· Product image is representative; revision or series may vary. Contact us to request a specific version.
- Customs & Documentation
- We prepare clear, order-specific documentation for every international shipment, including the commercial invoice, packing list and available product or compliance documents. Before dispatch, our logistics team confirms the consignee details, declared value, shipping terms and destination requirements with you. Tracking information is provided after shipment, helping your team prepare for import clearance with confidence.
Documents checked before dispatch · Shipment details confirmed · Global tracking provided
- Payment
- Payment is by bank wire only in RMB/CNY, GBP, EUR or USD. Amikon does not accept credit cards or provide credit terms. Cleared payment is required before shipment unless the written quotation expressly states otherwise.
- Product Condition
- Factory New These are new and current items that are procured directly from the manufacturer.
New In Sealed Package Parts are new. They have not been used and still have their original package seal intact.
New in Original Package These parts are new. The packages were not originally sealed by their original manufacturer.
-
20+
years in automation -
ISO 9001
certified quality system -
12 months
amikon warranty -
2-hour reply
from your account manager -
Success Story
solutions in action
-
Please try to be as accurate as possible with your search.
-
We can quote you on 1000s of specialist parts, even if they are not listed on our website.
-
We can't find any results for “”.
SEE PRODUCTS IN SEARCH PAGE ()
PRODUCT DESCRIPTION
3664 - Dual Digital Output Module
The Triconex 3664 is a 32-point, commoned Dual Digital Output Module with a dual serial configuration for 24 VDC field circuits.
Its recommended field range is 16-30 VDC, and the self-protected output switches provide over-voltage, over-temperature and over-current protection.
Its recommended field range is 16-30 VDC, and the self-protected output switches provide over-voltage, over-temperature and over-current protection.
BEFORE YOU BUY
Check the complete ordered configuration
ACTUAL APPLICATIONS
Where 3664 supports measurement tasks
Manufacturer literature supports the following measurement arrangements. Confirm the complete installed system and the exact ordered configuration before selecting this component.
-
01 · DC OUTPUTS
Command 24 VDC field loads
24 VDC solenoid and actuator control. Verify the documented field interface, configured limits and approved safety function before service. -
02 · RELAY COMMANDS
Operate interposing relay circuits
DC relay and interposing-relay outputs. Verify the documented field interface, configured limits and approved safety function before service. -
03 · COMMONED LOADS
Control grouped digital outputs
Indicator, alarm and control-panel outputs. Verify the documented field interface, configured limits and approved safety function before service.
Technical specifications for 3664
-
Product Model3664
-
Product ParametersDual Digital Output Module
-
In stock1 unit
-
ManufacturerInvensys
-
Output Signals32, commoned
-
Output ConfigurationDual, serial
-
Recommended Voltage16-30 VDC
-
Maximum Voltage36 VDC
-
Current Rating2 A per point maximum
-
Surge Current10 A for 10 ms maximum
-
Load Leakage2 mA maximum
-
Point Isolation1,500 VDC minimum
-
Slot KeysTop 006, bottom 007
-
Logic Power<10 W
View all additional
Alternative Names
3664
24 VDC Dual Digital Output Module
32-Point Commoned Output Module
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM CONFIGURATION
Match the installed measurement arrangement
The Triconex 3664 is a 32-point, commoned Dual Digital Output Module with a dual serial configuration for 24 VDC field circuits.
Use 3664 only with the compatible Tricon configuration identified by the complete model number.
Match the exact module type and system version.
Confirm the chassis, logical slot and mechanical keying.
Verify the 24 VDC field supply, common return, fault response and termination.
Check firmware, application configuration and hazardous-area requirements.
Do not treat another Tricon family module as interchangeable without controlled Triconex verification.
The 3664 is not recommended for energize-to-trip applications. Engineering review must confirm that the documented stuck-Off behavior is acceptable for the controlled process.
Features:
- 32 commoned outputs
- 16-30 VDC recommended
- 36 VDC maximum
The 3664 requires exact configuration and installation checks before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Confirm the complete 3664 model number before replacement because related Tricon modules may have different electrical and diagnostic behavior.
Record the installed chassis, slot, system version, firmware and termination arrangement.
Inspect the connectors, keys, terminals and mounting hardware.
Preserve the approved field wiring, scaling, application logic and safety function.
Verify current controlled Triconex documentation and hazardous-area requirements.
Contact Amikon with 3664 for availability and replacement support.
Its recommended field range is 16-30 VDC, and the self-protected output switches provide over-voltage, over-temperature and over-current protection.
Retain the validated safety logic, termination arrangement and proof-test records. Recommission every affected channel before the safety function is returned to service.
Features:
- 32 commoned outputs
- 36 VDC maximum
- 2 A per point maximum
The 3664 requires replacement verification of the complete ordered configuration and installed measurement system before commissioning.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The Manufacturer's Manual download is a manufacturer technical-data extract, not a complete operation manual. The installation guide contains only source-supported checks. Specifications of other configurations shown on source pages must not be applied to this exact order.
Features:
- Sources: Existing verified Triconex model documentation and saved model PDFs
- Use complete equipment instructions for installation and commissioning.
- Accessories are supplied only when listed in the quotation
Documentation for the 3664 is supplied here as a technical-data extract; confirm manual availability in the written quotation.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size49 × 45.3 × 6.8 cm
-
Shipping weight3.25 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8537101190
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 3664
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Is 3664 suitable for my 24 VDC output system?
Use 3664 for 32 commoned DC outputs with a recommended 16-30 VDC field range. Confirm the common return, load current, surge current and fault-response requirements. -
Can 3664 directly replace another Tricon digital output module?
Do not decide from the 32-point layout alone. Match the exact 3664 model, dual serial configuration, commoned wiring, slot keys 006/007, termination and application safety philosophy. -
What should an MRO buyer provide for an urgent 3664 quotation?
Provide the exact model, quantity, label and connector photos, chassis and slot, field voltage, load list, termination details, present fault symptoms and destination country. -
Is 3664 appropriate for an energize-to-trip application?
The manufacturer documentation does not recommend 3664 for energize-to-trip service. Have the system integrator verify the required safe-state behavior and approved output-module selection. -
What electrical limits should be checked for 3664 loads?
Keep the field supply within 16-30 VDC and never above 36 VDC. Confirm each load remains within 2 A maximum, 10 A for 10 ms surge and the documented leakage limits. -
What should be inspected when 3664 arrives?
Check the exact label, connector condition, slot keys, housing and front indicators. Compare the commoned termination and field-power arrangement with the installed module. -
What should be tested after installing 3664?
Verify PASS, FAULT, ACTIVE, output-state and LOAD/FUSE indications. Functionally test commanded On and Off states and confirm common return and field power before process release. -
What should engineers check if 3664 outputs remain off?
Check the 24 VDC supply, common return, termination, load wiring, controller commands and diagnostic indications. Consider the documented stuck-Off fault response when reviewing system behavior.
