ABB

I/O Control Module

Digital Inputs: 24V DC
Analog Inputs: 4-20mA or 0-10V
Power Supply:24V DC
Operating Temperature Range:0°C to +60°C

CHARGING CONTROL BOARD

Input Voltage:380-480V
Charging Voltage Range:12V to 600V DC
Current Rating:10A to 100A
Operating Temperature Range:-10°C to +60°C
Storage Temperature:-20°C to +70°C

Quad Elephant Inverter Rectifier Power Board

DC Output:DC 500-800V
Current Rating:100A to 200A
Continuous Current Rating:150A
Switching Frequency:10-20 kHz
Storage Temperature:-20°C to +70°C
Operating Temperature Range:-10°C to +55°C

Programmable Logic Controller

Memory Size:642 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Analog Inputs:2
Analog Outputs:1
Number of Digital Inputs:6
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

KONE Elevator Pulse Encoder Interface Module

Power Supply: Typically 24 V DC
Max Input Frequency: Typically 100 kH
Input Voltage Level: Usually 5V or 24V
Operating Voltage Range: 18-30V DC
Operating Temperature: -10°C to +55°C
Storage Temperature: -20°C to +70°C

ANALOG IO EXTENSION

Supply Voltage:
Typically 24V DC or 48V DC
Voltage: 0-10 V, ±10 V, 0-5 V.
Current: 4-20 mA
Operating Temperature: Typically -10°C to +55°C
Storage Temperature: Around -40°C to +70°C

Interface Board

Supply Voltage:Likely 24V DC or 48V DC
Current Consumption:150 mA to 500 mA
Operating Temperature:  -10°C to +55°C
Storage Temperature: -40°C to +70°C

Control Panel 10.4

Memory Size User Data:256 MB
Memory Size User Program:256 MB
Memory Type User Data:Flash Disk
Memory Type User Program:DDR RAM
Power Consumption (@Pcons):24 W
Power Supply:24 (18 ... 30) V DC
Product Main Type:CP651
Product Name:Control Panels
Operation 0 ... +50 °C
Storage -20 ... +70 °C

Control Panel 5.7 TFT touch screen

Memory Size User Data:128 MB
Memory Size User Program:256 MB
Memory Type User Data:Flash Disk
Memory Type User Program:DDR RAM
Power Consumption (@Pcons):16.8 W
Power Supply:24 (18 ... 30) V DC
Product Main Type:CP630
Product Name:Control Panels

Control Panel

Memory Size User Data:256 MB
Memory Type User Data:Flash Disk
Memory Type User Program:DDR RAM
Power Consumption (@Pcons):24 W
Power Supply:24 (18 ... 30) V DC
Product Main Type:CP651
Product Name:Control Panels

DRIVE MOTION CONTROL

DRIVE MOTION CONTROL
4AMP
3PHASE
48-63HZ
480V

Frequency Converter

Standard: -10°C to +40°C
Extended: -20°C to +50°C
Storage Temperature Range:-40°C to +70°C
Humidity:5% to 95% non-condensing
Current Rating:Approximately 28 A

Inverter Memory Card

Memory Type: Flash memory
Memory Capacity: Typically, 4 GB
Operating Temperature: Typically, -20°C to +85°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95%

Central Processing Unit Module

Processor Type: 32-bit RISC processor
Program Memory: 4 MB
Data Memory: 2 MB
Backup Memory: 512 kB
1 x RJ45 (10/100 Mbps)
Power Supply Voltage: 24 V DC
Operating Temperature: -25°C to +70°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

Prog.Logic Controller

Memory Size:142 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Number of Digital Inputs:8
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

2-port Modbus/TCP adapter module

2 x RJ45 connectors
Data rates: 10/100 Mbps
Maximum Nodes: Up to 32 nodes
Power Supply Voltage: 24 V DC
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

Control Unit

Power Supply Voltage: 24 V DC ±10%
Power Consumption: Typically 5 W
RAM: 64 MB (typical)
Analog Outputs: 2 channels, 0-10 V or 4-20 mA
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

EtherNet/IP adapter module

Supports 10 Mbps and 100 Mbps
Maximum Nodes: Up to 64 nodes
Operating Voltage: 24 V DC ± 10%
Power Consumption: 2.5 W (typical)
Operating Temperature: -25°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

Control Panel 7 TFT touch screen

Operation 0 +50 °C
Storage -20  +70 °C
Memory Size User Data:128 MB
Memory Size User Program:256 MB
Memory Type User Data:Flash Disk
Memory Type User Program:DDR RAM
Power Consumption (@Pcons):16.8 W
Power Supply:24 (18 ... 30) V DC
Product Main Type:CP635
Product Name:Control Panels

PROFIBUS DP adapter module

Baud Rates Supported: 9.6 kbps to 12 Mbps
Communication Connector: 9-pin D-Sub
Operating Voltage: 24 V DC ± 10%
Power Consumption: Typically 2.5 W
Operating Temperature Range: -25°C to +60°C
Storage Temperature Range: -40°C to +85°C
Relative Humidity: 5% to 95%

CANopen interface Module

Operating Voltage: 24 V DC
Interface Type: CAN 2.0A and CAN 2.0B
Standard CAN: Up to 1 Mbps

Processor Module

Memory Size:642 kB
Memory Type User Data:RAM
Number of Digital Inputs:8
Number of Digital Outputs:6
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

EMC FILTER 3 PHAS

Type: 3-Phase EMC Filter
Rated Voltage: 480 VAC or 400 VAC
Rated Current: 16 A to 29 A
Frequency Range: 50 Hz to 60 Hz
Attenuation:150 kHz to 30 MHz
Operating Temperature Range: -25°C to +85°C
Storage Temperature Range: -40°C to +85°C

CVMI Board

Voltage Input Range:24 VDC or 110/220 VAC
Current Input: 1-10 A
Power Supply: 24 VDC or 48 VDC
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -40°C to +85°C

Interface Board

Operating Voltage:Typically 24V DC
Temperature Range:-20°C to 60
