The Honeywell TC-IAH161 is a 16-channel High Level Analog Input Module for the Honeywell Series C I/O platform. The TC-IAH161 accepts multiple industry-standard analog signal types, including 0–20 mA, 4–20 mA, ±10 V, 0–10 V, 1–5 V, and 0–5 V, allowing the module to interface with a wide variety of transmitters, sensors, and field instruments. Each input channel can be individually configured to match the connected device, providing flexible integration within industrial process control systems.
The TC-IAH161 utilizes 16-bit analog-to-digital conversion to provide high-resolution measurement of process variables. According to the datasheet, all sixteen channels are scanned with a 25 ms module update period, enabling fast acquisition of analog signals while maintaining measurement accuracy. The module is intended for continuous monitoring of process parameters such as pressure, temperature, flow, level, and other analog measurements used by Honeywell control systems.
The TC-IAH161 utilizes 16-bit analog-to-digital conversion to provide high-resolution measurement of process variables. According to the datasheet, all sixteen channels are scanned with a 25 ms module update period, enabling fast acquisition of analog signals while maintaining measurement accuracy. The module is intended for continuous monitoring of process parameters such as pressure, temperature, flow, level, and other analog measurements used by Honeywell control systems.
Technical specifications for TC-IAH161
-
Product ModelTC-IAH161
-
Product ParametersHigh Level Analog Input Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size3.5x14.2x14.5cm
-
ManufacturerHoneywell
-
Weight0.2 kg
-
Channels16 single-ended
-
Voltage0-5V, 0-10V, ±5V, ±10V
-
Current0-20mA, 4-20mA
-
Resolution16-bit ADC
-
Power Supply24V DC ±10% (typical)
-
RFI ImmunityError of less than 2.0% of range at 10 V/m,27 to 1000 MHz
-
Channel Bandwidth20 Hz(-3dB)
-
Module Publish Rate250 msec
View all additional
Alternative Names
TC-IAH16I
TC IAH161
Technical notes
The TC-IAH161 provides 2550 VDC user-to-system isolation, with each module 100% tested for one second. This isolation separates field wiring from the system electronics, improving protection against electrical disturbances and supporting reliable signal acquisition in industrial environments. The module connects to field devices through the Honeywell TC-TBNH terminal block, providing a standardized wiring interface for installation and maintenance.
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
Overview
Manuals
Technical notes
Product Applications
Electrical & Environmental Protection
Features:
- High Level Analog
- 16-Input
- Voltage and Current (10 V & 4-20 mA)
The TC-IAH161 Honeywell Analog input module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell TC-IAH161 Analog input module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The TC-IAH161 features 16 isolated, high-resolution (16-bit) analog input channels supporting both voltage and current signals. It operates with a 250 ms response time, offers 2550 VDC isolation, and has a 4.1 W maximum power dissipation. The module utilizes a 36-position (TC-TBCH) terminal block
- Energy and Power: Turbines, generators and other power generation equipment.
- Oil and Gas: Oil well pumps, compressors and long-distance pipelines in oil refineries.
- Metallurgy and Steel: Temperature monitoring and material control equipment during high-temperature smelting processes.
- Environmental Protection and Public Facilities: Water treatment systems (water supply/waste disposal), heating systems.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Isolation Protection: The module is 100% tested at 2550 VDC for 1 second for user-to-system isolation, protecting internal logic from high-voltage transients on the field side.
Overvoltage Capability: It can handle continuous overvoltage at room temperature up to 30 VDC for voltage inputs and 8 VDC for current inputs.
RFI Immunity: Protection against Radio Frequency Interference (RFI) ensures an error of less than 2.0% of the range when exposed to 10 V/m across frequencies from 27 to 1000 MHz.
Noise Rejection: It provides Normal Mode Noise Rejection greater than 33 dB at 50 Hz and Common Mode Rejection of 100 dB at 50/60 Hz to protect signal accuracy from electrical noise.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about TC-IAH161
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
What is the TC-IAH161？
The Honeywell TC-IAH161 is a high-level analog input module commonly used in Experion PKS and C200/C300 control systems. -
What are the TC-IAH161 key technical specifications?
The TC-IAH161 is a High Level Analog Input Module with RFl immunity of less than 2.0% of range at 10V/m, 27 to 1000MHz, and an isolation voltage of 2550VDC for Is. It has a maximum power dissipation of 4.1W. -
What input ranges does TC-IAH161 support?
It supports voltage inputs (±10.25 V, 0 to 10.25 V, 0 to 5.125 V) and current inputs (0 to 20.5 mA using an internal 250-ohm resistor). -
What is the TC-IAH161 power dissipation?
Maximum power dissipation is 4.1 W. -
What is the difference between TC-IAH161 and TK-IAH161?
While listed interchangeably by some vendors as analog input modules,
