HRC FUSE LINK

Fuselink
rated current 500A
size NH3
rated voltage 500VAC / 250VDC
utilization category gG
rated breaking capacity 120 kA (AC) / 80 (kA DC)

Binary Input Unit

Input Channels:16
Input Type:Dry Contact or 24V DC Sourcing
Voltage Range:19–30 V DC
Input Current:3–5 mA per channel
Logic Levels:"1" (ON): +15–30 V DC
"0" (OFF): 0–5 V DC
Response Time:≤ 2 ms (ON/OFF)
Overvoltage Protection:60 V DC (continuous), 75 V DC (1s)
Isolation:1500 V AC

UNITROL CARD

Input Voltage :24 V DC (±20%)
or 48 V DC (±20%)
Analog Inputs:6 channels
Digital Inputs:8 channels
Analog Outputs:4 channels
(0–20 mA / 4–20 mA)
Digital Outputs:6 channels
Processing Speed:32-bit DSP
Communication:RS-485 Modbus RTU, CANopen

I/O Module Adaptor

Data Transfer Rate:Up to 12 Mbps (PROFIBUS)
Isolation Voltage:1.5 kV AC
Power Supply:24 V DC
Power Consumption:≤ 1.2 W

Regen supply module

MODULE
PLC MODULE
16 CHANNEL
ANALOG OUTPUT

Binary I/O Module

Input Channels:16x Binary Inputs
Output Channels:10x Binary Outputs
Contact Rating (Outputs):5A @ 250V AC/30V DC
Input Voltage Ranges:24/48/110/125 V DC
Input Threshold (ON):>70% of rated voltage
Response Time:<10 ms
Isolation Voltage:2.5 kV AC
Power Consumption:≤ 5 W

Fiber Optic Remote I/O Termination Unit

Isolation Voltage:1.5 kV AC
Power Supply:24 V DC (±15%), 5 W typical
Redundancy:Dual fiber ports
Fiber Interface:2x ST/PC connectors
Data Rate:10 Mbps
Max. Distance:2 km

Turbine Auto Sync Module

Input Voltages:100–120V AC
Voltage Diff: ±0.5%
Slip Freq: ±0.05 Hz
Operating Voltage:24/48/125V DC
Response Time:<20 ms

Turbine Protection Module

Operating Voltage:24/48/125V DC (±20%)
Response Time:<20 ms
Speed Range:0–9999 RPM
Redundancy:2-out-of-3 (2oo3) voting logic
Overspeed Thresholds:2x Adjustable
Input Signals:3x Magnetic Pickups (MPU) / Proximity Sensors
Trip Outputs:3x Relay Contacts (NO/NC, 5A @ 250V AC)

Analog Control Station

Operating Voltage:24V DC (±10%), 3W typical
Accuracy:±0.5% of full scale
Resolution:0.1% (for bargraph display)
Update Rate:100 ms
Isolation: 1.5 kV AC
MODE Switch: Toggle MAN/AUTO/CAS

Drive Unit Drive Controller

Control Platform:32-bit RISC processor with FPGA logic
Control Methods:DTC , Scalar, Vector
I/O Capacity:16x DI
Operating Voltage:24 V DC (±10%)
Power Consumption:25 W (typical)
Memory:2 GB Flash (firmware/logs)


Controller Module

Model: KUC755AE117 / 3BHB005243R0117
Product Type: Controller Module
Power Supply Voltage: 24V DC
Operating Temperature: 0°C to +55°C
Storage Temperature: -20°C to +70°C
Humidity: Relative humidity 5% -95%

OVERVOLTAGE MEASURING CD BOARD

UBC717AE101
HIEE300927R0101
CIRCUIT BOARD
OVERVOLTAGE MEASURING CD BOARD

MLink Control Unit

Model: M-Link (Motor Link)
Series: ABB MNS iS Intelligent MCC System
Processor:ARM Cortex-A9 @ 800 MHz
Memory:512 MB RAM, 4 GB Flash
MCC Bus Interface:MNS Connect
Operating Voltage: 110-240V AC (50/60 Hz)
Power Consumption:≤ 15 W

Drive Control Board

Control Methods:DTC
Communication:Embedded
Operating Voltage:24 V DC (±10%)
Power Consumption:30 W (typical)
Memory:512 MB DDR3 RAM, 4 GB Flash

UNITROL 1010 Voltage Regulator

Generator Voltage:100–690V AC (50/60 Hz),
Field Voltage (Output):10–250V DC
Regulation Accuracy:±0.5%
Response Time:<30 ms
Auxiliary Supply:24/48/110/250V
Power Consumption:≤25 W (standby)

Handheld communicator

Mobility MFC Hand Held Configuration Device
Display:4.3" TFT LCD
Touchscreen:Capacitive (glove-friendly)
Processor:ARM Cortex-A8 @ 800 MHz
Memory:512 MB RAM, 4 GB Flash
Charging:AC adapter (100–240V)
Operating System:Linux-based RTOS

Power Voting Unit

Input Channels:24V DC signals
Response Time:<10 ms
Operating Voltage:24V DC
Power Consumption:≤ 5 W
Isolation:1.5 kV AC

POWER SUPPLY BOARD

Acs880/580 Series Inverter
Input Voltage: 1-phase/3-phase input
AC Input: 200–500 VAC
DC Input: 500–700 VDC
Frequency: 50/60 Hz
Output Power: ≤ 100 W
Output Voltage: Supplies +24 VDC
Load Capacity: 5 A @ 24 VDC

MC INTERFACE BOARD

Input Voltage: Typically 24V DC
Output Signals: Digital and analog signals for
motor control and feedback.
Current Consumption:100-500mA
Communication Voltage Levels: 3.3V or
5V logic levels for digital communication.

Touch screen

Screen Size: 7 inches (diagonal).
Resolution: 800 x 480 pixels.
Display Type: TFT LCD with vibrant colors and excellent contrast.
Touch Screen Type: Resistive touch for accurate and reliable input.
Brightness: 400 cd/m².
Colors: 65,536 colors for sharp and detailed visualization.
Viewing Angle: ±70° )

Main Control Board

DCS880
SDCS-CON-H01
Main Control Board
Operating Voltage:24 V DC (±10%)
Current Consumption:≤1.5 A
Digital I/O Channels:32 optoisolated DC I/O points
Analog I/O:±10 V DC / 4–20 mA

ACS880 AC Drive- 500V, 3PH, wall mount, regenerative

LV AC industrial wall-mounted regenerative single drive
Input Supply:3-phase 380–480V AC (±10%), 50/60 Hz
Output Power:5.5 kW (7.5 HP) @ 400V AC
Output Current:21 A continuous (40°C ambient)
Overload Capacity:110% for 60s, 150% for 2s
Output Frequency:0–500 Hz (motor-dependent)
Efficiency:>98% (at full load)
Power Factor:0.98 (min)

Terminal base

Terminal base
For AC500 V3. 1 slot for communication module.
2 Ethernet interfaces
1 serial interface
1 CAN interface (TB5610-2ETH)

Prog.Log.Control

Memory Size:142 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Analog Inputs:2
Analog Outputs:1
Number of Digital Inputs:8
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):230 V AC
Supply Voltage:100 … 240 V AC
