Technical specifications for CSNK500M-600
-
Product ModelCSNK500M-600
-
Product ParametersCurrent transducer based
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size8.8x2.6x8.4cm
-
ManufacturerHoneywell
-
Weight0.25 kg
-
Nominal current500 A.t rms
-
Measuring range0 to ± 1200 A.t
-
Nominal analogue output current at 500A100 mA
-
Turns ratio1 / 5000
-
Supply voltage±15 to ±18 Vdc (±5%)
-
Galvanic isolation6 kV rms / 50 Hz / 1 minute
-
Operating temperature-40°C to +85°C
-
Storage temperature-40°C to +90°C
-
Current consumption20 mA plus output current
-
Secondary internal resistance (at +70°C)50 ohm
Description
The CSNK500M-600 is a Honeywell CSN Series closed-loop current transducer designed for precise and isolated measurement of AC, DC, or impulse currents in industrial applications. The CSNK500M-600 utilizes closed-loop Hall effect current sensing technology, providing accurate current measurement with excellent linearity and fast response time.
The CSNK500M-600 provides a nominal measuring range of ±500A with a peak measuring range of ±1275A, accommodating high-current industrial applications such as motor drives, power converters, and welding equipment. The CSNK500M-600 delivers high accuracy of ±0.5% for precise current measurement and control in demanding industrial applications. The CSNK500M-600 features an ultra-fast response time of 1 microsecond, enabling real-time current monitoring and protection in high-speed switching applications.
The CSNK500M-600 operates reliably in ambient temperatures from -40°C to +85°C, making it suitable for harsh industrial environments with extreme temperature variations. The CSNK500M-600 operates with a supply voltage range of ±12V to ±18V, with a maximum supply current of 20mA, providing flexibility for integration with various industrial control systems.
The CSNK500M-600 provides a nominal measuring range of ±500A with a peak measuring range of ±1275A, accommodating high-current industrial applications such as motor drives, power converters, and welding equipment. The CSNK500M-600 delivers high accuracy of ±0.5% for precise current measurement and control in demanding industrial applications. The CSNK500M-600 features an ultra-fast response time of 1 microsecond, enabling real-time current monitoring and protection in high-speed switching applications.
The CSNK500M-600 operates reliably in ambient temperatures from -40°C to +85°C, making it suitable for harsh industrial environments with extreme temperature variations. The CSNK500M-600 operates with a supply voltage range of ±12V to ±18V, with a maximum supply current of 20mA, providing flexibility for integration with various industrial control systems.
Alternative Names
CSNK500M-60O
CSNK500M-6O0
CSNK50OM-600
CSNK5O0M-600
CSNK500M 600
CSNK500M 60O
CSNK500M 6O0
CSNK50OM 600
CSNK5O0M 600
Information
Overview
Manuals
Application Notes
Product Applications
Mechanical Mounting
Features:
- CURRENT SENSOR
- BIDIRECTIONAL MODULE
- CLOSED LOOP
- SINGLE PASS THROUGH
The CSNK500M-600 Honeywell CURRENT SENSOR may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell CSNK500M-600 CURRENT SENSOR Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The CSN Series of closed loop current sensors are based on the principles of the Magnetoresistive or Hall effects, and the null balance or zero magnetic flux method (feedback system). The magnetic flux in the sensor core is constantly controlled at zero.
The amount of current required to balance zero flux is the measure of the primary current flowing through the conductor, multiplied by the ratio of the primary to secondary windings.
- Automotive & EV Assembly Plants:Monitors welding currents & BMS testing in EV production
- Renewable Energy Equipment Manufacturing:Monitors current during rapid load changes for solar/wind controllers
- Industrial Automation Hubs:VFDs & servo drives: powers conveyors, stackers & sorters
- Semiconductor & High-Tech Fabrication:Ultra-clean stable current for sensitive manufacturing equipment
- Heavy Machinery Factories:Overcurrent & ground fault protection for steel/chemical plants
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Primary Conductor: Pass the conductor to be measured through the central aperture (iris). For optimal accuracy, ensure the conductor is centered and keep a minimum distance of 5 mm from the sensor body to allow for heat dissipation.
Orientation: The sensor can be mounted in any orientation. Use the integrated mounting holes for screw attachment to a panel or bracket.
Separation: Maintain at least 1 inch (25 mm) of space between the sensor and other magnetic components like contactors or transformers to avoid interference.
Technical notes
The transducer features a single-channel, bidirectional design with through-hole mounting for single pass-through installation. It operates from a dual supply voltage of ±12 V to ±18 V with a maximum supply current of 20 mA. The sensor provides a ratiometric current output proportional to the measured primary current.
FAQs
-
What is CSNK500M-600?
+The Honeywell CSNK500M-600 is a closed-loop current sensor designed for the electronic measurement of DC, AC, or pulsed currents with a measuring range up to ±1275 A. -
What is the difference between the CSNK500M and the CSNK500M-600?
+The primary difference is the electrical connector. While the standard CSNK500M is often considered obsolete or uses a different internal connector, the CSNK500M-600 requires the Molex RSD-46607-001 mating harness -
What are the power supply requirements?
+It requires a regulated dual power supply of ±15 V to ±18 V DC. Using a single power supply or an unregulated source can lead to inaccurate readings or sensor failure. -
Can it measure both AC and DC?
+Yes, it is designed for the electronic measurement of DC, AC, and pulsed currents with galvanic isolation between the primary and secondary circuits.
