Technical specifications for IFMA0035
-
Product ModelIFMA0035
-
Product ParametersSignal Converter
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size12.2x10.7x3cm
-
ManufacturerRed Lion
-
Weight0.3 kg
-
AC Operation85 to 250 VAC, 48 to 62 Hz; 6.5 VA
-
DC Operation9 to 32 VDC; 2.5 W
-
Power Up CurrentIp = 600 mA for 50 msec. max
-
SENSOR POWER(AC version only) +12 VDC ±25% @ 60 mA max
-
OPERATING FREQUENCY RANGEFrom 0 Hz to 25 KHz; user selectable
-
Voltage3.5 mV min
-
Current5 µA min
-
Operating Temperature0 to 50°C
-
Storage Temperature-40 to 80°C
-
AltitudeUp to 2000 meters
Description
SIMPLE ON-LINE RANGE SETTING
USER SETTABLE FULL SCALE FREQUENCY
FROM1 Hz to 25 KHz
FOUR OUTPUT OPERATING RANGES
0 to 5 V, 0 to 10 V, 0 to 20 mA, and 4 to 20 mA
PROGRAMMABLE INPUT CIRCUIT ACCEPTS
OUTPUTS FROM AVARIETY OF SENSORS
85 to 250 VAC and 9 to 32 VDC
POWERED VERSIONSAVAILABLE
USER SETTABLE FULL SCALE FREQUENCY
FROM1 Hz to 25 KHz
FOUR OUTPUT OPERATING RANGES
0 to 5 V, 0 to 10 V, 0 to 20 mA, and 4 to 20 mA
PROGRAMMABLE INPUT CIRCUIT ACCEPTS
OUTPUTS FROM AVARIETY OF SENSORS
85 to 250 VAC and 9 to 32 VDC
POWERED VERSIONSAVAILABLE
FAQs
-
What is IFMA0035?
+A DC-powered industrial transducer that converts frequency/pulse signals (from sensors, flowmeters) into standard analog outputs (voltage/current). -
How do I configure the device?
+Setup is done via a 7-position DIP switch, an on-board rotary switch, and a push-button. -
Can it be set manually or with a source?
+Yes, the full-scale input frequency can be set either digitally using the switches/buttons or by applying a known frequency source. -
What affects the response time?
+The response time is determined by a user-programmable Minimum Response Time plus up to one full period of the input signal.
