Siemens 6ES7336-1HE00-0AB0
· Product image is representative; revision or series may vary. Contact us to request a specific version.
Ships by Friday, November 20

6ES7336-1HE00-0AB0

Fail-Safe Analog Input Module

Shipping Information

  • For inventory products, we support same day shipping upon payment.
  • For urgent needs, we offer same-day shipping on most items for orders placed before 2:00 PM UTC+8 Simply mention your preferred next-day shipping when place the order, and your order will be prioritized to minimize downtime.
  • For indent items, typical turnaround is 1-3 weeks, depending on parts availability and scarcity.
Customs & Documentation
We prepare clear, order-specific documentation for every international shipment, including the commercial invoice, packing list and available product or compliance documents. Before dispatch, our logistics team confirms the consignee details, declared value, shipping terms and destination requirements with you. Tracking information is provided after shipment, helping your team prepare for import clearance with confidence.
Documents checked before dispatch · Shipment details confirmed · Global tracking provided
Payment
Payment is by bank wire only in RMB/CNY, GBP, EUR or USD. Amikon does not accept credit cards or provide credit terms. Cleared payment is required before shipment unless the written quotation expressly states otherwise.
Product Condition
Factory New These are new and current items that are procured directly from the manufacturer.
New In Sealed Package Parts are new. They have not been used and still have their original package seal intact.
New in Original Package These parts are new. The packages were not originally sealed by their original manufacturer.
Quantity
Mobile *
Country/Region *
E-mail *
Company
Content *
(gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Amikong please read our privacy policy.
  • 20+

    years in automation
  • ISO 9001

    certified quality system
  • 12 months

    amikon warranty
  • 2-hour reply

    from your account manager
  • Success Story

    solutions in action
PRODUCT DESCRIPTION

Analog acquisition with distinct standard and safety measurement modes

Siemens 6ES7336-1HE00-0AB0 is an SM 336 analog input module supporting standard and safety operation. It provides six current inputs, while standard-mode voltage measurement is available on four channels. Safety operation uses the documented 4 to 20 mA measurement arrangements.

The module provides sensor-supply monitoring, group-fault indication and configurable diagnostic interrupts. Measurement resolution is thirteen bits plus sign. Safety performance depends on sensor suitability, wiring and evaluation configuration; channel isolation and supply arrangements must follow this exact module's documented limitations.
ACTUAL APPLICATIONS

Where 6ES7336-1HE00-0AB0 Fits Across Industrial Sectors

Industrial uses span production, processing and utility operations, subject to compatible configuration and the applicable engineering requirements.
  • 01 · FOOD & BEVERAGE

    Food Processing and Beverage Production for Consumer Markets

    Food preparation and processing for packaged consumer product supply.Commercial beverage manufacturing for retail and hospitality market distribution.
  • 02 · TEXTILE MANUFACTURING

    Textile Material Production and Commercial Fabric Finishing

    Fiber processing and yarn manufacturing for industrial textile production.Fabric production and finishing for commercial textile product supply.
  • 03 · WATER & WASTEWATER

    Public Water Supply and Industrial Wastewater Treatment

    Treatment and distribution of drinking water for public supply.Collection and processing of wastewater from communities and industries.

Technical specifications for 6ES7336-1HE00-0AB0

  • Product Model
    6ES7336-1HE00-0AB0
  • Spare Model
    SM336
  • Product Parameters
    Fail-Safe Analog Input Module
  • Manufacturer
    Siemens
  • Input arrangement
    6 current inputs; up to 4 voltage inputs in standard mode
  • Standard-mode ranges
    0-20 mA, 4-20 mA, 0-10 V
  • Safety-mode range
    4-20 mA
  • Resolution
    13 bits plus sign, including overrange
  • Integration time
    20 ms at 50 Hz; 16.66 ms at 60 Hz
  • Rated electronics supply
    24 V DC, reverse-polarity protected
  • Backplane current
    90 mA maximum
  • L+ current
    160 mA typical
  • Typical power loss
    4.25 W
  • Input resistance
    107 ohm current; 59 kohm voltage
  • Operational error
    ±0.48% of input range across temperature range
  • Basic error at 25°C
    ±0.40% of input range
  • Shielded cable length
    200 m documented maximum
  • Front connector
    40 pins
  • Channel isolation
    No channel-to-channel isolation; electronics-supply isolation only with external sensor supply
View all additional
SYSTEM & REPLACEMENT CHECK

Information needed before ordering

Three direct checks to secure your system integration and minimize ordering risks.

