PRODUCT DESCRIPTION
3008 - TMR Main Processor Module
Triconex 3008 is a main processor module for the Tricon v9.6-v10.x controller range documented in the manufacturer guide. Three main processors independently execute the control program and exchange voted data through TriBus.
The exact-model specification identifies a 50 MHz Motorola MPC860, 16 MB DRAM, 32 KB battery-backed SRAM and 6 MB Flash PROM. Check the installed controller version, matching processor firmware and slot keys before planning an exchange; 3006 or 3007 identity alone does not establish interchangeability.
The exact-model specification identifies a 50 MHz Motorola MPC860, 16 MB DRAM, 32 KB battery-backed SRAM and 6 MB Flash PROM. Check the installed controller version, matching processor firmware and slot keys before planning an exchange; 3006 or 3007 identity alone does not establish interchangeability.
BEFORE YOU BUY
Check the complete installed configuration
ACTUAL APPLICATIONS
Where 3008 supports controller processing
The manufacturer describes these processor functions. Validate the installed Tricon version and the complete safety application before service.
-
01 · CONTROL EXECUTION
Run the validated control program
Execute the configured control program independently in each of the three processor legs. The architecture compares program data between processors while each leg maintains its own I/O communication. -
02 · EVENT RECORDING
Capture discrete sequence-of-events data
Record configured Boolean state changes with timestamps in SOE buffers. Main processors work with communication modules; configure SOE blocks in TriStation and retrieve them through the appropriate recorder software. -
03 · DATA INTEGRITY
Coordinate interprocessor data voting
Use the documented TriBus path for interprocessor exchange, digital-input majority voting and control-variable comparison. The exact 3008 specification identifies CRC-protected, isolated DMA transfer.
Technical specifications for 3008
-
Product Model3008
-
Product ParametersTMR Main Processor Module
-
In stock1 unit
-
ManufacturerInvensys
-
Main processorMotorola MPC860, 32-bit, 50 MHz
-
DRAM16 MB, without battery backup
-
SRAM32 KB, with battery backup
-
Flash PROM6 MB
-
TriClock functionTime and date with battery backup
-
TriClock driftTypical +/-2 seconds/day; maximum +/-2.16 seconds/day
-
TriBus transfer rate25 megabits/second, per model 3008 Table 8
-
TriBus error protection32-bit CRC
-
TriBus transfer mechanism32-bit DMA, fully isolated
-
Diagnostic serial interfaceOptically isolated RS-232; one 25-pin connector
-
Diagnostic serial isolation500 VDC
-
Communication processorMotorola MPC860, 32-bit, 50 MHz
-
Communication bus interfaceRS-485, 2 megabits/second
-
I/O bus interfaceRS-485, 375 kilobits/second
-
Logic power10 W
View all additional
Alternative Names
3008
Tricon Main Processor
MP 3008
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM CONFIGURATION
Match controller version and processor set
Triconex 3008 is a main processor module for the Tricon v9.6-v10.x controller range documented in the manufacturer guide. Three main processors independently execute the control program and exchange voted data through TriBus.
The exact-model specification identifies a 50 MHz Motorola MPC860, 16 MB DRAM, 32 KB battery-backed SRAM and 6 MB Flash PROM. Check the installed controller version, matching processor firmware and slot keys before planning an exchange; 3006 or 3007 identity alone does not establish interchangeability.
Record the installed Tricon release, processor firmware and validated application before replacement. The guide requires matching firmware across the main processors and identifies dedicated mechanical keys for 3008.
Features:
- Three independent processor legs
- 16 MB DRAM and 32 KB backed SRAM
- 25 Mbit/s exact-model TriBus rating
The 3008 requires configuration and installation checks before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Preserve the exact 3008 identity, installed Tricon version and matching processor firmware. A 3006 or 3007 is not established as interchangeable by a similar appearance.
The exact-model specification identifies a 50 MHz Motorola MPC860, 16 MB DRAM, 32 KB battery-backed SRAM and 6 MB Flash PROM. Check the installed controller version, matching processor firmware and slot keys before planning an exchange; 3006 or 3007 identity alone does not establish interchangeability.
Retain the validated safety logic and proof-test records. Recommission affected channels under the approved site procedure.
Features:
- Three independent processor legs
- 25 Mbit/s exact-model TriBus rating
- Battery-backed time and date
The 3008 requires replacement verification of controller release, matching firmware, mechanical keys and the validated application before commissioning.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The Manufacturer's Manual download is a manufacturer technical-data extract, not a complete operation manual. The installation guide contains only source-supported checks. Specifications of other configurations shown on source pages must not be applied to this exact order.Features:
- Sources: Invensys Tricon v9-v10 Planning and Installation Guide, 9720077-012, February 2009
- Use complete equipment instructions for installation and commissioning.
- Accessories are supplied only when listed in the quotation
Documentation for the 3008 is supplied here as a technical-data extract; confirm manual availability in the written quotation.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size2.2 × 40.8 × 40 cm
-
Shipping weight2.10 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8537101190
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 3008
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Which Tricon versions does the guide list for 3008?
The compatibility table lists v9.6-v10.x for 3008. It lists 3006 and 3007 against earlier versions, so check the installed system release instead of treating the main processors as automatically interchangeable. -
Which memory retains configured values with battery backup?
The 32 KB SRAM is battery-backed; the 16 MB DRAM is not. The guide assigns defined program retentives and disabled-point configuration to SRAM. -
Why is 25 Mbit/s used instead of the general TriBus description?
Table 8 specifically assigns 25 megabits/second to model 3008. A general overview elsewhere in the guide describes 4 megabits/second; use the exact-model table for this specification. -
What does a blinking yellow Active indicator signify?
With Pass green and Fault off, Active blinks once per scan while executing an application. Interpret it with the complete indicator combination in the 3008 status table. -
Which slot keys distinguish 3008 from 3006 or 3007?
The guide lists top key 007 and bottom key 002 for 3008. The older processors use a different bottom key; do not force a module past an obstructing key. -
How is a firmware mismatch identified across the processors?
The 3008 indicator table associates steady Fault with blinking Maint1 and Maint2 and Active off with mismatched MP firmware. Use a correctly matched replacement under the approved system procedure. -
Is the DB9 connector a documented working Modbus port?
The architecture labels a DB9 Modbus connector but marks it reserved for future use. Do not promise it as an operational application interface; the documented diagnostic serial interface is the isolated 25-pin RS-232 connection. -
What must accompany an SOE recording requirement?
Provide the configured SOE blocks, designated Boolean variables and the installed communication-module arrangement. The main processors timestamp events, while retrieval requires the appropriate communication and recorder setup.
