Technical specifications for MVC4-TCB 36-0576
-
Product ModelMVC4-TCB 36-0576
-
Product ParametersCircuit Board
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size43.2x16.5x3cm
-
ManufacturerMotortronics
-
Weight0.85 kg
-
Control Voltage120 VAC
-
Relay Selections16 programmable selections per relay
-
Timer Functions3 delay-on-make timers (TON), 1 off-delay timer (TOF)
-
Relay Rating5A @ 250VAC max
Description
MVC4TCB
MVC4 SPARE PARTS
CONTROL BOARD
RANGE: ALL RATINGS
Terminal and Control Board
MVC4 SPARE PARTS
CONTROL BOARD
RANGE: ALL RATINGS
Terminal and Control Board
Information
Overview
Manuals
Technical notes
Product Applications
General Setup and Installation
Features:
- Advanced I/O and Communication Options
- Msmart Touch Panel Interface
- 120 VAC Control Board
The TCB board, provides interconnections between the main power and CPU boards and thecustomer’s control logic connections. It is a 120 VAC control board with several auxiliary dry contacts, built-in time delaycircuits and an emergency bypass function. It also controls the inline isolation and bypass contactor and providesprovisions for shutdown interlocks.
The MVC4-TCB 36-0576 MOTORTRONICS Circuit Board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
MOTORTRONICS MVC4-TCB 36-0576 Circuit Board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Motortronics MVC4-TCB (Part Number: 36-0576) is the Terminal and Control Board (TCB) for the Motortronics MVC4 Series Medium Voltage Soft Starter (1.0 – 7.2kV Class). It serves as the primary user connection interface and control interface for the starter electronics. Acts as the interface between external control circuits and the soft starter's central control board.Contains user terminal blocks, redundant output relays, input terminals, and control power connections.
- Pumping Systems: Water and wastewater pumping
- Industrial Fan and Blower Systems: Large-scale air handling
- Compressors: Used in various industrial processess
- Conveyors and Crushers: Applications requiring high torque and smooth acceleration
- Heavy Duty Infrastructure: Mining, oil and gas, and power generation facilities where 2.3kV-15kV motors are employed
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Safety Warning: Dangerous voltages are present. Installation should be performed by qualified personnel. Failure to follow instructions can lead to death or serious injury.
Connections: All user connections for control signals are connected directly to this board. Ensure all field wiring is properly secured according to the wiring diagrams in the manual.
Fiber Optic Connections: Ensure the fiber optic cables from the Gate Drive Boards (on the SCR stacks) are properly connected to the TCB/Main Board to prevent SCR damage.