Information

System integration Replacement check Manuals & support
SM 336 ANALOG SAFETY INPUT

Mode-specific analog acquisition with documented sensor evaluation

Use the exact current or voltage terminal arrangement. Standard mode allows six current measurements or up to four voltage measurements with the remaining channels used for current; safety mode uses 4-20 mA.
Coordinate sensor supply with the documented isolation and common-mode limits. Internal supply is monitored, while external supply stability and grounding require the additional prescribed safeguards.
Select the safety case according to qualified sensors and evaluation requirements. Match address-switch configuration, monitoring time and any discrepancy analysis to the approved safety program.

Features:

  • Mode-specific measurement ranges
  • Monitored sensor supply
  • Configured sensor evaluation
The Siemens 6ES7336-1HE00-0AB0 requires the documented hardware configuration, installation conditions and interface arrangement to be verified before system integration and commissioning.
INTERCHANGEABILITY

Verify the complete replacement identity before commissioning

Confirm the complete 1HE00 identity and the product revision covered by the manual. The 4GE00 HART module has different dimensions, connection and measurement characteristics.
Capture operating mode, range, sensor supply, MANA wiring, address switch and safety evaluation parameters. Keep the same validated field-sensor arrangement.
Replacement interrupts fail-safe communication. Use the documented host procedure and complete reintegration and signal verification; do not describe a module swap alone as revalidation of the entire safety function.

Features:

  • Exact revision verification
  • Safety-configuration capture
  • Controlled reintegration
The Siemens 6ES7336-1HE00-0AB0 requires replacement verification based on its complete order number, installed hardware, signal configuration and project documentation.
DOCUMENTATION STATUS

Browse the Manuals, Datasheets, Official Documents, Links

Important Notice: Official documents are provided through manufacturer links. Accessories, manuals, cables, calibration data, software, certificates, and other items are not included with this equipment unless listed in the stock item description.

Features:

  • Exact-model manufacturer data and relevant original manual pages
  • Standard and safety current/voltage connections, sensor-supply safeguards, MANA/common-mode limits, historical PROFIsafe addressing and qualified sensor evaluation.
  • Accessories and supplied documentation follow the written quotation
Documentation for the Siemens 6ES7336-1HE00-0AB0 includes an independent technical summary and selected original manufacturer pages; check the applicable document edition against the delivered product and approved installation documentation.

Important notice

Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION

Commercial terms without hidden steps

Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
  • 01

    Shipping & delivery

    Dispatch
    Eligible stock: same / next day
    Carriers
    DHL, FedEx or UPS
    Ship from
    Xiamen, China
    Packed size
    Confirm final packed dimensions
    Shipping weight
    Confirm final packed weight
  • 02

    Payment & customs

    Payment
    Bank transfer (T/T)
    Currencies
    USD · EUR · GBP · RMB
    Credit cards
    Not accepted
    HS reference
    8538900000
    Origin
    Confirm supplied-unit origin
  • 03

    Warranty & returns

    Warranty
    12 months from AMIKON
    Inspection
    Label, condition and packing checks
    Returns
    Prior RMA authorisation required
    Compatibility
    Confirm before order
    OEM warranty
    Does not apply
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
  • Part checked

    Full suffix recorded
  • Condition checked

    Label and appearance
  • Packing checked

    Antistatic protection
  • Tracking supplied

    Established couriers
  • Sandy Lin

    Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS

Questions buyers ask about 6ES7336-1HE00-0AB0

Direct answers about identity, compatibility, stock, warranty, payment and shipping.
  • Are voltage measurements available in safety mode?

    No. The exact chapter limits safety operation to 4-20 mA. The 0-10 V and 0-20 mA ranges are standard-mode options; voltage measurement is limited to channels 0-3.
  • Is resolution thirteen or fourteen bits?

    The detailed manual specifies 13 bits plus sign, including overrange. A fourteen-bit headline can count the sign bit; it must not imply fourteen magnitude bits.
  • Are all input channels electrically isolated from one another?

    No. Isolation from the backplane is documented, but channel-to-channel isolation is not. Isolation from electronics supply applies only with externally powered sensors.
  • Does the module bridge sensor-supply voltage dips?

    No. The manual warns that dips affect sensor supply and can falsify values. Use the specified supply provisions or appropriately supported transducer measures; external supply stability also requires the safety-related assessment.
  • Can the highest safety level be assumed from the module alone?

    No. The manual conditions the achieved level on sensor quality, proof-test interval and configuration. Some schemes use qualified single sensors; others require redundant sensors, opposite channels and discrepancy evaluation.
  • How is the PROFIsafe address set on this historical module?

    This module uses the start-address-based method in section 4.3.2: configure safety mode and set the corresponding rear switch before installation. Do not transfer the newer module addressing method without checking the exact instructions.
