Technical specifications for IC660BBA021
-
Product ModelIC660BBA021
-
Product ParametersRTD Input Block
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size22.3x8.5x10cm
-
ManufacturerGeneral Electric
-
Weight1.45 kg
-
LEDs (I/O Block)Unit OK, I/O Enabled
-
Block to Block Isolation1500V
-
Group to Group Isolation300V
-
Heat Dissipation7W maximum
-
Block Power105-145 VDC10% max. ripple
-
Power supply dropout time10ms
-
Input resolution0.1° C
-
Input update frequency Once every400ms, 800ms, or 1600ms
-
Input filter ranges (per block)400ms, 800ms, 1600ms
-
Resistance measurementrange0 to 5000 Ohms
Description
I/O MODULE
GENIUS BLOCK
RTD INPUT BLOCK
6 CHANNELS
24/48 VDC POWER
3 GROUPS OF 2 CIRCUITS EACH
GENIUS BLOCK
RTD INPUT BLOCK
6 CHANNELS
24/48 VDC POWER
3 GROUPS OF 2 CIRCUITS EACH
Information
Overview
Manuals
Technical notes
Product Applications
Wiring Instructions
Features:
- Alarm thresholds
- RTD resistance
- Linearization
- Alpha type
- Input filter time
An RTD Input block has six input circuits, in three groups of twocircuits each. Group to group isolation is 300 volts. Each input canbe used with platinum, nickel, or copper RTDs. Input data for eachcircuit is linearized according to the type of RTD selected. Inputdata is reported to the CPU in engineering units of tenths of degreesCelsius, tenths of degrees Fahrenheit, tenths of Ohms, or counts.
The IC660BBA021 GE RTD Input Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IC660BBA021 RTD Input Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Genius I/O blocks are considered "open equipment" and thereforemust be installed within a protective enclosure. They should belocated in an area that is clean and free of airborne contaminants.There should be adequate cooling airflow.The block can be mounted right side up, or upside down. Leave atleast 2 inches of space between blocks. Mount the block by drillingtwo screw or bolt holes for 8-32 hardware. Position the block so thatthe notches in the upper and lower flanges line up with the mountingholes. Mount the block using 8-32 screws. Use star washers toprovide ground integrity
- Automotive Manufacturing:Monitors machinery temps on assembly lines & paint shops
- Steel & Mining Operations:1500V isolation for motor/bearing temp tracking in harsh environments
- Water Treatment:Processes flow & temp signals for large-scale utilities
- Large-Scale Climate Control:Monitors & controls complex HVAC systems
- Energy Acquisition:Collects temp data to optimize industrial plant efficiency
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Block Power: Connect 24/48 VDC power to terminals 6 (DC+) and 7 (DC-).
Grounding: Connect the green ground screw to a reliable system ground using a minimum AWG #12 wire.
Serial Bus: Terminals 1–4 are for the Genius serial bus (Serial 1, Serial 2, Shield In, and Shield Out).
Field Sensors (RTDs):
The block has 6 input channels grouped in three rows.
Terminal Pairs: Channel 1 uses terminals 13/14, Channel 2 uses 15/16, etc..
Shielding: Use twisted-pair shielded cables and ground the shield at the block end only to avoid ground loops
FAQs
-
What is IC660BBA021 ?
+The GE Fanuc IC660BBA021 is a 6-Channel 24/48VDC Resistance Temperature Detector (RTD) Input Block from the Genius I/O series. -
What type of sensors are compatible with this block?
+The block is compatible with Platinum, Nickel, or Copper RTDs, and can receive 0-5000 Ohms input signals. -
What is the required power supply voltage for IC660BBA021?
+This module uses a 24/48V DC external power supply. -
How does this differ from the IC660BBA101?
+Both are 6-channel RTD blocks, but the IC660BBA021 is designed for 24/48V DC, while the IC660BBA101 is designed for 115V AC/125V DC. .
