PRODUCT DESCRIPTION
4329G - Network Communication Module
Triconex 4329G is a Network Communication Module with GPS-based time-synchronization capability. It connects a Tricon controller to other Tricons and external Ethernet hosts through two BNC network ports using RG58 50-ohm coaxial cable.
NET 1 serves the documented Tricon-only peer and time-synchronization network; NET 2 serves external host applications. Preserve the network address switches and coaxial terminations during replacement. Paired NCMs operate independently, and communication through a removed module stops.
NET 1 serves the documented Tricon-only peer and time-synchronization network; NET 2 serves external host applications. Preserve the network address switches and coaxial terminations during replacement. Paired NCMs operate independently, and communication through a removed module stops.
BEFORE YOU BUY
Check the complete installed configuration
ACTUAL APPLICATIONS
Where 4329G supports legacy Tricon networks
The manufacturer distinguishes peer networking, external host access and time synchronization. Select the network port and topology for the intended task.
-
01 · CONTROLLER PEERS
Exchange data between Tricons
Use NET 1 for the documented Peer-to-Peer network composed only of Tricon controllers. Check the logical-slot configuration because the two-slot NCM arrangement excludes Peer-to-Peer operation. -
02 · HOST ACCESS
Connect external operator applications
Use NET 2 for documented external host applications such as TriStation and SOE tools. Preserve the coaxial network and its end terminations when servicing a module to avoid disrupting other devices. -
03 · TIME REFERENCE
Align controller clocks to GPS
Use the NCMG capability to synchronize time from a GPS system within the documented system design. Confirm the installed time-reference arrangement instead of treating the ordinary NCM serial connector as a general-purpose device port.
Technical specifications for 4329G
-
Product Model4329G
-
Product ParametersNetwork Communication Module
-
In stock1 unit
-
ManufacturerInvensys
-
Network connectorsTwo BNC ports
-
Network cableRG58, 50-ohm coaxial thin cable
-
Ethernet electrical interfaceIEEE 802.3
-
Communication speedUp to 10 Mbps
-
Typical direct coaxial distanceUp to 185 m (607 ft)
-
Extended network distanceUp to 4000 m using repeaters and standard thick-net cabling
-
External transceiver portsNot used
-
Serial interfaceOne RS-232-compatible port
-
Port isolation500 VDC for network and RS-232 ports
-
NET 1 roleTricon-only Peer-to-Peer and Time Synchronization
-
NET 2 roleExternal host networking and TSAA applications
-
NCMG time referenceGPS-based time synchronization
-
Processor data refreshTypically once per scan
-
Logical-slot operationTwo NCMs operate independently; not hot-spare modules
-
Logic powerLess than 20 W
View all additional
Alternative Names
4329G
Tricon NCMG
GPS Network Communication Module
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM CONFIGURATION
Preserve the coaxial network and port roles
Triconex 4329G is a Network Communication Module with GPS-based time-synchronization capability. It connects a Tricon controller to other Tricons and external Ethernet hosts through two BNC network ports using RG58 50-ohm coaxial cable.
NET 1 serves the documented Tricon-only peer and time-synchronization network; NET 2 serves external host applications. Preserve the network address switches and coaxial terminations during replacement. Paired NCMs operate independently, and communication through a removed module stops.
Keep NET 1 and NET 2 assigned to their documented roles. Review logical-slot restrictions, network-address switches and coaxial end terminations before any maintenance operation.
Features:
- Two BNC coaxial network connections
- Up to 10 Mbps Ethernet communication
- GPS-based time synchronization
The 4329G requires configuration and installation checks before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Record the 4329G identity and network-address switch settings. Do not break the coaxial network or disconnect its end terminations while removing communication cables from the module.
NET 1 serves the documented Tricon-only peer and time-synchronization network; NET 2 serves external host applications. Preserve the network address switches and coaxial terminations during replacement. Paired NCMs operate independently, and communication through a removed module stops.
Retain the validated safety logic and proof-test records. Recommission affected channels under the approved site procedure.
Features:
- Two BNC coaxial network connections
- GPS-based time synchronization
- Independent operation without hot sparing
The 4329G requires replacement verification of network address, cable terminations and restored host or peer communication before commissioning.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The Manufacturer's Manual download is a manufacturer technical-data extract, not a complete operation manual. The installation guide contains only source-supported checks. Specifications of other configurations shown on source pages must not be applied to this exact order.Features:
- Sources: Invensys Tricon v9-v10 Planning and Installation Guide, 9720077-012, February 2009
- Use complete equipment instructions for installation and commissioning.
- Accessories are supplied only when listed in the quotation
Documentation for the 4329G is supplied here as a technical-data extract; confirm manual availability in the written quotation.
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size2.2 × 40.8 × 40 cm
-
Shipping weight2.40 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8537101190
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 4329G
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Can an Ethernet patch lead be plugged directly into 4329G?
Its network connectors are BNC for RG58 50-ohm coaxial cable, not RJ-45. Verify the existing medium and network arrangement before ordering a spare. -
Are the 15-pin transceiver connectors usable network interfaces?
The exact 4329/4329G specification lists external transceiver ports as not used. The family front-panel drawing marks those connectors reserved; they are not extra supported network ports. -
What can be disturbed by removing a coaxial end termination?
The manufacturer warns that breaking the cables or disconnecting their end terminations disrupts other network devices. Disconnect the module without dismantling the network termination arrangement. -
Which address setting must be copied from the removed NCM?
Identify the network-address switch setting and set the replacement switches to the same address before inserting it, as required by the replacement procedure. -
Does the 4000 m figure apply to one direct RG58 cable run?
No. The direct coaxial connection is described as typically up to 185 m. The longer distance requires repeaters and standard thick-net cabling, not an extended unmodified RG58 segment. -
What restriction applies when two logical slots are configured for NCMs?
The communication rules require slots 6 and 7 in the Main Chassis, and Peer-to-Peer cannot be used in that arrangement. A single logical slot may instead be in the Main Chassis or Chassis 2. -
Can an NCM network be retained alongside a TCM in one Tricon system?
The manufacturer communication rules prohibit NCM and TCM modules in the same Tricon system. Review the complete installed communication configuration before planning a migration. -
Does a faster Ethernet host make the NCM data fresher than the controller scan?
The documented network rate is up to 10 Mbps, and Main Processors typically refresh NCM data once per scan. Link speed must not be presented as a guarantee of faster controller-data updates.
