Technical specifications for FC-MCAR-02
-
Product ModelFC-MCAR-02
-
Product ParametersMounting Carrier (36 inch)
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size92.4x22.8x10.5cm
-
ManufacturerHoneywell
-
Weight5.95 kg
-
Operating temperature-40 .. +70 degC (-40 .. +158 degF)
-
Storage temperature-40 .. +85 degC (-40 .. +185 degF)
-
Relative humidity10..95% (non condensing)
-
Supply voltage24 Vdc -15%..+30%
-
Supply currentnone
-
Supply rail currentmax. 40 A
Description
The FC-MCAR-02 is a Honeywell Mounting Carrier (36 inch) designed for installation in Safety Manager systems. The FC-MCAR-02 is a carrier that can be screwed on any flat surface and can carry two IOTA-R24 assemblies. The FC-MCAR-02 consists of a Cable Carrier Assembly (CCA), a metal profile, two plastic cover plates, a ground rail with 32 ground connection screws, and two power rails with M5 holes (+24V and 0V).
The FC-MCAR-02 features four mounting holes for screws with a diameter less than 5.5 mm. The FC-MCAR-02 allows power rails of two carriers to be coupled using two M5 screws to connect the power rails of the top carrier with the bottom carrier through the 5 mm holes. An IOTA-R24 is fixed on the FC-MCAR-02 with ten ground screws and two power screws (24V and COM), and 24Vdc power must be connected to the FC-MCAR-02 on the power rails using M5 screws. Up to three IOTA-NR24 units can be fixed on the FC-MCAR-02with eight ground screws and two power screws (24V and COM) each, with 24Vdc power connected to the power rails using M5 screws.
The FC-MCAR-02 features four mounting holes for screws with a diameter less than 5.5 mm. The FC-MCAR-02 allows power rails of two carriers to be coupled using two M5 screws to connect the power rails of the top carrier with the bottom carrier through the 5 mm holes. An IOTA-R24 is fixed on the FC-MCAR-02 with ten ground screws and two power screws (24V and COM), and 24Vdc power must be connected to the FC-MCAR-02 on the power rails using M5 screws. Up to three IOTA-NR24 units can be fixed on the FC-MCAR-02with eight ground screws and two power screws (24V and COM) each, with 24Vdc power connected to the power rails using M5 screws.
Information
Overview
Manuals
Application Notes
Product Applications
Mechanical Mounting
Features:
- Cable Carrier Assembly (CCA)
- metal profile
- two plastic cover plates
- a ground rail with 32 ground connection screws
- two power rails with M5 holes (+24V and 0V)
The carrier features ten ground screws for secure grounding of mounted IOTA modules and two power screws (24V and COM) for distributing 24 Vdc power to the connected modules via internal power rails. The 36-inch length accommodates multiple IOTA assemblies mounted side-by-side in a standard industrial control cabinet.
The FC-MCAR-02 is constructed from metal (aluminum or steel) for durability and electromagnetic compatibility. It supports DIN rail or direct panel mounting. Each mounted IOTA module can be fused up to 15 A for overcurrent protection.
The FC-MCAR-02 Honeywell Mounting Carrier (36 inch) may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell FC-MCAR-02 Mounting Carrier (36 inch) Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The assembly is capable of accommodating two FC-IOTA-R24 Redundant I/O Termination Assemblies, creating a compact and organized installation platform for safety-related field wiring and remote I/O equipment. Integrated power rails distribute 24 VDC system power, while the ground rail offers 32 grounding connection points for field and system wiring.
- Oil & Gas: Used in upstream and downstream facilities to manage safety instrumented systems
- Petrochemical & Chemical: Integrates remote I/O for hazardous processing environments requiring failsafe controls
- Power Generation: Manages critical safety loops and remote sensor data across plant turbines and boilers
- Process Automation: Serves as the backbone for distributed and remote sensor signal processing across continuous manufacturing
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Positioning: The FC-MCAR-02 is designed for back-panel or rack mounting within a standard industrial enclosure.
Fastening: Use the provided mounting points and corrosion-resistant hardware to securely screw the carrier onto any flat surface (such as a sub-panel in a cabinet).
Grounding: Secure a heavy-duty ground strap from the carrier's grounding lug to the main enclosure Earth ground to protect against electromagnetic interference (EMI) and electrical faults.
Alternative Names
FC-MCAR-O2
FC-MC4R-02
FC MCAR 02
FC MCAR O2
FCMCAR02
FCMCARO2
Technical notes
The FC-MCAR-02 operates in temperatures from -40°C to +70°C (-40°F to +158°F) and can be stored in temperatures from -40°C to +85°C (-40°F to +185°F). The FC-MCAR-02 is rated for relative humidity of 10% to 95% non-condensing and pollution degree 2 or better. The FC-MCAR-02 is approved to CE and UL pending standards. The FC-MCAR-02 operates with a supply voltage of 24 V DC with a range of -15% to +30%, with no supply current consumption by the carrier itself.
FAQs
-
What is the function of the Honeywell FC-MCAR-02?
+It is a mounting carrier designed to house and organize equipment within industrial automation systems, specifically to hold up to 18 SM RIO modules. -
Is this product brand new?
+Yes, Honeywell FC-MCAR-02 is brand new, original, unused, and factory sealed -
Which specific hardware does it support?
+It is primarily utilized to mount redundant (IOTA-R24) or non-redundant (IOTA-NR24) modules used in Honeywell Safety Manager systems. -
What are the input power and rating constraints?
+It operates on a nominal 24 VDC supply and can handle high-density distribution paths rated up to 40A.
