PRODUCT DESCRIPTION
3006 - Main Processor Module
The Triconex 3006 is a Main Processor Module for Tricon v9.0-v9.5.x systems, using a 32-bit 25 MHz processor, 2 MB SRAM and the fault-tolerant Tricon bus architecture.
The module provides isolated diagnostic communications, RS-485 controller interfaces and independent processing for one of the three Tricon controller channels.
The module provides isolated diagnostic communications, RS-485 controller interfaces and independent processing for one of the three Tricon controller channels.
BEFORE YOU BUY
Check the complete ordered configuration
ACTUAL APPLICATIONS
Where 3006 supports measurement tasks
Manufacturer literature supports the following measurement arrangements. Confirm the complete installed system and the exact ordered configuration before selecting this component.
-
01 · PROCESSING CORE
Execute Tricon safety logic
Main processing for Tricon v9 safety systems. Verify the documented field interface, configured limits and approved safety function before service. -
02 · ESD CONTROL
Coordinate shutdown processing
TMR controller processing for emergency shutdown systems. Verify the documented field interface, configured limits and approved safety function before service. -
03 · FAULT-TOLERANT LOGIC
Maintain triplicated controller execution
Controller processing for burner management systems. Verify the documented field interface, configured limits and approved safety function before service.
Technical specifications for 3006
-
Product Model3006
-
Product ParametersMain Processor Module
-
In stock1 unit
-
ManufacturerInvensys
-
System VersionsTricon v9.0-v9.5.x
-
Central ProcessorNS32GX32, 32-bit, 25 MHz
-
EPROM Memory512 KB
-
SRAM2 MB
-
TriBus4 Mbit/s, 16-bit DMA
-
Serial PortIsolated RS-232, DB25
-
Communication InterfaceRS-485, 2 Mbit/s
-
I/O InterfaceRS-485, 375 kbit/s
-
Slot KeysTop 007, bottom 007
-
Logic Power15 W
View all additional
Alternative Names
3006
Tricon v9 Main Processor Module
Triple Modular Redundant Controller Processor
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM CONFIGURATION
Match the installed measurement arrangement
The Triconex 3006 is a Main Processor Module for Tricon v9.0-v9.5.x systems, using a 32-bit 25 MHz processor, 2 MB SRAM and the fault-tolerant Tricon bus architecture.
Use 3006 only with the compatible Tricon configuration identified by the complete model number.
Match the exact module type and system version.
Confirm the chassis, logical slot and mechanical keying.
Verify the processor set, firmware and communication architecture.
Check firmware, application configuration and hazardous-area requirements.
Do not treat another Tricon family module as interchangeable without controlled Triconex verification.
Model 3006 is documented for Tricon v9.0-v9.5.x systems. It uses top and bottom slot key 007 and must be installed with firmware compatible with the remaining Main Processor modules.
Features:
- Tricon v9.0-v9.5.x
- NS32GX32, 32-bit, 25 MHz
- 2 MB SRAM
The 3006 requires exact configuration and installation checks before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Confirm the complete 3006 model number before replacement because related Tricon modules may have different electrical and diagnostic behavior.
Record the installed chassis, slot, system version, firmware and termination arrangement.
Inspect the connectors, keys, terminals and mounting hardware.
Preserve the approved field wiring, scaling, application logic and safety function.
Verify current controlled Triconex documentation and hazardous-area requirements.
Contact Amikon with 3006 for availability and replacement support.
The module provides isolated diagnostic communications, RS-485 controller interfaces and independent processing for one of the three Tricon controller channels.
Retain the validated safety logic, termination arrangement and proof-test records. Recommission every affected channel before the safety function is returned to service.
Features:
- Tricon v9.0-v9.5.x
- 2 MB SRAM
- 4 Mbit/s TriBus
The 3006 requires replacement verification of the complete ordered configuration and installed measurement system before commissioning.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The Manufacturer's Manual download is a manufacturer technical-data extract, not a complete operation manual. The installation guide contains only source-supported checks. Specifications of other configurations shown on source pages must not be applied to this exact order.
Features:
- Sources: Existing verified Triconex model documentation and saved model PDFs
- Use complete equipment instructions for installation and commissioning.
- Accessories are supplied only when listed in the quotation
Documentation for the 3006 is supplied here as a technical-data extract; confirm manual availability in the written quotation.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size49 × 45.3 × 6.8 cm
-
Shipping weight2.9 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8537101190
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 3006
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Is 3006 suitable for my installed Tricon system?
Use 3006 only with a documented Tricon v9.0-v9.5.x controller. Confirm the chassis, three-processor set, firmware, communication modules and slot keying before ordering. -
Can 3006 directly replace another Tricon Main Processor?
Do not decide from appearance or the Main Processor family name alone. Match the exact 3006 model, system version, firmware, 2 MB SRAM configuration, slot keys and the other two processor modules. -
What should an MRO buyer provide for an urgent 3006 quotation?
Provide the exact model, quantity, nameplate and connector photos, Tricon system version, installed firmware, chassis and slot, fault indications and destination country. -
Can 3006 be mixed with different processor firmware in the same chassis?
The three Main Processor modules must be verified as a compatible set. Confirm the documented system release and firmware alignment before replacing one processor or returning the controller to service. -
What should a system integrator inspect when 3006 arrives?
Check the exact label, physical condition, DB25 diagnostic connector, RS-485 interfaces, slot keys and front indicators. Compare the received module with the installed processor set before removal. -
What installation checks are important for 3006?
Use the keyed Main Processor slot, follow the approved Tricon maintenance procedure and confirm chassis power and connector condition. Do not force a module whose top and bottom keys do not match. -
What should be tested after installing 3006?
Verify PASS, FAULT, ACTIVE, MAINT1 and MAINT2 indications, controller execution, I/O and communication-bus operation, redundancy and the event log before returning the process to service. -
What should engineers check if the replacement 3006 does not become active?
Recheck model and slot keying, processor-set firmware, chassis connectors, communication buses and diagnostic indications. Review the Tricon event log before replacing additional hardware.
