Technical specifications for GSV142 244-142-000-103
-
Product ModelGSV142 244-142-000-103
-
Product ParametersTransmitter Power Supply
-
Tariff Code8537101190
-
Country of originsweden
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size7.8x5.3x4.8cm
-
ManufacturerVibro-Meter
-
Weight0.25 kg
-
Product FamilyGSV14x Series
-
Input Voltage24 VDC Nominal
-
Operating Temperature–20°C to +60°C
-
Storage Temperature–25°C to +70°C
-
Relative Humidity95% max. non-condensing
Description
The Vibro-Meter GSV142 244-142-000-103 is a transmitter power supply and intrinsic safety barrier unit designed for use with Vibro-Meter proximity measurement systems. The module supplies operating power to compatible signal conditioners while providing the isolation and protection required for installations in hazardous and potentially explosive environments.
A primary function of the GSV142 is to serve as an intrinsic safety barrier. When proximity transducer systems are installed in hazardous areas, the GSV14x series limits energy transfer to the field devices and helps ensure compliance with applicable explosion-protection requirements. Installation manuals for Vibro-Meter proximity systems specify the use of a GSV14x power supply and safety barrier unit in potentially explosive atmospheres
A primary function of the GSV142 is to serve as an intrinsic safety barrier. When proximity transducer systems are installed in hazardous areas, the GSV14x series limits energy transfer to the field devices and helps ensure compliance with applicable explosion-protection requirements. Installation manuals for Vibro-Meter proximity systems specify the use of a GSV14x power supply and safety barrier unit in potentially explosive atmospheres
Alternative Names
GSV 142 244-142-000-103
GSV142 244 142 000 103
GSV 142 244-142-000-103
GSV142 244-142-OOO-1O3
GSV I42 244-I42-000-I03
GSV142 244 142 OOO 1O3
GSV I42 244 I42 000 I03
Information
Overview
Manuals
Application Notes
Product Applications
Wiring and Grounding
Features:
- Transmitter power supply module
- Intrinsic safety barrier function
- Compatible with IQS signal conditioners
- Hazardous-area application support
The unit consists of three functional modules: a power supply block for main power conversion and regulation, an intrinsically safe power supply component with Zener diode safety barriers, and a measurement current circuit also isolated by safety barriers. The intrinsically safe output circuit provides 27.5 V at 75 mA with a maximum power of 820 mW, suitable for powering intrinsically safe transmitters. The measurement current circuit provides 21 V at 50 mA with 270 mW maximum power for signal transmission.
The GSV142 244-142-000-103 Vibro-Meter Transmitter Power Supply may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Vibro-Meter GSV142 244-142-000-103 Transmitter Power Supply Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The module is designed for industrial machinery monitoring applications including steam turbines, gas turbines, compressors, generators, pumps, and other rotating equipment. It supports continuous operation in machinery protection and condition monitoring systems where reliable power delivery and signal integrity are essential.
The GSV142 is frequently used in power generation facilities, oil and gas processing plants, petrochemical installations, refineries, and other industrial environments where proximity probe measurements are required for shaft vibration, shaft position, eccentricity, and differential expansion monitoring
- Gas Turbine Combustor Monitoring:Tracks dynamic pressure pulsations to prevent acoustic fatigue
- Power Generation Facilities:Nuclear/hydro/thermal: safeguards high-vibration zones
- Oil Refining and Petrochemical Processing:Tracks rapid pressure fluctuations in compressors/pumps
- Automated Assembly Lines:Step-by-step diagnostics & cycle tracking for auto/electronics
- Hazardous Industrial Zones:Class I Div2: oil/gas, chemical mixers & paint booths
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Intrinsic Safety Segregation: Always route and terminate intrinsically safe (IS) wires and non-IS wires in separate cable trays or conduits. Maintain a minimum distance of 50 mm between IS and non-IS conductors.
Shielding and Grounding: Shielded cables must be used for all measurement signals. Connect the cable shield to a clean, dedicated instrument ground (earth) on the safe side, avoiding ground loops.
Connections: Follow the terminal pinout for the GSV142 to correctly connect the sensor, monitoring system (e.g., Vibro-meter VM600 or VibroSmart), and the 24 VDC power.
Technical notes
A primary function of the GSV142 is to serve as an intrinsic safety barrier. When proximity transducer systems are installed in hazardous areas, the GSV14x series limits energy transfer to the field devices and helps ensure compliance with applicable explosion-protection requirements. Installation manuals for Vibro-Meter proximity systems specify the use of a GSV14x power supply and safety barrier unit in potentially explosive atmospheres.
FAQs
-
What is the primary purpose of the GSV142?
+The GSV142 serves as a dual-channel vibration monitor. It continuously tracks either absolute bearing vibration (velocity/acceleration) or relative shaft displacement. It acts as a safety barrier by triggering machine shutdowns if vibrations exceed safe limits. -
How do I configure the measurement ranges or sensor types?
+The configuration is entirely hardware-based. You adjust the parameters using internal DIP switches located on the circuit board. This removes the need for external software or laptop calibration during basic setups. -
What is the supply voltage for the GSV142?
+The GSV142 operates on 24 V DC power. -
How does it differ from the GSV140 and GSV141 variants?
+The core distinction lies entirely in the input mains voltage. The GSV140 requires 230 V AC, the GSV141 requires 110 V AC, and the GSV142 runs on 24 V CC (DC).
