SIMADYN D OPERATOR PANEL 0P1
SIMADYN D OP2
Operator Panel Keypad
1 x RS-485 Interface (USS)
1 x Serial Printer Interface (V.24/TTY)
24V DC Power
for use with SIMOVERT MASTERDRIVES
and SIMOREG DC MASTER Drives
Input Type: Digital (24 V DC)
Signal Voltage Range: 0-30 V DC
Input Logic: TTL/CMOS-compatible
Isolation: Optocoupler isolation (≤500 V)
Output Type: Transistor (24 V DC)
Switching Capacity: Up to 2 A per channe
SIMADYN D T400 with axle winder with min.
Max Axles (Drives):4 axes per module
Cycle Time:≤1 ms (deterministic)
Encoder Interfaces:2x (HTL/TTL, sin/cos) per axis
Supply Voltage:24 V DC ±5%
Power Consumption:8 W
Min/Max Diameter Ratio:1:50
