- Siemens
- Siemens SIMODRIVE
- 6SN1123-1AA00-0DA0
In Stock
Ships by Sunday, June 28
Fast Shipping Available
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6SN1123-1AA00-0DA0
-
Product Model6SN1123-1AA00-0DA0
-
Product ParametersSIMODRIVE 611 POWER MODULE
-
Tariff Code8537101190
-
Country of originGERMANY
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size15.2x29x50cm
-
ManufacturerSiemens
-
Weight11.35 kg
-
DC Link Voltage600 V DC (typical)
-
DC Link Current (Max.)80 A
-
DC Link Capacitance1100 µF
-
Pulse Frequency4 kHz
-
Output Frequency0 to 600 Hz
-
1FT5 Servo Motor40 A
-
1FT6 Servo Motor28 A
-
Induction Motor (Asynchronous)30 A
Description
The SIEMENS 6SN1123-1AA00-0DA0 is a single-axis power module from the SIMODRIVE 611 drive system. It is designed for internal cooling with an integrated fan and operates from a 600 V DC link supplied by a SIMODRIVE 611 infeed or regenerative feedback module.
The power module delivers a maximum DC link current of 80 A and is rated for various motor types: 40 A for 1FT5 servo motors, 28 A for 1FT6 servo motors, and 30 A for 1PH main spindle motors and standard induction motors. The module provides adjustable pulse frequency with a standard setting of 4 kHz and an output frequency range from 0 to 600 Hz.
The power module delivers a maximum DC link current of 80 A and is rated for various motor types: 40 A for 1FT5 servo motors, 28 A for 1FT6 servo motors, and 30 A for 1PH main spindle motors and standard induction motors. The module provides adjustable pulse frequency with a standard setting of 4 kHz and an output frequency range from 0 to 600 Hz.
Alternative Names
6SN1123 1AA00 0DA0
6SN1123-1AAOO-ODAO
6SN1123-IAA00-0DA0
6SN1123-IAAOO-ODAO
6SN1123 1AAOO ODAO
6SN1123 IAAOO ODAO
Information
Overview
Manuals
Application Notes
Product Applications
Key Installation Steps
Features:
- SIMODRIVE 611 single-axis power module
- Common DC bus architecture
- Servo and spindle motor compatibility
- Compatible with SINUMERIK CNC systems
The Siemens 6SN1123-1AA00-0DA0 power module is part of the SIMODRIVE series and specifically crafted for CNC applications. It accommodates a single axis and can deliver robust performance across various motor types. Internally, the heat dissipation system is built into the module to ensure efficient operation under load. For motor control, it supports 30 Amps for both asynchronous and 1-phase motors while being rated for up to 40 Amps with 1FT5 motors and 28 Amps for 1TF6 types. It meets high-demand industrial needs with a rated power module current of 80 Amps.
The 6SN1123-1AA00-0DA0 Siemens SIMODRIVE 611 Power Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6SN1123-1AA00-0DA0 SIMODRIVE 611 Power Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 6SN1123-1AA00-0DA0 power device's operating conditions are optimized for altitudes below 1000 meters, allowing it to function effectively in standard environments. Operating temperatures range from 0 to 55 degrees Celsius, while it can be safely stored in conditions ranging from -25 to 55 degrees Celsius. The device's shipping weight is approximately 17 pounds, making it a manageable component for installation in industrial settings.
- Portal/Gantry Mills: Large CNC mills shaping aerospace components and locomotive frames
- Boring Mills (HBM/VBM): Drill large-diameter deep holes into heavy castings
- Multi-Spindle Turning Centers: Production lathes with multiple spindles for automotive parts
- Servo Press Lines: High-tonnage stamping presses forming car body panels
- Decoilers/Levelers/Slitters: Unwind, flatten, and cut steel coils into strips
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
De-energize the system: Turn off all supply voltages. Note that hazardous residual voltage remains in the capacitor modules for up to 30 minutes. Measure with a multimeter to ensure zero-voltage status before proceeding.
Handle with ESD Protection: Wear a grounded ESDS wrist strap and avoid touching electronic circuit boards unless absolutely necessary.
Control Board Insertion: Verify that the memory module is locked into the control board, insert the control board into the power module, and tighten the retaining screws (usually 2 on the front panel).
Wiring and Connections: Connect the front panel of the board using your applicable connection diagram. Ensure the mating connectors are properly seated and that shield connections are utilized.
Technical notes
It requires a separate SIMODRIVE 611 control unit (such as the 6SN1118 series) for axis control and closed-loop regulation. The module includes integrated protection functions for overcurrent, overvoltage, undervoltage, overtemperature, ground fault, and short-circuit conditions.
FAQs
-
What is the 6SN1123-1AA00-0DA0?
+The Siemens 6SN1123-1AA00-0DA0 is a 1-axis SIMODRIVE 611 power module rated at 80 A. -
Can this part be replaced by an updated version?
+es, you can typically use the 6SN1123-1AA00-0DA1 or 6SN1123-1AA00-0DA2 to replace the 0DA0 model. These updated versions are compatible, often providing enhanced EMC (Electromagnetic Compatibility), and allow for easier fan replacements. -
Why am I getting Fault Code 2 on my drive?
+A Fault or Alarm 2 is a very common issue that usually indicates a problem with the motor encoder. Before replacing the power module, check the encoder cable for damage and ensure the motor encoder itself is functioning properly. -
What does Fault Code 05 mean?
+Fault Code 05 also points to an Encoder Fault. It indicates that the feedback device is experiencing issues transmitting position and speed data back to the module.
