- 6ES7288-5DT04-0AA0
In Stock
Ships by Tuesday, August 25
Fast Shipping Available
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6ES7288-5DT04-0AA0
-
Product Model6ES7288-5DT04-0AA0
-
Spare ModelSIMATIC S7-200 SMART SB DT04
-
Product ParametersCompact digital I/O board
-
Tariff Code85389091
-
Country of originChina
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size3.5 x 5.2 x 1.6 cm
-
ManufacturerSiemens
-
Weight0.02 kg
-
Product familySIMATIC S7-200 SMART
-
Board designationSB DT04
-
Digital inputs2 sink inputs
-
Input rating24 V DC at 4 mA nominal
-
Digital outputs2 sourcing MOSFET outputs
-
Output voltage20.4 to 28.8 V DC
-
Rated output current0.5 A per point
-
Switching delay2 µs on, 10 µs off maximum
-
Power dissipation1.0 W
-
Degree of protectionIP20
Description
Siemens 6ES7288-5DT04-0AA0 is a SIMATIC S7-200 SMART SB DT04 digital signal board with two 24 V DC digital inputs and two sourcing transistor outputs. It expands a compatible CPU without requiring a full-width external expansion module.
Information
Overview
Manuals
Product Applications
Compatibility
Lifecycle & Replacement
Features:
- Product family: SIMATIC S7-200 SMART
- Board designation: SB DT04
- Digital inputs: 2 sink inputs
- Input rating: 24 V DC at 4 mA nominal
- Digital outputs: 2 sourcing MOSFET outputs
The board uses individually selectable input filter times and solid-state MOSFET outputs rated for 20.4 to 28.8 V DC. It dissipates approximately 1.0 W and must be wired through the specified X19 connector with correct field power, common reference, load protection, and project configuration.
6ES7288-5DT04-0AA0 Siemens: Use only with a compatible SIMATIC S7-200 SMART assembly and verify wiring, power, project configuration, firmware requirements, and controlled Siemens documentation before commissioning.
Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 digital input/output signal board Manuals, Datasheets, Official Documents, Links
- Preview Data Sheet PDF
- Preview Manufacturer's Manual PDF
- View Siemens SIMATIC S7 Products
- View All Siemens Products
Important Notice: Amikon PDF documents are independent reference materials prepared from verified Siemens sources. Use the current controlled Siemens documentation for installation and commissioning. Accessories, manuals, cables, software, certificates, and other items are not included with this equipment unless listed in the stock item description.
- Local sensor status acquisition
- Compact actuator command output
- Machine interlock signal processing
- Alarm contact monitoring and indication
- Auxiliary digital control point expansion
These applications reflect the documented functional role of the SB DT04 within SIMATIC S7-200 SMART automation systems. Final suitability depends on the configured CPU, electrical interface, field wiring, firmware, project settings, environmental conditions, and controlled Siemens instructions.
Siemens 6ES7288-5DT04-0AA0 is intended for a compatible SIMATIC S7-200 SMART system and must be installed in the correct CPU signal-board slot. Confirm the exact article number, CPU model, firmware level, available power budget, mechanical space, terminal hardware, and STEP 7-Micro/WIN SMART configuration before installation.
Do not substitute this product solely by channel count or physical size. Match the SB DT04 function, 2 sink inputs, electrical ranges or network role, connector and wiring arrangement, diagnostics, isolation, current limits, environmental rating, and project parameters.
Siemens documentation identifies 6ES7288-5DT04-0AA0 as the SIMATIC S7-200 SMART SB DT04 digital input/output signal board. Confirm current ordering availability, product lifecycle status, firmware support, certificates, and delivery information with Siemens when procuring the exact article number.
For replacement, preserve the complete article number and compare CPU compatibility, firmware, slot type, channel or interface function, power consumption, terminal assignment, electrical limits, diagnostics, mechanical dimensions, and project configuration. Back up the program and hardware configuration before exchanging the module or signal board.
Alternative Names
Siemens 6ES7288-5DT04-0AA0
SIMATIC S7-200 SMART SB DT04
SB DT04 digital input/output signal board
Technical notes
Verify X19 pin assignment, 24 V DC field supply, sink-input wiring, sourcing-output load polarity, current limits, external load protection, input filtering, common reference, and CPU signal-board configuration.
FAQs
-
How many I/O points does SB DT04 add?
+It adds two 24 V DC digital inputs and two sourcing transistor outputs. -
What is the output voltage range?
+The solid-state outputs operate from 20.4 to 28.8 V DC. -
What current can each output switch?
+The official specification rates each output point at up to 0.5 A. -
Are the output channels overload protected?
+No internal overload protection is specified, so the external circuit must be protected correctly. -
How is the board connected?
+Field signals and 24 V DC power connect through the X19 signal-board connector.
