S100 I/O

Repeater Module

DSAI 133A Analog Input Module

Analog Input Board

Number of Channels: 8 channels
Current: 4–20 mA, 0–20 mA
Voltage: 0–10 VDC, ±10 VDC
Resolution: 16-bit
Accuracy: ±0.05%
Drift: ±0.005%/°C
Channel-to-Channel: 250 VAC.
Channel-to-Backplane: 1500 VAC
Supply Voltage: 24 VDC (±10%)
Power Consumption: ≤2 W (typical)

DSAI 130A Analog Input Module

Analog Input Module

AF100 Communication Interface Kit

Connection Unit for DSDX180

3BUR980025R1
CONNECTION UNIT

DSAX 110A Analog Input/Output Module

3BSE018291R1
I/O BOARD ANALOG 8/8CHANNELS
Tariff Code: 85389091
Country of Origin: Sweden

Analog Input Board 32 Channels

DSAI133
INPUT CARD ANALOG
Tariff Code: 8538907080
Country of Origin: Sweden

Analog Output Board

Current: 4–20 mA
Voltage: 0–10 VDC, ±10 VDC
Resolution: 16-bit
Accuracy: ±0.05% of full scale at 25°C
Temperature Drift: ±0.005%/°C
Channel-to-Channel: 250 VAC.
Channel-to-Backplane: 1500 VAC
Supply Voltage: 24 VDC (±10%) via backplane.
Power Consumption: ≤2 W

Digital Input/Output Module

3BSE003859R1
PC BOARD

Digital Output Module

3BSE018298R1
MODULE
Tariff Code: 85389091
Country of Origin: Sweden

DSBC 174 Bus Extender Module - S100 I/O Bus

DSBC174
DISCONTINUED BY MANUFACTURER
COMMUNICATION MODULE
BUS EXTENDER
S100
I/O BUS
Tariff Code: 8517620050
Country of Origin: Sweden

DSAI 145 RTD Input Module

DSAI145
DISCONTINUED BY MANUFACTURER
PC BOARD
ANALOG INPUT UNIT
(5712001-HA)
Tariff Code: 85389091
Country of Origin: Sweden

DSAI 110 Analog Input Module

DSAI110
DISCONTINUED BY MANUFACTURER
INPUT MODULE
ANALOG
32 CHANNEL
+/- 10V
(57120001-DP)
Tariff Code: 85389091
Country of Origin: Sweden

DSDO120 Digital Output Module

DSDO120
DIGITAL OUTPUT UNIT 24-48VDC 1A
Tariff Code: 8538907080
Country of Origin: Sweden

DSAO130 Analog Output Board 16 Channels

DSAO130
DISCONTINUED BY MANUFACTURER
OUTPUT MODULE
ANALOG
16 CHANNEL
0-10 V
0-20 MA

DSDO131 Digital Output Board Relay

DSDO131
DIGITAL OUTPUT UNIT
Tariff Code: 8538907080
Country of Origin: Sweden

DSBC 173 Bus Extender S100 I/O Bus

DSBC173
DISCONTINUED BY MANUFACTURER
PC BOARD
BUS REPEATER SLAVE
7LED INDICATORS

DSAX 110 Analog Input/Output Module

57120001PC
DSAX 110 ANALOG INPUT/OUTPUT BOARD

AF100 Twisted pair Coax Modem

Advant Fieldbus 100 twisted pair
coax or coax
twisted pair cable
Power 24V d.c.
Rated isolation 50V
Operating Voltage: 24 V DC
Power Consumption: Typically < 5 W
Coaxial (Coax): 75 Ω coaxial cable
Data Rate: Up to 1.5 Mbps
Twisted Pair: Up to 500 meters

Digital Input Board

Terminator Unit for Bus Extension

Connection Unit for Analog Board

AF100 Coaxial Modem
