Technical specifications for A5F00133580-014 C98043-A7100
-
Product ModelA5F00133580-014 C98043-A7100
-
Product ParametersDRIVE BOARD
-
Tariff Code8537101190
-
Country of originGERMANY
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size18.5x14.5x3.5cm
-
ManufacturerSiemens
-
Weight0.2 kg
-
Serial InterfaceRS232 / RS485
-
Connector Type9-Pin D-Sub Connector
-
Power Supply24 V DC
-
Electronics Power2-phase 380–480 V AC
-
Operating Temperature0°C to +60°C
-
Storage Temperature-40°C to +70°C
-
Relative Humidity<95% (non-condensing)
Description
The SIEMENS A5F00133580-014 / C98043-A7100 is the Control Unit Digital (CUD) mainboard — the central intelligence and control core of Siemens' SINAMICS DCM and SIMOREG DC-MASTER 6RA80 series DC converters. This advanced drive control board serves as the primary controller card, control plate, and CPU board, orchestrating all motor control, communication, and protection functions for DC drive systems ranging from 15 A to 3,000 A rated armature current.
The SIEMENS A5F00133580-014 C98043-A7100 Drive Board is an industrial drive control board used within SINAMICS DCM and related DC drive systems. The board functions as the primary control and communication platform for drive regulation, signal processing, monitoring, diagnostics, and field interface management. It serves as a controller card and control plate, coordinating drive operation and communication between the power section, operator interfaces, and automation networks.
The SIEMENS A5F00133580-014 C98043-A7100 Drive Board is an industrial drive control board used within SINAMICS DCM and related DC drive systems. The board functions as the primary control and communication platform for drive regulation, signal processing, monitoring, diagnostics, and field interface management. It serves as a controller card and control plate, coordinating drive operation and communication between the power section, operator interfaces, and automation networks.
Alternative Names
A5F00133580-014
C98043-A7100
C98O43-A71OO
C98043-A7I00
A5F00133580 014
A5FOO13358O-O14
A5F00I33580-0I4
Information
Overview
Manuals
Application Notes
Product Applications
Safety and Pre-Installation Setup
Features:
- 9-pin D-Sub interface
- Controller card architecture
- RS232 and RS485 communication
- Analog and digital I/O processing
- Operator panel connectivity
At its heart, the CUD board implements a powerful embedded microprocessor running Siemens' proprietary closed-loop control firmware, delivering precise speed, torque, current, and field current regulation for DC motors. The board supports sophisticated control strategies including armature voltage control, field weakening (EMF control), and torque limiting, making it suitable for the most demanding industrial applications such as rolling mills, paper machines, cranes, extruders, and test stands.
The A5F00133580-014 C98043-A7100 SIEMENS DRIVE BOARD may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS A5F00133580-014 C98043-A7100 DRIVE BOARD Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ESD Precautions: Protect the board from Electrostatic Discharge (ESD). All personnel must use grounded wrist straps when handling the circuit board.
De-energize Equipment: Before plugging, unplugging, or servicing the A5F00133580-014, ensure the main drive system is fully isolated from the power supply, and allow sufficient discharge time for internal capacitors.
- Metal Rolling Mills:Counteracts voltage drops from slab impact
- Heavy-Duty Polymer Extruders:High-torque low-speed screw control
- Industrial Centrifuges & Mixers:Safe high-inertia rotational ramp control
- Paper, Film, & Foil Machines:Micro-tension balancing for miles of material
- Textile & Wire-Drawing Blocks:Syncs spooling speeds as radius changes
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Lockout/Tagout (LOTO): Isolate and lock out all AC main power lines feeding into the converter power unit. Verify zero voltage across all input and armature terminals before opening the chassis panel.
ESD Protections: Wear a grounded wrist strap or operate on a conductive static-safe mat. The components on both sides of the A5F00133580 board are highly sensitive to electrostatic discharge.
Firmware Backup: If replacing a functioning board, backup the parameter tree using a Siemens memory card or the STARTER software utility tool.
Technical notes
The board's comprehensive I/O capabilities are accessed through connector board C98043-A7125, providing multiple analog inputs/outputs (±10 V, 0–10 V, 4–20 mA), extensive digital I/O, incremental encoder feedback, analog tachometer input (up to ±270 V with 14-bit resolution), and temperature sensor interfaces for PT100/PT1000/KTY sensors. A potential-free relay output (XR1) controls the line contactor, while a dedicated E-STOP safety input (XS1) ensures compliance with machinery safety standards.
FAQs
-
What equipment is this board typically used in?
+This specific type of CUD board is primarily used as a central control and communication module for heavy-duty DC drives and converters, such as the Siemens SIMOREG DC Master. -
Are these boards plug-and-play, or do they require configuration?
+They require configuration. Because they are the brain of the drive unit, replacement CUD boards typically need to be parametrized to match your specific motor and operational specifications. You will likely need to use the Siemens parameter toolset to upload the backup parameters from the old board to the new one. -
What is the function of this board?
+It serves as a core drive controller card and motherboard. It handles high-efficiency signal processing, microprocessor-based automation, and links the external ports (such as 9-pin D-sub connectors and Ethernet/network ports) to the main DC converter unit. -
What are its electrical ratings?
+The board interfaces natively with standard industrial control platforms, operating primarily on a 24 V DC input voltage for its control electronics.
