Technical specifications for IC693CHS398
-
Product ModelIC693CHS398
-
Product Parameters5 SLOT EXPANSION BASE PLATE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size26.4x13x2cm
-
ManufacturerGeneral Electric
-
Weight0.55 kg
-
Number of I/O points2048
-
Processor speed133 Megahertz
-
Register memory240 kilobytes
-
Power requirements7.4 Watts at 5 Volts DC
-
Number of Ethernet ports2
Description
IC693CHS398
5 SLOT EXPANSION BASE PLATE
SERIES 90-30
25-PIN FEMALE D-TYPE I/O BUS EXPANSION CONNECTOR
CANNOT STAND ALONE
MUST BE CONNECTED TO A SYSTEM WITH A CPU
5 SLOT EXPANSION BASE PLATE
SERIES 90-30
25-PIN FEMALE D-TYPE I/O BUS EXPANSION CONNECTOR
CANNOT STAND ALONE
MUST BE CONNECTED TO A SYSTEM WITH A CPU
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Electrical and Signal Protection
Installation Instructions
Features:
- 5-slot Expansion Baseplate
- Series 90-30
- Single slot CPU module with embedded Ethernet Interface
The IC693CHS398 GE 5 SLOT EXPANSION BASE PLATE may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IC693CHS398 5 SLOT EXPANSION BASE PLATE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The IC693CPU374 is a GE Fanuc Programmable Logic Controller (PLC) module from the 90-30 series. This module is a processor module that is used to host the user program, execute the logic and managed data exchanges to and from the processor via the embedded communication ports.
The IC693CPU374 may also be referred to as a controller. This controller has built-in microprocessor with embedded 586 processor with processing speed of 133 MHz. It has a typical scan rate of 0.15 miliseconds per 1K Boolean contact logic. This controller module has a single slot width that is installed to the 90-30 PLC rack.
- Water treatment and environmental protection: Control of water treatment plant pump stations and water quality monitoring systems.
- Food and beverage processing: Packaging machines, filling lines, and material conveying systems in food processing plants.
- Electricity and energy: Auxiliary equipment for small power plants and substations in power plants.
- Building automation: HVAC, lighting control, and elevator monitoring systems for managing large commercial buildings.
- Light industry manufacturing: Automation control of textile machinery, printing equipment, and injection molding machines.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The IC693CHS398 is engineered with several layers of defense against electrical interference and environmental hazards common in industrial settings:
Noise Immunity and EMI/RFI Shielding: The unit is designed for electrically harsh conditions, featuring resistance to electromagnetic and radio frequency interference. According to Alibaba, it uses Transient Voltage Suppression (TVS) to protect against voltage spikes from lightning or switching surges and includes common-mode chokes to eliminate unwanted differential signals.
Common Grounding Requirement: For system safety and signal stability, all expansion baseplates must be connected to a common ground. This prevents ground loops and ensures that shields can safely divert electrical noise away from signal wires.
The IC693CHS398 is a 5-slot expansion baseplate for the GE Fanuc Series 90-30 PLC system. Its instructional protection guidelines focus on maintaining system stability, electrical grounding, and safe operation in hazardous environments.
Slot Population Protection: All unused slots in the baseplate must be populated with filler modules (model IC693ACC310) or equivalents to maintain proper airflow and protect internal circuitry from debris.
Cabling Limitations: To ensure signal integrity, the total length of interconnecting cables between the CPU baseplate and all expansion baseplates must not exceed 50 feet (15 meters).
- What happens next
- Get the quote now Write Email to INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and payment
- Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
FAQs
-
What is IC693CHS398？
+The GE Fanuc IC693CHS398 is a 5-slot expansion baseplate used in the Series 90-30 Programmable Logic Controller (PLC) system -
Does IC693CHS398 come with a power supply?
+No, a separate power supply module must be installed. -
What is the IC693CHS398 load current?
+170 mA at 5VDC -
What is the capacity of the IC693CHS398?
+It contains 5 I/O slots for various modules. -
What is the IC693CHS398 maximum cable distance allowed?
+The total length of interconnecting cables between the CPU baseplate and expansion baseplates cannot exceed 50 feet (15 meters).
