Technical specifications for 6DD1688-1AB0
-
Product Model6DD1688-1AB0
-
Product ParametersSIMADYN D INTERFACE SUBMODULE
-
Tariff Code8537101190
-
Country of originGERMANY
-
Place of shipmentXiamen, China
-
Estimated Shipping Size5x1.8x1cm
-
ManufacturerSiemens
-
Weight0.01 kg
-
Power Supply+5 V DC
-
Current Draw80 mA
-
Interface1 × RS-485
-
Baud Rate300 – 19 200 bit/s
-
Isolation1000 V DC port-to-ground
-
Operating Temperature0 … +60 °C (rack inlet air)
-
Storage Temperature–40 … +85 °C
-
Humidity5 – 95 % RH non-condensing
Description
6DD1688-1AB0
SIMADYN D
INTERFACE SUBMODULE
SS2 SERIAL INBTERFACE V.24
SIMADYN D
INTERFACE SUBMODULE
SS2 SERIAL INBTERFACE V.24
Information
Overview
Manuals
Technical notes
Product Applications
Installation Procedure
Features:
- Serial interfaces
- 25-pin sub-D plug connector X01
- 20 mA (TTY) or as V24 (RS232) interface
The 6DD1688-1AB0 Siemens INTERFACE SUBMODULE SS2 SERIAL INBTERFACE may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6DD1688-1AB0 INTERFACE SUBMODULE SS2 SERIAL INBTERFACE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Siemens 6DD1688-1AB0 (also known as the SS2) is an interface sub-module used within the Siemens SIMADYN D digital control system. It functions as a serial communications module that provides an RS-232 (V.24) connection, often used to equip communications boards (like the SS4) with an extended serial interface.Typically plugs directly onto processor modules (e.g., PT20 or PS16) to facilitate programming, diagnostics, or external serial peripheral communication.
- Metal Processing: Rolling mills and continuous casting plants
- Energy & Power: Line-commutated converter controls and power distribution systems
- Mining & Material Handling: Heavy-load conveyor and hoisting drives
- Chemical & Process Engineering: High-precision, closed-loop process control
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Alignment: Locate the 40-pin socket (typically X51) on your carrier board (e.g., SS4 communication module or PM16/PG16/PT20 processor boards).Orientation: Ensure the recess/notch on the SS2 submodule aligns with the marking on the carrier board's socket (Pin 1 is marked with a point).Safety: Always follow Electrostatic Discharge (ESD) guidelines. The human body must be discharged before touching the board.
