Technical specifications for C98043-A7042-L1-6
-
Product ModelC98043-A7042-L1-6
-
Spare Model6RY1703-0CM00
-
Product ParametersPower Interface Circuit Board
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size26x25x4cm
-
ManufacturerSiemens
-
Weight0.8 kg
-
Flammability Rating94V-0
-
Incoming Supply (400V)2AC 380V (-25%) to 460V (+15%); I₁n = 1A
-
Incoming Supply (230V)1AC 190V (-25%) to 230V (+15%); I₁n = 2A
-
Internal FusingF1, F2 (1A medium time-lag for 400V; 2×1A for 230V)
-
External FusingMax. 6A, characteristic C
-
Tolerance Extension-35% for 1 minute
Description
The C98043-A7042 is a Power Interface Circuit Board (Power Interface) from Siemens, designed specifically for the SIMOREG DC-MASTER 6RA70 series variable-speed DC drive control modules. The C98043-A7042 serves as the critical interface between the CUD1/CUD2 control electronics and the external power section, handling signal conditioning for current measurement, voltage acquisition, and firing pulse distribution to the thyristor modules.
The C98043-A7042 features an integrated current measurement circuit that includes load resistors R75 and R76 (10Ω each) and a differential amplifier for precise armature current acquisition. The current measurement circuit on the C98043-A7042 can be configured via switches S1, S2, and S3 to accommodate various external current transformer configurations, including V-connection with +1V or +10V at rated armature direct current, as well as differential input for +10V at rated current. This flexibility of the C98043-A7042 enables adaptation to different motor power ratings and current measurement requirements.
The C98043-A7042 features an integrated current measurement circuit that includes load resistors R75 and R76 (10Ω each) and a differential amplifier for precise armature current acquisition. The current measurement circuit on the C98043-A7042 can be configured via switches S1, S2, and S3 to accommodate various external current transformer configurations, including V-connection with +1V or +10V at rated armature direct current, as well as differential input for +10V at rated current. This flexibility of the C98043-A7042 enables adaptation to different motor power ratings and current measurement requirements.
Alternative Names
C98043-A7042-L1-6
C98043 A7042 L1 6
C98043A7042L16
C98043-A7042-LI-6
C98O43-A7O42-LI-6
C98O43-A7O42-L1-6
C98O43 A7O42 L1-6
Information
Overview
Manuals
Application Notes
Product Applications
Wiring and Grounding Rules
Features:
- Power Interface Circuit Board for SIMOREG DC-MASTER
- Integrated Current Measurement Circuit
- Differential Input for Voltage Measurement
- Firing Pulse Interface for Thyristor Modules
- Fuse Monitoring Integration
The C98043-A7042 interfaces with firing transformer boards (C98043-A7043) to deliver triggering pulses to the thyristor power modules in the armature and field circuits. The firing pulse connections on the C98043-A7042 support individual thyristor triggering, parallel connection of firing pulses, and external amplification of firing pulses for high-power applications. The maximum cable length between the C98043-A7042 and the firing transformers is 10 meters, ensuring reliable pulse transmission in standard industrial installations.
The C98043-A7042-L1-6 SIEMENS Power Interface Circuit Board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS C98043-A7042-L1-6 Power Interface Circuit Board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The C98043-A7042-L1-6 is a rectangular printed circuit board assembly populated with power electronic components, fusing elements, and terminal connectors. The board measures approximately 820 grams in weight and mounts internally within the SIMOREG 6RA70 chassis converter. The front edge features Type 49 plug-in terminals accepting conductors up to 1.5 mm² finely stranded wire. The board contains two internal fuses (F1 and F2) for electronics supply protection. The PCB substrate is manufactured with 94V-0 flame-retardant material rating. The module connects to the drive's main power bus and distributes conditioned power to the control electronics and field circuit.
