ABB Drives

Control unit

Processor:32-bit
I/O Capacity Up to 1,024 I/O points
Voltage: +5V DC
Consumption: 15 W
Battery Backup:BCL003 battery module

Industrial Circuit Board

Power Supply:24V DC
Analog Inputs: 4-20mA
Digital I/O: Opto-isolated inputs
Communication: Possible RS-485/Modbus
Type: Industrial control

Pulse Amplification Board

Input Voltage Range:10mV - 30V AC/DC
Input Impedance:100kΩ (typical)
Output Signal:24V transistor / 0-20mA
Output Current:≤500mA (transistor), ≤20mA (analog)
Isolation Voltage:1500V AC
High-gain amplifier: 10-100x adjustable
Wide input range: 10mV to 30V pulses
Frequency response: DC to 500kHz
Isolated output: 24V PNP/NPN or 0-20mA

Control Board

Analog I/O update rate: 1 kHz
Digital I/O update rate: 10 ms
Standard range: -20°C to +60°C
Extended range: -40°C to +70°C
Power consumption: Max. 10W
Humidity: 5% to 95% RH
16-bit resolution for analog inputs/outputs

FIELD PROTECTION UNIT

Operating Time:<8ms for critical faults
Measurement Accuracy:±0.5% of reading
Sampling Rate:64 samples/cycle
Time Sync Accuracy:±1μs
Power Supply:48-125V DC or 90-264V AC
Power Consumption:15W typical
Isolation Voltage:2.5kV AC

Mini Contactor Relay

Rated Current (Ie):6A (AC-1)
Rated Voltage (Ue):230V AC / 24V DC
Breaking Capacity:3A @ 400V AC (AC-3)
Contact Material:Silver alloy (AgSnO₂)
Coil Voltage:24V DC / 48V DC / 110V AC / 230V AC (selectable)
Power Consumption:2.2W (DC) / 3.5VA (AC)
Operate Time:≤15ms (DC), ≤20ms (AC)
Release Time:≤10ms (DC), ≤15ms (AC)

IGBT Module

Voltage Ratings:1700 V
Current Ratings;450 A
Power Dissipation:2-3 kW
Switching Frequency Range: Up to 5-10 kHz
Isolation Voltage:2500-4000 V

GATE POWER UNIT

Model: KUC755 AE106
Order/Part Number: 3BHB005243R0106
Description: Gate Power Unit
Input Voltage: Typically 24V DC
Output Gate Drive Voltage: ±15V to ±20V
Output Current: Up to 5A peak
Isolation Voltage: ≥2500V AC

Converter Display Board

Supply Voltage: 24V DC
Power Consumption: <5W
Part Number: 3BHB006943R0002
Supported Languages: Multiple
Alternative Designation: UNS0885A-Z, V2
Description: Display and control interface board

Ethernet POWERLINK adapter module

Supply Voltage: 24V DC
Power Consumption: ≤5W
Isolation: 1500V AC
Cycle times :≤200 µs
Protocol: Ethernet POWERLINK

Processor board

Power Supply: 24V DC ±10%
Power Consumption: 15W typical
Isolation: 1500V AC
RAM: 512MB
Flash Memory: 128MB
Memory Card Slot: Supports PPD104 CF card
Ethernet Ports: 2x 10/100/1000 Mbps
Serial Port: 1x RS-232/485

Power Supply Board

3-phase: 380-500V AC
1-phase: 200-240V AC
Frequency Range: 47-63Hz
DC Bus Voltage: 510-620V DC
Rated Power: 11kW
Overload Capacity: 150% for 60 seconds
Inrush Current Protection: <25A for 10ms
Efficiency: >95%
Undervoltage Lockout: <300V DC input

POWER SUPPLY BOARD

Input Voltage Range:380-500V AC
Optional: 200-240V AC
Frequency Range: 47–63Hz
Inrush Current Protection: <30A
Output Voltage: 24V DC
Rated Current: 10A
Power Rating: 240W
Ripple Noise: <100mV peak-to-peak
Overload Capacity: 150% for 5 seconds

Motor Control Card

Supply Voltage: 24V DC ±10%
Power Consumption: 15W typical
Isolation: 2.5kV input-to-output
PWM Frequency: 2-16kHz
Analog Inputs:4 channels
Digital Inputs:8 channels
Power Range: 0.5-800kW
Max Motor Speed: 6000 rpm

CONTROL BOARD

CONTROL BOARD
230-500V
(64379143)
CPU: 32-bit RISC processor
Flash Memory: 32MB
Digital Inputs: 16 channels
Analog Inputs: 8 channels
Pulse Inputs: 2 channels
Power Supply: 24V DC ±10%
Power Consumption: 12W typical

Communication adapter

Ethernet connector
Fibre optic SPA-bus connectors
Auxiliary power supply connector
SPA TX and RX LEDs
LAN and diagnostic LEDs

Ethernet Adapter

Ethernet connector
LON/SPA bus FO connector (optional)
LON/SPA Rx LED4. LON/LAN service pin
LAN and diagnostic LEDs

F-series Extension Adapter

Voltage: 24V DC (±10%)
Consumption: 2.5W typical
Isolation: 1.5kV AC
PROFIBUS DP (up to 12Mbps)
Modbus RTU (RS485)
CANopen (optional)

Frequency Converter

Frequency (f):47.5 ... 63 Hz
Frame Size:R3
Input Voltage (Uin):380 … 480 V
Mounting Type:Wall-mounted_NO UNIT$
Output Current, Normal Use (In):45 A
Output Current, Heavy-Duty Use (IHD):38 A
Output Power, Normal Use (Pn):22 kW
Output Power, Heavy-Duty Use (PHD):18.5 kW

Interface board

Voltage: 24V DC
Consumption: 3.5W typical
Isolation: 1.5kV AC
PROFIBUS DP (up to 12Mbps)
Modbus RTU (RS485)
Node Capacity: Up to 124 devices
IEC 60870-5-101/104

Field Exciter Board

Field Voltage Output:50-300V DC
Field Current Rating:Up to 20A
Control Voltage:24V DC (±10%)
Isolation Voltage:2500V AC
Response Time:<10ms
Analog Inputs: 2x (0-10V/4-20mA) for field ref
Digital Inputs: 3x (24V DC) for enable/disable
Relay Outputs: 2x (5A @ 250V AC)

Frequency Converter

Power Range: 157A / 110kW (at 400V)
Input Voltage:3-phase 380-480V AC (±10%), 50/60Hz
Output Current:157A continuous
Overload Capacity:110% for 60s / 150% for 3s
Switching Frequency:1-16kHz (adjustable)
Efficiency:≥97% (at full load)
Analog Inputs: 2x (0-10V / 4-20mA)
Digital Inputs: 6x (24V DC)
Relay Outputs: 2x (5A @ 250V AC)

MEMORY BOARD

MEMORY BOARD
CIRCUIT BOARD
RESISTIVE NETWORK
YPR-104B

PC BOARD

PC BOARD
PULSE TRANSFORMER UNIT
CONTROL UNIT
YXU-173E

CIRCUIT BOARD

Memory 512MB DDR3
PWM Resolution 15-bit
Analog Inputs:8x (16-bit SAR ADC)
Digital I/O:16x (24V DC opto)
Encoder Interfaces:1x (A/B/Z + SSI)
Isolation Voltage:2500Vrms
Fieldbus:PROFIBUS DP-V1 (12Mbps)
Ethernet:10/100BASE-TX
