      6SE7090-0XX84-4HA0

      Need Help? Contact US!
      Call us: +86-18020776786
      Proper, Ready.

      Delivery time
      Please indicate your delivery time

      Product Information

      Product Describe
      6SE70900XX844HA0
      LOCAL BUS ADAPTER
      FOR ELECTRONIC BOX
      SIMOVERT MASTERDRIVES

      Technical specifications for 6SE7090-0XX84-4HA0

      • Product Model
        6SE7090-0XX84-4HA0
      • Product Parameters
        LOCAL BUS ADAPTER
      • Tariff Code
        8537101190
      • Country of origin
        Germany
      • Place of shipment
        Xiamen, China
      • Estimated Shipping Size
        26.3x12.5x2.5cm
      • Manufacturer
        Siemens
      • Weight
        0.2 kg
      • Power Supply
        24 V DC ±10%
      • Transmission Speed
        ≤ 12 Mbps
      • Ambient Conditions
        0°C to +55°C

      • Factory New

        These are new and current items that are procured from the manufacturer.

      • New No Package

        These parts are new. They have not been used, but their original packaging is no longer available.

      • New In Opened Package

        These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged.

      • New In Sealed Package

        Parts are new. They have not been used and still have their original package seal intact.

      • New in Original Package

        These parts are new. The packages were not originally sealed by their original manufacturer.

      Warranty Period & Disclaimer

      Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.

      FAQs

      • What is 6SE7090-0XX84-4HA0?+
        The Siemens 6SE7090-0XX84-4HA0 is a discontinued spare part for the SIMOVERT MASTERDRIVES series.
      • What is the primary function of this part?+
        It is a hardware adapter (Local Bus Adapter / LBA) that mounts inside the electronic box of a SIMOVERT MASTERDRIVES unit. It provides the physical connection and interface required to integrate supplementary option boards or communication modules into the drive.
      • Does the 6SE7090-0XX84-4HA0 require any programming or parameter changes?+
        No. As a passive hardware adapter, it does not hold firmware or require parameterization. If you are replacing the adapter itself, it is a plug-and-play hardware swap. However, if you are adding or replacing the option cards mounted on the adapter, those may require parameterization via Siemens DriveMonitor software or the OP1S operator panel.
      • What should I check if I have communication errors?+
        Ensure that the adapter is correctly seated in the electronic box. If using specific communication processors like the CP340, there may be known library issues requiring a contact to Siemens technical support.
      Get a quick price fo 6SE7090-0XX84-4HA0
      *Quantity
      *E-mail
      Company
      *Mobile
      *Content
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Amikong please read our privacy policy.
      whatsapp
      Inquiry

      Control system parts

      Required delivery time
      ask

      Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions

      Product

      MORE INFORMATION

      Overview Manuals Technical notes Product Applications Verification & Configuration

      Features:

      • Integrated Backplane Extension
      • Dual-Slot Capability
      • Plug-and-Play Compatibility
      • Robust Electrical Shielding
      The Siemens 6SE7090-0XX84-4HA0, commonly referred to as the LBA (Local Bus Adapter), is a fundamental hardware component within the SIMOVERT MASTERDRIVES ecosystem. Its primary function is to expand the internal "Local Bus" of the drive unit, acting as a backplane extender that facilitates the installation of optional expansion modules. Without the LBA, a standard MASTERDRIVES electronics box is typically limited in its ability to interface with multiple peripheral boards simultaneously.

      The 6SE7090-0XX84-4HA0 SIEMENS LOCAL BUS ADAPTER may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
      SIEMENS 6SE7090-0XX84-4HA0 LOCAL BUS ADAPTER Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
      Remove the CU (lefthand slot in the electronics box)using the handles after first removing the connectingcable to the PMU and both retaining screws.Insert the LBA bus expansion in the electronics box(position, refer to the diagram) so that it snaps intoplace. Re-insert the CU into the lefthand slot, screw theretaining screws on the handles tight, and insert theconnecting cable to the PMU. Insert the option board in slot 2 (right) or slot 3(center) of the electronics box, and screw into place.Each option board may only by inserted in theelectronics box. If only one option is used, it mustalways be inserted at slot 2 (right).
      • Continuous Production Lines:Synchronizes multi-motor drives for paper/plastic-film
      • Automated Conveying:PLC-controlled conveying & material handling logistics
      • Advanced Motion Control:Angular synchronism/electronic cams for printing/packaging
      • Heavy Duty Infrastructure:Power plant DCS, substations & industrial water supply
      • Industrial Processing:Stable speed/torque for extruders, compressors & centrifuges
      This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
      Visual Check: Ensure no cables are pinched and all boards are seated straight.
      Power Up: Reconnect the auxiliary 24V power. The drive should recognize the newly added hardware.
      Parameterization: You may need to perform a "Power Definition" (e.g., setting P060 = 8) or use DriveMonitor to configure the newly installed cards so the system knows how to communicate through the LBA.
