PRODUCT DESCRIPTION
7MH4910-0AA01 Electronic weighing measurement module
Siemens 7MH4910-0AA01 is the SIWAREX CS weighing module for compatible SIMATIC distributed automation. It connects documented strain-gauge load cells for configured industrial weighing and material-dosing tasks.
The module supplies 6 V load-cell excitation and measures bridge signals in the specified 1, 2 or 4 mV/V ranges. Its 50 Hz measurement refresh, digital filtering and calibration settings support the engineered weighing function. Bridge resistance, cable length and legal-calibration requirements must match the applicable SIWAREX configuration.
The module supplies 6 V load-cell excitation and measures bridge signals in the specified 1, 2 or 4 mV/V ranges. Its 50 Hz measurement refresh, digital filtering and calibration settings support the engineered weighing function. Bridge resistance, cable length and legal-calibration requirements must match the applicable SIWAREX configuration.
BEFORE YOU BUY
Confirm the complete electronic weighing measurement module
ACTUAL APPLICATIONS
Application context for 7MH4910-0AA01
Siemens 7MH4910-0AA01 is the SIWAREX CS weighing module for compatible SIMATIC distributed automation. It serves compatible automation in food and beverage, chemical processing, logistics. Suitable use requires the documented companion hardware, electrical connections and configured production process.
-
01 · FOOD & BEVERAGE
Food Processing and Industrial Beverage Production
Food Processing and PackagingBeverage Production and Bottling -
02 · CHEMICAL PROCESSING
Chemical Production and Industrial Batch Processing
Industrial Chemical ManufacturingChemical Batch Process Production -
03 · LOGISTICS
Industrial Logistics and Material Handling
Bulk Material Transfer WeighingProduction Material Inventory Weighing
Technical specifications for 7MH4910-0AA01
-
Product Model7MH4910-0AA01
-
Product ParametersElectronic weighing measurement module
-
In stock7 units
-
ManufacturerSiemens
-
Supply voltage range20.4 to 28.8 V DC
-
Maximum supply current150 mA
-
Maximum power loss5 W
-
Backplane currentLess than 10 mA
-
Measurement accuracy0.05% or better
-
Measurement refresh50 Hz
-
Resolution65535 parts
-
Bridge sensitivity ranges0 to 1, 2 or 4 mV/V
-
Load-cell excitation6 V, 68 mA
-
Internally supplied bridge resistance87 to 4010 Ω
-
Externally supplied bridge resistance40 to 4010 Ω
-
Maximum load-cell cable1000 m; 500 m for legal calibration
-
Minimum calibration signal1.5 µV/e
-
Common-mode rejection120 dB at 50 Hz
-
Low-pass filter range0.05 to 5 Hz
View all additional
Alternative Names
7MH4910-0AA01
SIWAREX CS Electronic weighing measurement module
CS 20.4 to 28.8 V DC supply voltage range
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM INTEGRATION
Integrate 7MH4910-0AA01 electronic weighing measurement module
Siemens 7MH4910-0AA01 is the SIWAREX CS weighing module for compatible SIMATIC distributed automation. It connects documented strain-gauge load cells for configured industrial weighing and material-dosing tasks.
Compare supply voltage range (20.4 to 28.8 V DC), maximum supply current (150 mA) and maximum power loss (5 W) with the installed SIWAREX CS configuration. Match the supply connections and documented companion hardware before connection.
Use the applicable SIWAREX CS instructions for wiring and commissioning. Test the affected functions of 7MH4910-0AA01, review its status indications and record the accepted settings with the equipment documentation.
Features:
- Supply voltage range: 20.4 to 28.8 V DC
- Maximum supply current: 150 mA
- Maximum power loss: 5 W
The 7MH4910-0AA01 electronic weighing measurement module requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify 7MH4910-0AA01 electronic weighing measurement module
Replace 7MH4910-0AA01 only after matching its complete article, SIWAREX CS role and installed interface configuration. Related order numbers do not establish interchangeability.
Record the existing electronic weighing measurement module connections and preserve the configured SIWAREX CS settings before removal. Photograph connector keying, cable labels and the supplied article identification.
After fitting the verified 7MH4910-0AA01, restore the documented settings and test the affected functions at a safe operating point. Retain its receiving inspection and functional acceptance results with the asset record.
Features:
- Supply voltage range: 20.4 to 28.8 V DC
- Maximum supply current: 150 mA
- Maximum power loss: 5 W
The 7MH4910-0AA01 electronic weighing measurement module requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the 7MH4910-0AA01 electronic weighing measurement module must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size3 × 8 × 5 cm
-
Shipping weight0.08kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8538900000
-
OriginGermany
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 7MH4910-0AA01
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Which load-cell signal ranges are selectable in SIWAREX CS?
The documented ranges are 0 to 1, 2 or 4 mV/V. -
What excitation is supplied to the weighing bridge?
The module provides 6 V excitation with up to 68 mA according to the documented bridge limits. -
How frequently is the weighing value refreshed?
The specified measurement refresh frequency is 50 Hz. -
What resistance range applies to an internally excited bridge?
The internal-supply bridge-resistance range is 87 to 4010 Ω. -
Is the maximum cable length identical for legal calibration?
No. The documented maximum is 1000 m generally and 500 m for legal calibration. -
What low-pass filter range is configurable?
The specified low-pass range is 0.05 to 5 Hz. -
Which scale data should accompany a SIWAREX CS spare inquiry?
Include load-cell sensitivity, bridge resistance, cable length and the existing calibration configuration. -
What should purchasing verify with a CS weighing-module delivery?
Check the 0AA01 article, load-cell terminal arrangement and the documented calibration requirements.
