Siemens

Digital output module

SIMATIC S7-300
Digital output SM 322
Isolated 16 DO
relay contacts
1x 20-pole

Inverter Drive

PCS 7 CPU410-5H F-S7-400/S7-400H/F/FH

SIMATIC CPU 410-5H
Process Automation
central unit for S7-400 and S7-400H/F/FH
5 interfaces: 2x PN, 1x DP
2x for sync modules
for use as spare part
without System Expansion Card

PS405 Power Supply - 10 A

SIMATIC S7-400
power supply PS405
wide range 10 A
24/48/60 V DC
5 VDC/10 A

SINAMICS G120C DP 2,2KW FILA

Inverter Drive

IM153-2 HF DP Slave Interface Module

SIMATIC DP
Connection ET 200M IM 153-2
High Feature for max.
12 S7-300 modules with redundancy capability
Timestamping suitable for isochronous mode
New features: up to 12 modules
can be used Slave INITIATIVE
for Drive ES and Switch ES
 Expanded quantity structure for HART
auxiliary variables Operation of the
64-channel modules 32 signals/slot

6DP16318AA
DISCONTINUED BY MANUFACTURER
INTERFACE MODULE
IM 631
IN THE APF SUBRACK FOR CONNECTING THE APF SUBRACK AND FUM F SUBRACK FUM F SUBRACK

IM661 Module

IM661 Module

FUM310 Fail Safe Binary Module

6DP13108AA
SENSOR

PC Aadapter

PC adapter USB A2 USB adapter (USB V2.0)
for connection of a PG/PC or notebook to
SIMATIC S7 via PROFIBUS or MPI contain USB cable 5 m
MPI cable 0.3 m can be
used under Windows XP/Vista/ Windows
7 32/64 bit and higher

SIMATIC HMI TP1500 COMFORT

Product type designation:TP1500 Comfort
Design of display TFT
Screen diagonal 15.4 in
Display width 331.2 mm
Display height 207 mm
Horizontal image resolution 1 280 pixel
Vertical image resolution 800 pixel
Backlighting
MTBF backlighting (at 25 °C) 80 000 h
Backlight dimmable Yes; 0-100 %

Master Drives Interface board

SIMOVERT Master
drives Interface board
DIGITALTACHO DTI HTL
level up to 24 V

CPU 313C Compact CPU with MPI

SIMATIC S7-300
CPU 313C
Compact CPU with MPI
24 DI/16 DO, 4 AI
2 AO, 1Pt100
3 high-speed counters (30 kHz)
Integr. power supply 24 V DC
workmemory 128 KB
Front connector (2x 40-pole)
Micro Memory Card required

CPU 226 Compact Unit

SIMATIC S7-200 CN
CPU 226 Compact device
AC power supply 24 DI DC/16 DO relay
16/24 KB progr./10 KB data
2 PPI/user-programmable interface
this S7-200 CN product
only has CE approval

SM 1231 Analog Input Module

SIMATIC S7-1200
Analog input, SM 1231
8 AI, +/-10 V, +/-5 V, +/-2.5 V
or 0-20mA/4-20 mA
12 bit+sign or (13 bit ADC)

Digital output module

SIMATIC S7-1500
digital output module
DQ 32x24V DC/0.5A HF
32 channels ingroups of 8
4 A per group; single-channel diagnostics
substitute value, switchingcycle counter for connected actuators

6DP16168CA
INTERFACE MODULE IM616 PROFIBUS

Digital Output Module - Profisafe

6ES71384FB030AB0
DISCONTINUED BY MANUFACTURER
ELECTRONICS MODULE
ET200S
4 F-DO PROFISAFE
24 VDC
2 AMP
PROFINET
Tariff Code: 8538903000
Country of Origin: Germany

Terminal Module

SIMATIC DP
Terminal module
TM-P15C23-A0 for ET 200S for power modules
15 mm width, spring-type terminals (Cage Clamp)
2x3 terminal connections
with terminal access to AUX1
AUX1 interrupted

Analog input module

SIMATIC S7-300
Analog input SM 331
isolated, 2/3/4-wire, 8 AI
Resistor,Pt100/200/1000
NI100/120/200/500/1000, CU10
characteristics according toGOST 16 (internal 24) bit
50ms, 1x 40-pole

Analog Input Module

SIMATIC S7-200 SMART
Analog input SM AI08
8 AI, 0...10V,0...5V
+/-5 V, +/-2.5 V
or 0/4-20 mA
11 bit + sign (12 bit ADC)

S7-400 Rack UR1

SIMATIC S7-400
rack UR1, central and
distributed with 18 slots
2 redundant PScan be plugged in

EM277 Profibus DP Module

SIMATIC S7-200
PROFIBUS DP Slave module
9.6 KB to 12 MB
1 interface PROFIBUS-DP/MPI

Digital Input Module

SIMATIC S7-1500
digital input module DI 32x24 V DC HF
32 channels in groupsof 16
of which 2 inputs as counters can be used
input delay 0.05..20 ms inputtype 3 (IEC 61131)
