PRODUCT DESCRIPTION
Thermal conductivity gas transmitter
XMTC-62-11-0 is listed within the Panametrics XMTC thermal-conductivity gas-transmitter family. The manufacturer describes XMTC instruments as measuring constituent concentration in binary or pseudobinary gas mixtures. The exact calibration, measuring-cell package and suffix configuration of this ordering reference have not been independently established.
The retained XMTC family datasheet explains the measurement principle, sample-system requirements and available configurations. Before selecting a spare, confirm the gas mixture, concentration range, reference-gas arrangement and nameplate approvals. A suitable sample system is mandatory, and family options must not be assumed to be fitted to this unit.
The retained XMTC family datasheet explains the measurement principle, sample-system requirements and available configurations. Before selecting a spare, confirm the gas mixture, concentration range, reference-gas arrangement and nameplate approvals. A suitable sample system is mandatory, and family options must not be assumed to be fitted to this unit.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Application context for XMTC-62-11-0
XMTC-62-11-0 is a Thermal conductivity gas transmitter for compatible Fanuc CNC systems. Its application context includes chemical and petrochemical, oil and gas, metals. Suitability depends on the complete part number, equipment revision, electrical interfaces and documented configuration.
-
01 · CHEMICAL & PETROCHEMICAL
Industrial Chemical and Petrochemical Production
Industrial Chemical ProductionPetrochemical Production and Processing -
02 · OIL & GAS
Oil Extraction and Natural Gas Processing
Oil Exploration and ProductionNatural Gas Processing -
03 · METALS
Primary Metal Production and Metalworking
Iron and Steel ProductionNonferrous Metal Processing
Technical specifications for XMTC-62-11-0
-
Product ModelXMTC-62-11-0
-
Product ParametersThermal conductivity gas transmitter
-
In stock1 unit
-
ManufacturerGeneral Electric
-
Measurement principleThermal conductivity using glass-coated thermistors (XMTC family)
-
Mixture requirementBinary or pseudobinary gas composition totaling 100% (family)
-
Family accuracy+/-2% of span
-
Family linearity+/-1% of span
-
Family repeatability+/-0.5% of span
-
Zero stability+/-0.5% of span per week (family)
-
Span stability+/-0.5% of span per week (family)
-
Response time20 seconds for 90% step change (family)
-
Analog outputIsolated 4-20 mA, field-programmable (family)
-
Maximum output load800 ohms (family)
-
Power specification24 VDC +/-2 VDC; 1.2 A maximum in family specification table
-
Nominal sample flow250 cc/min in standard family sample-system example
-
Sample-system requirementMandatory; clean representative sample within applicable limits
View all additional
Alternative Names
XMTC-62-11-0 Panametrics Transmitter
XMTC-62-11-0 Thermal Conductivity Analyzer
XMTC-62-11-0 Binary Gas Transmitter
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
THERMAL CONDUCTIVITY GAS TRANSMITTER
Match the calibration and mandatory sample system
The XMTC family uses heated glass-coated thermistors to compare sample and reference gas thermal conductivity. The resulting signal represents a constituent concentration in a binary or pseudobinary mixture. The complete gas composition must be appropriate for this measurement method; an unspecified multicomponent stream is not automatically suitable.
BHCS38653 states that a sample system is mandatory and must deliver a clean, representative sample within the permitted temperature, pressure and flow limits. Its standard example uses a sample below 50 degrees C with a 55-degree-C measuring cell, approximately 250 cc/min flow and atmospheric pressure. Verify which temperature option and sample conditions apply to the installed unit.
The family datasheet offers two-port sealed-reference and four-port flowing-reference arrangements, different cell packages and several gas calibrations. The supplied XMTC-62-11-0 suffix has not been conclusively mapped to that ordering scheme. Confirm its label and calibration documentation before deciding on materials, port arrangement, hazardous-area suitability or connections.
Features:
- Verify the complete gas mixture and calibrated range
- Provide the documented sample-conditioning system
- Confirm the installed cell, ports and approvals
The XMTC-62-11-0 gas transmitter requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Match XMTC-62-11-0 against the installed transmitter's nameplate and calibration records. Replacing an XMTC solely by its family name can overlook differences in gas range, cell construction, reference-gas arrangement, materials or temperature set point.
The manufacturer describes a plug-in measuring cell and field calibration for the family. This does not approve every spare cell for every transmitter. Verify the applicable cell and calibration instructions, and confirm the offered accessory scope before maintenance.
No exact-order discontinuation date or designated successor was verified. The retained 2023 family datasheet is not a lifecycle announcement, and it does not establish a fully interchangeable newer ordering number for this specific configuration.
Features:
- Compare gas calibration and reference arrangement
- Check measuring-cell and materials compatibility
- Require exact-order evidence for any successor
The XMTC-62-11-0 gas transmitter requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the XMTC-62-11-0 gas transmitter must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed sizePacking dimensions require confirmation
-
Shipping weightShipping weight requires confirmation
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8537101190
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about XMTC-62-11-0
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Which gas range is configured in XMTC-62-11-0?
The exact calibration has not been verified. Check the unit's calibration label and records; the family datasheet's available gas ranges are options, not proof of the configuration supplied. -
Can an XMTC be used without a sample system?
No. Panametrics states that a sample system is mandatory and must deliver a clean, representative sample within the acceptable temperature, pressure and flow limits. -
What is the difference between sealed and flowing reference arrangements?
The family offers a two-port version using sealed reference gas and a four-port version using a specific flowing reference gas. Confirm which measuring-cell package is installed rather than assuming either arrangement from the family name. -
Does the family provide a 4-20 mA output?
Yes. The specification lists an isolated, field-programmable 4-20 mA output with an 800-ohm maximum load. Confirm the installed configuration and follow its applicable wiring instructions. -
Can it measure an arbitrary multicomponent gas stream?
The datasheet describes binary or pseudobinary mixtures and states that the composition must total 100%. The complete gas mixture and calibration must be assessed for suitability; the instrument should not be assumed suitable for any unspecified multicomponent stream. -
Are explosion-proof approvals confirmed for this exact order?
The family includes different enclosure and approval options. No exact-order approval was established here, so verify the actual nameplate, certificate and installation conditions before hazardous-area use. -
Can the measuring cell be replaced separately?
Panametrics describes a replaceable plug-in measuring cell for the XMTC family. The correct cell, calibration and maintenance instructions still need to be matched to the installed transmitter; this is not universal spare-cell interchangeability approval.
