC200ALG263
Product Description :Analog Input Module
Number of Inputs:15, single-ended
Input Voltage:-10 Volts to 10 Volts
Input Impedance:100K Ohms minimum
Resolution:+/- 15 bits
Update Rate:7.5 ms
LED Indicators:OK LED

Input Terminal Board

Series: Mark VI
Model Number: IS200AEADH4ADA
Type: Input Terminal Board
Input Voltage:
Typically operates at 24V DC
Operating Temperature Range:
-40°C to +85°C (-40°F to +185°F)

CIRCUIT BOARD

Input Voltage:
Typically operates at 24V DC
Operating Temperature Range:
-40°C to +85°C (-40°F to +185°F)
Serial Communication: RS-232/RS-485

Printed circuit board

Input Voltage: Typically 24 V DC
Operating Temperature Range:
Typically -30°C to +70°C (-22°F to 158°F)
Storage Temperature Range:
 -40°C to +85°C (-40°F to 185°F)

Digital Input Module

DIGITAL INPUT MODULE
24VDC
SOURCE
64 POINT

Vibration Monitor I/O Pack

Ambient Temperature Range:-30 to 65 °C
Board Compatibility:Vibration Terminal Board (TVBA)
Channels Thirteen for Proximity and Vibration
Common Mode Voltage Min:5 VDC
Frame Rates:3.125, 6.25, 12.5, 25, 50, and 100 Hz
Functional Acronym/Abbreviation:PVIB
LED Indicators:4
Probe Power:-24 VDC, 12 mA load per transducer
Status LEDs:Attn, Pwr, Link, TxRx

Analog input module

Series:PACSystem RX7i
Module Type:Analog Input
Number of Inputs:8 single-ended or 4 differential input channels
Input signals, Current:0-20 mA; 4-20 mA; +/-20 mA;
Product Description Analog input module
Current Range:0-20 mA, 4-20 mA, +/-20 mA

Processor-based VME (VMEbus) single board computer

Up to 512MB PC133 SDRAM
Built-in SVGA support with 4 Mbytes DRAM display cache
Built-in dual 10/100 Mbit Ethernet
IDE drive support
Floppy drive support
Two RS232 serial ports
Dual USB ports
Real-Time clock/calendar
Front panel reset switch
Miniature speaker
Keyboard/Mouse port

PROFIBUS INTERFACE CARD

PROFIBUS INTERFACE CARD
1 PORT CHANNEL
Operating Temperature Range: -40°C to +70°C.
Power Consumption: Maximum of 5W
Data Transfer Rate: Up to 400 Mbps
Digital I/O Channels: Provides 32 digital

Digital Signal Processor Board

CONTROL BOARD
DIGITAL SIGNAL PROCESSOR
60 MHZ
MARK VI
Clock Frequency:Up to 200 MHz
Program Memory:512 KB Flash
Input Voltage:Typically 12 V DC
Power Consumption:Approximately 3–5 W

DeviceNet Master Module

Series:PACSystem RX3i
Product Description:DeviceNet Master Module
Part Number:IC694DNM200
Communication protocol:DeviceNet
Maximum Number of Slave Devices Supported:63
No. of supported DeviceNet slave:63
Slave Operation:Supported
Input data:255 Bytes
Communication Rates:125k, 250k, or 500k bauds
Output data:255 Bytes

Control Memory Xchange Module

Data Transmission Rate: 2.12 Gbaud
Reflective Memory Capacity: 16 MB SDRAM
Access Time: 200 to 400 nanoseconds
Node Capacity: Supports up to 256 nodes in a network
Connectors: Fiber optic LC type, conforming to IEC 61754-20
Operating Voltage: +5 VDC (from power supply)
Current Requirements: 1.8 Amperes

Emergency Turbine Protection I/O Pack

Input Voltage Range: 85–264 V AC
Output Voltage: 24 V DC
Output Current: 10 A
Efficiency: 88%
Operating Temperature Range: -40°C to +70°C
Storage Temperature Range: -40°C to +85°C
Humidity Range: 5% to 95% non-condensing
Power Consumption: Approximately 25 W

PROTECTION RELAY

Ambient Humidity Maximum:Up to 95% non condensing
Dimensions:approx: 11.5 in H x 5.5 in W x 8.5 in L
Display Version:Enhanced
Fuse:3.15 A H 250 V
Input Power:110-250VDC 100-240VAC
Manufacturer:GE Multilin
Model Number:369-HI-R-M-0-0-0-E
Phase Current Input:1 A and 5 A secondary

Reflective Memory interface Module

Memory Size:8 MB, 16 MB, or 32 MB
Data Transfer Rate:Up to 43 MB/s
Node Support:Supports up to 256 nodes
Connectors:
ST-style fiber-optic connectors
Power Requirements:+5 VDC
Storage Temperature:-40°C to +85°C
Operating Temperature:0°C to +60°C

Safety Controller Module

Microprocessor: 1066 MHz Intel EP80579
Operating System: QNX Neutrino
Operating voltage: 24 VDC
Operating Temperature: -10°C to +60°C.
Storage Temperature: -40°C to +85°C
Memory:4GB to 16GB RAM
Modbus TCP/IP, Profibus DP

UCSB Controller Module

Operating voltage: 24 VDC
Operating Temperature: -10°C to +60°C.
Storage Temperature: -40°C to +85°C
Memory:4GB to 16GB RAM
Modbus TCP/IP, Profibus DP
