ABB

Processor module

Memory Size:1008 kB
Memory Type User Data:RAM
Controller Processing Time:0.0002 ms
Number of Digital Inputs:6
Number of Digital Outputs:4
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Degree of Protection:IP20
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

pH/Redox (ORP) Sensor Assembly

pH Range: 0 to 14 pH
ORP Range:-1000 mV to +1000 mV
Accuracy:pH: ±0.2 pH

liquid-cooled inverter module

Voltage Rating: 400–690 VAC ±10%
Input Current: 1,100 A (maximum)
Frequency Range: 0–1000 Hz
Operating Temperature:-20°C to +50°C
Storage Temperature: -40°C to +70°C.
Humidity: 5% to 95% (non-condensing)

Analog Input/Output Module

Rated value 24 VDC
Max. ripple 5 %
Rated protection fuse on UP 10 A fast
Number of channels per module 8
nput signal voltage 24 VDC

Processor module

Series: AC500 PLC
Type: Central Processing Unit
Processor: 32-bit RISC processor.
Clock Speed: 400 MHz
RAM: 4 MB.
Flash Memory: 2 MB for user programs.
Backup Memory: 256 kB
Voltage Range: 24 VDC ±20%.
Power Consumption: 5 W

Central Processing Unit

Memory Size:142 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Analog Inputs:2
Analog Outputs:1
Number of Digital Inputs:6
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

Touch Screen

Screen Size: 5.7 inches .
Resolution: 640 x 480 pixels.
Display Type: TFT LCD with high brightness and contrast.
Touch Screen Type: Resistive touch technology for precise input.
Brightness: 350 cd/m².
Colors: 65,536 colors for high-quality visualization.
Viewing Angle: ±60°

PULSE AMPLIFIER BOARD

Voltage Rating:24V DC
Input Signal Type:24V
Operational Temperature Range: -20°C to +70°C
Part Number:61073027C

Drive Board

DRIVE BOARD
POWER INTERFACE BOARD
WITH ON-BOARD TRANSFORMER
RELAY OUTPUTS
(SDCS-PIN-F01A)

VVP-Board Coated

PC BOARD
OVVP-BOARD COATED
UB C717 BE101

Sample Gas Feed Unit

In operation: +5 to +45 °C
Storage and transport: –25 to +60 °C
 75 % year-round average
Input voltage 230 V AC or 115 V AC, 50 Hz or 60 Hz
Power consumption max. 185 VA
Sample gas pressure pabs = 70 to 105 kPa (0.7 to 1.05 bar)
Sample gas inlet temperature +10 to +50°C

HVD Board

Power Supply: 24 V DC
Communication Protocol:
Ethernet, Modbus TCP/IP
Operating Temperature Range:
-20°C to +60°C

DU/DT Filter

Input Voltage: 380–690 V AC, 3-phase
Rated Current: 65 A
Protection Rating: IP22

Control Board

Operating Voltage: 24V DC
Temperature Range: -20°C to +60°C
Humidity Range: 5% to 95%, non-condensing.

SERVO DRIVE

SERVO DRIVE
4AMPS
230VAC
50/60HZ

UNIVERSAL PROCESS CONTROLLER

CM303S0S0E0STD
UNIVERSAL PROCESS CONTROLLER
1/4 DIN
STANDARD VERSION WITH OPTIONS 1 AND 2
REPLACES C351/0000/STD

VERITRON POWER CONVERTER

Series: BBC
Type: Power Converter
Output Voltage:  24V DC
Power Rating:5kW

SwitchLine

220 V AC OETL
ZT 80 A220AC
1SCA022079R9050
OETLZT 80_/_ Un /R
110VAC/1000Ω, 230VAC/3900Ω
24VDC/48Ω, 48VDC/190Ω
60VDC/300Ω,110VDC/1000Ω
220VDC/3900Ω, U=0.7...1.1*Un
PDC=15 W, PAC = 30VA

CANopen adapter module

Power Supply:24V DC
Input/Output Voltage:24V DC
Operating Temperature Range:
-20°C to +60°C
Humidity:
5% to 95% relative humidity

PCB Card

Input Voltage: Typically 24V DC
Operating Temperature Range:  -20°C and 60°C
Storage Temperature:  -40°C to 85°C

Analog Input Module

Input Range: 0-10V (voltage),
4-20mA (current)
Resolution: 16-bit
Sampling Rate: 1000 samples per second per channel
Accuracy: ±0.1% of full scale
Isolation: 1500V isolation between channels and the system
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -40°C to +85°C
Power Supply Voltage: 24V DC
Power Consumption: Maximum 5W

Drive Board

Voltage Range:  24V DC
Operating Frequency: 50Hz or 60Hz
Operating Temperature Range: -10°C to +50°C
Storage Temperature Range: -20°C to +70°C

VOLTAGE INSERT CARD

Input Voltage Range: 24V DC
Output Voltage Range 24V DC, 48V DC
Operating Temperature Range
0°C to 60°C (32°F to 140°F)
Storage Temperature Range:
-20°C to 70°C (-4°F to 158°F).
Humidity Range:
5% to 95%, non-condensing.

Control Module

Series: 800xA
Input Voltage: 24 V DC
Power Consumption: Typically around 10 W
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5% to 95%, non-condensing

Terminator Box

General Information
Product ID:3BSE005881R1
ABB Type Designation:TX560
Catalog Description:TX560 Terminator
Long Description:Terminator Box
