ABB

Digital Output Module

Power Supply:24V DC ±10%
Power Consumption:4W (typical)
Isolation:500V AC (channel-to-channel)
Backplane Current:100mA (max)
Output Voltage:24V DC
Output Current:0.5A per channel
Switching Frequency:Up to 100Hz

Digital Output Module

Power Supply:24V DC ±10%
Power Consumption:5W (max)
Isolation:500V AC
Backplane Current:120mA (max)
Output Type:Solid-state
Output Voltage:24V DC
Output Current:0.5A per channel
Switching Frequency:Up to 100Hz
Leakage Current:<1mA

Binary Input Module

Power Supply:24V DC ±10%
Power Consumption:3W (typical)
Backplane Current:80mA (max)
Update Rate:10ms
Input Type:Sink/Source (configurable)
Input Voltage:12-60V DC
Threshold Voltage:8V DC (ON), 5V DC (OFF)
Input Current :3mA @ 24V DC
Response Time:<1ms
Isolation :1500V AC

Station bus coupling module

Power Supply:24V DC ±20%
Power Consumption:15W (typical)
Isolation:1500V AC
Data Rates:10/100 Mbps
Latency: <100μs
I/O Capacity:Up to 1024 signals

Universal Control Module

Memory:128MB Flash
Control Loops:Up to 64 PID loops
Scan Time:<1ms
Analog Input:4-20mA/0-10V
Digital Input:24V DC, 3mA

Analog Input Module

Power Supply:24V DC ±10%
Power Consumption:8W (max)
Sampling Rate:50Hz/channel
CMRR:>120dB @ 50/60Hz
NMRR:>60dB
Input Impedance:250Ω

Industrial Control Panel

Input Voltage:400-480V AC 3-phase (50/60Hz)
Control Voltage:24V DC ±10%
Main Circuit Breaker:80A (adjustable)
Short Circuit Rating:65kA @ 480V AC
Power Consumption:≤500W

Analog Input Unit

Power Supply:24V DC ±10%
Power Consumption:5W (typical)
Current:4-20mA/0-20mA
Voltage:0-10V/±10V
RTD :Pt100
Sampling Rate:10ms/channel
Common Mode Rejection:>100dB @ 50Hz
Input Impedance:250Ω

Bus Coupling Module

Power Supply:24V DC ±10%
Power Consumption:5W (typical)
Isolation :1500V AC
Protocol :PROFIBUS DP
Data Rates:9.6kbps to 12Mbps

Transducer Board

Power Supply:24V DC ±10%
Power Consumption:5VA (max)
Isolation:2kV AC (input-to-output)
Voltage Input:0-690V AC
Current Input:0-5A AC (via CTs)
Frequency Range:45-65Hz
Input Impedance:>1MΩ (voltage)
Analog Outputs:2x 4-20mA
Accuracy:±0.5% of span
Load Capacity:≤500Ω

IGBT Module

Voltage Ratings:1700 V
Current Ratings;450 A
Power Dissipation:2-3 kW
Switching Frequency Range: Up to 5-10 kHz
Isolation Voltage:2500-4000 V

GATE POWER UNIT

Model: KUC755 AE106
Order/Part Number: 3BHB005243R0106
Description: Gate Power Unit
Input Voltage: Typically 24V DC
Output Gate Drive Voltage: ±15V to ±20V
Output Current: Up to 5A peak
Isolation Voltage: ≥2500V AC

Converter Display Board

Supply Voltage: 24V DC
Power Consumption: <5W
Part Number: 3BHB006943R0002
Supported Languages: Multiple
Alternative Designation: UNS0885A-Z, V2
Description: Display and control interface board

Power Supply

Input Voltage Range:85–264V AC
Frequency Range: 47–63Hz
Inrush Current: ≤20A
Efficiency: ≥90%
Output Voltage: 24V DC
Output Current: 5A
Power Rating: 120W
Overload Protection: 105–150% of rated current

Ethernet POWERLINK adapter module

Supply Voltage: 24V DC
Power Consumption: ≤5W
Isolation: 1500V AC
Cycle times :≤200 µs
Protocol: Ethernet POWERLINK

Electro-Pneumatic Positioner

Low operating cost
Compact design
For SIL2 safety loops
Mechanical position indicator
Well-proven technology and intelligence
Robust and environmentally ruggedized
ATEX, FM, CSA, GOST and IECEx approvals
Wide operating temperature range -40 ... 85 °C

MLink Control Unit

Baslc-Modbus TPC+serial/RS 485
Communication Gateway
Product Main Type:MLink
Hardware Version 2
Internal: Modbus TCP
Fieldbus: Profibus, Modbus RTU/TCP, PROFINET IO

Memory Card

Order Number: 3BHE017400R0101
Memory Type: Flash memory
Capacity: 1GB
Write Cycles: 100,000 minimum
Interface: CompactFlash (CF)
Supply Voltage: 3.3V ±5%
Data Transfer Rate: Up to 16MB/s

Processor board

Power Supply: 24V DC ±10%
Power Consumption: 15W typical
Isolation: 1500V AC
RAM: 512MB
Flash Memory: 128MB
Memory Card Slot: Supports PPD104 CF card
Ethernet Ports: 2x 10/100/1000 Mbps
Serial Port: 1x RS-232/485

Power Supply Board

3-phase: 380-500V AC
1-phase: 200-240V AC
Frequency Range: 47-63Hz
DC Bus Voltage: 510-620V DC
Rated Power: 11kW
Overload Capacity: 150% for 60 seconds
Inrush Current Protection: <25A for 10ms
Efficiency: >95%
Undervoltage Lockout: <300V DC input

INTERFACE BOARD

Channels: 16
Voltage: 24V DC
Isolation: 1500V AC
Type: 4-20mA/0-10V
Resolution: 16-bit
Field-to-system: 2500V AC
Channel-to-channel: 500V AC

POWER SUPPLY BOARD

Input Voltage Range:380-500V AC
Optional: 200-240V AC
Frequency Range: 47–63Hz
Inrush Current Protection: <30A
Output Voltage: 24V DC
Rated Current: 10A
Power Rating: 240W
Ripple Noise: <100mV peak-to-peak
Overload Capacity: 150% for 5 seconds

Six-axis motor

Rated Power: 7 kW
Rated Speed: 3000 RPM (Variable Speed)
Rated Voltage: 400 V (3-phase AC)
Rated Current: 14 A
Rated Frequency: 50 Hz
Torque Constant: 20 Nm/A
Service Factor: 1.5

Motor Control Card

Supply Voltage: 24V DC ±10%
Power Consumption: 15W typical
Isolation: 2.5kV input-to-output
PWM Frequency: 2-16kHz
Analog Inputs:4 channels
Digital Inputs:8 channels
Power Range: 0.5-800kW
Max Motor Speed: 6000 rpm

Battery pack

LITHIUM 34X102X63
Nominal Voltage: 24V DC
Capacity: 7Ah
Operating Voltage Range: 21.6V - 26.4V DC
Max Discharge Current: 10A
Charging Voltage: 27.6V ±0.2V
Charging Current: 2.1A
