General Electric

RXi Controller

RXI CONTROLLER / PACSYSTEMS
HIGH PERFORMANCE DISTRIBUTED IO
PROGRAMMABLE
REQUIRES ICRXIACCIDM001A

Common Analog I/O Board

Series: Mark V
Product Type: Terminal Board
Input Channels: 8 Analog Inputs
Input Resolution: 12-bit / 16-bit
Output Type: Voltage (0-10V, ±10V)
Output Resolution: 12-bit / 16-bit
Input Type: Voltage (0-10V, ±10V)
Communication Protocol: RS-485
Power Supply: 24V DC ±10%, < 5W
Isolation: 1500V

TRIP CONTROL CARD

TRIP CONTROL CARD
PC BOARD SDCC MARK V SYSTEM
PC BOARD
TRIP MODULE

DOS DUP Processor Board

PC BOARD
MARK 5 SERIES
TURBINE AND GAS CONTROL BOARD
WITH ON-BOARD MEMORY
MULTI-INPUT/OUTPUT

Power Connect Card

Series: EX2000
Microprocessor: Intel Ultra Low Voltage Celeron 650 MHz
Operating System: QNX Neutrino
Operating Temperature: 0 to 60°C
Product Type: Power Connector
Analog Input current: 240 V rms
DC Bus Voltage: 125 VDC
Auxiliary Voltage: +15 VDC

static-sensitive board

Processor:Triple 32-bit RISC processors
I/O Channels :16 digital inputs
Trip Outputs:4 relay outputs
Communication:Ethernet RSTP
Response Time:<15 ms
Power Supply:+24V DC (±10%), 2A

Single Board Computer

VME-7807 Series
SINGLE PCB BOARD
PROCESSOR: 1.8GHZ PENTIUM M DDR
SDRAM: 1 GB L2 CACHE: 2MB
FLASH: 512 KB 1101.10
FRONT PANELSCAN DISK 2GBITES

Vibration Input Terminal Board

Series:Mark VIe Speedtronic
Part Number:IS200TVBAH2A
Functional Acronym:TVBA
Functional Description:Vibration Input Terminal Board
PCB Coating:Conformal Coating
Functional Revision 1:B

RX3I PROFINET SCANNER MODULE

RX3I PROFINET SCANNER MODULE
10/100/1000 WITH FOUR PORTS
1.2AMP @ 3.3VDC
1.1AMP @ 5 VDC
SINGLE SLOT

Terminal block

I/O BASE
BARRIER STYLE
2 TIER BOX TERMINAL

Terminal block

I/O BASE
BARRIER STYLE
2 TIER BOX TERMINAL

Thermocouple Input Module

ANALOG INPUT MODULE
THERMOCOUPLE
8POINT
INDEPENDENT THERMOCOUPLE OR MULTIVOLT INPUTS
50/60HZ

small form-factor pluggable scanner module

Type:Scanner module
Speed:100 Mbps
Material:Multi-mode fiber (MMF)
Length:2 Kilometers
SD Card:Supported
Power:3.3 to 5 Volts
Port Connectors:Two RJ-45 and two SFP cages.
LED Indicators:Yes

Terminal board

Series: GE Mark VIe Series
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤8 W
Voltage Range:0–30 V DC or 0–120 V AC
Range: 0–10 V DC, 4–20 mA
Resolution: 16-bit ADC
Type: Form-C contact relays (1 A at 30 V DC)
Operating Temperature: -40°C to +70°C
Relative Humidity: 5–95% (non-condensing)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Input: 24 V DC (±10%)
Isolation: ≥1.5 kV
Digital Inputs:0–30 V DC
Analog Resolution:16-bit ADC
Operating Temperature: -40°C to +70°C
Shock/Vibration: to 5 G (5–500 Hz)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Terminal Capacity: ≤32 AWG
Input Voltage: 24 V DC (±10%)
Power Consumption: <5 W
Galvanic Isolation: Up to 1.5 kV AC/DC
Voltage Range for Inputs: 0–120 V AC/DC
Digital Inputs (DI):30 V DC/120 V AC
Operating: -40°C to +70°C
Storage: -40°C to +85°C
Humidity Tolerance: 5–95% non-condensing

Turbine Emergency Trip Board

Series: GE Mark VIe
Dual Power Inputs: Isolated 24 V DC
Fail-safe relay contact rating: 2 A at 24 V DC
Input Voltage: 24 V DC (±10%)
Temperature Range: -40°C to +70°C (continuous operation)
Surge Protection: TVS diodes/SRC filters on I/O channels
Relative Humidity: 5–95% (non-condensing)

RTD Input terminal board

Operating Voltage:24 V DC ±10%
Power Consumption: <10 W
Types: 2-wire, 3-wire
Number of Inputs: 8 channels
Excitation Current:1 mA
Measurement Resolution: ≤0.1°C

Relay Output Terminal Board

Series: Mark VIe
Product Type: Relay Output Terminal Board
Number of channels: 16
Relay Type: SPDT
Relay Contact Rating: 10A
Input Voltage Range: 12V, 24V
Number of Relay Channels: 4, 8
Relay Switching Current: Max 10A
Mounting Type: DIN rail
Output Resolution: 12-bit
Output Impedance: 10 Ohm
Analog outputs: 0-20 mA

Vibration terminal board

Series: GE Mark VIe
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
Proximity Probes: 0–10 kHz
Accelerometers: Up to 20 kHz
IEPE sensor excitation:typically 18–24 V DC
Analog input: ±10 V peak
Operating Temperature: -40°C to +70°C.
Humidity Tolerance: 5–95% (non-condensing)

Transient Data Interface Module

Input Voltage: 24 V DC (±10%)
Power Consumption: Typically <20 W
Sampling Rate:Up to 25.6 kS/s
Voltage ranges (analog): Typically ±10 V DC
Analog Input: 16-bit
Operating Temperature: -40°C to +70°C
Storage Temperature: -40°C to +85°C.
Relative Humidity: 5%–95% (non-condensing)

SERVO AMPLIFIER MODULE

A06B6290H106
SERVO DRIVE
SERVO AMP
SERVO AMPLIFIER MODULE AISV 180HV
SERVO DRIVE MODULE AISV 180HV-B
FOR 30I-B SERIES
CNC

I/O Pack processor board

Processor Type:Mark VI
Backplane Power: +5 VDC
Analog: ±10 V, 4–20 mA
Digital: 24 V DC
Processing Speed: 100–200 MHz
Non-Volatile Memory (Flash):16–64 MB

CPU RAM backup battery

AUXILARY BATTERY MODULE
15.0 AMP-HOURS
COMPATIBLE WITH ALL BATTERY
CONNECTORS ON IC693 POWER SUPPLIES
MEMORY BACKUP BATTERY

Ethernet network interface unit

RX3I NIU WITH TWO SERIAL PORTS
20K OF LOCAL LOGIC
MODULE REQUIRES UNIVERSAL BASE (IC695CHSXXX)
REQUIRES ETHERNET MODULE (IC695ETM001)
NIU SUPPORTS ALL RX3I I/O MODULES
