ABB

Trigger Pulse Amplifier

Voltage: 5-15V DC
Frequency: Up to 10kHz
Pulse Voltage: 24V DC
Peak Current: 2A
Pulse Width: 60-120μs
Input-to-output: 4kV AC
Channel-to-channel: 2kV AC
Operating Voltage: 220V AC ±15%
Power Consumption: 15W max
Backup Power: Optional 24V DC input

IGBT Kit

Module Type:High-capacity IGBT Kit
Configuration: Dual-switch structure
Voltage Rating: 3300V/4500V
Current Rating: 1600A-3000A
Switching Speed:<150ns turn-off time
Power Class: ≥5MW

CONTROL BOARD

CONTROL BOARD
230-500V
(64379143)
CPU: 32-bit RISC processor
Flash Memory: 32MB
Digital Inputs: 16 channels
Analog Inputs: 8 channels
Pulse Inputs: 2 channels
Power Supply: 24V DC ±10%
Power Consumption: 12W typical

Power supply

Series: CP-C
Model: 24/20.0
Type: Industrial switching power supply
Power Rating: 480W
Output Voltage: 24V DC ±1%
Input Voltage Range:100-240V AC (47-63Hz)
Inrush Current: <20A
Power Factor: >0.95 at full load
Efficiency: Up to 93%

Processor Board

Type: Dedicated 32-bit
Clock Speed: 80 MHz
Non-volatile Memory (Flash): 16 MB
RAM: 64 MB
Serial/Fieldbus Ports: CAN

MB300E Communication Processor

Voltage: 24 V DC
Power Consumption: ≤ 5 W
Serial Ports: RS-232/RS-485
Ethernet Port: 10/100 Mbp
Fieldbus Support: Profibus DP
Processor: 32-bit RISC-based
Flash Memory: 16 MB
Data Throughput: Up to 10,000 signals

Extension Mounting Panel

Operating Voltage: 24V DC
Current Rating: ~1-5A
Layers: Likely 2-4 layer PCB
Possible RJ45/RS-485

Power Supply Board

AC Input: 85-264V AC
DC Input: 120-370V DC
Frequency: 47-63Hz
Inrush Current: ≤20A
Output Current: 5A
Ripple & Noise: <150mV peak-to-peak
Efficiency: ≥88%

Drive Control Board

Input Voltage: 24V DC (±10%)
Power Consumption: 15W typical
Analog Inputs:0-10V/4-20mA
Digital Inputs:24V DC
Processor: 32-bit DSP
Memory: 16MB Flash

Transformer Module

Voltage Input: 100-120V
Current: 0.1A
Voltage: 57.7V
Frequency: 50/60Hz (±5%)
Accuracy Class: 0.5%
Part Number: 1MRK002247-AHR05

Communication Card

Ethernet: 10/100 Mbps
Input: 24-48V DC
Consumption: 3.5W typical
Isolation: 2.5kV AC
Processor: 32-bit ARM
Memory:64MB Flash
Digital Inputs:24V DC

Communication Card

Ethernet: 10/100 Mbps
Serial (RS485): 300–115,200 bps
Input Voltage: 24V DC
Power Consumption: 4W
Isolation: 2.5 kV AC
Processor: 32-bit ARM
Digital Inputs: 24V DC

CONTROL BOARD

Operating Voltage: 24V DC (±10%)
Power Consumption: ≤10W
Isolation: 1500V AC
Processor: 32-bit DSP
PWM Frequency: 2–16 kHz

CODIRECTIONAL MODULE

Binary Outputs:250V AC
Operating Voltage: 24-48V DC
Voltage polarization:57-120V AC
Current inputs :1A/5A AC
Sensitivity: ≤0.5° phase error

Control Module

Supply Voltage: 24V DC (±10%)
Power Consumption: ≤8W
Isolation: 1500V AC
Digital Inputs:24V DC
Analog Inputs:0–10V or 4–20mA
Relay Outputs: 5A, 250V AC
Processor: 32-bit DSP
PWM Frequency: 2–16 kHz

Processor Unit Relay Card

Operating Voltage: 24V DC
Power Consumption: ≤5W
Isolation: 2.5kV AC
Processor: 32-bit DSP
Memory:64MB Flash

Processor Unit Relay Card

Operating Voltage: 24V DC
Power Consumption: ≤5W
Isolation: 2.5kV AC
Processor: 32-bit DSP
Memory:64MB Flash

Drive Power Supply Board

3-phase: 380-480V AC
Frequency: 47-63Hz
Continuous: 150W
Isolation Voltage: 2500V AC
Vibration Resistance: 5-200Hz

Control Circuit Board

Input Voltage Range:90VAC to 264VAC
Output Voltage:DC 24V
Power Consumption:≤ 15W
Communication Interface:RS-232, RS-485
Relay Output:4 channels

Servo Controller UNIT

Voltage: 3-phase 200-480V AC
Frequency: 50/60Hz (±5%)
Power Range: 0.5-5kW
Continuous Current: 5A RMS
Peak Current: 15A
Analog Input: ±10V
Encoder Interface: 1MHz differential
Control Bandwidth: 1.2kHz velocity loop
Positioning Accuracy: ±1 encoder count

Auxiliary DC Power Supply Unit

Input Voltage:110/125/250V DC
Range: 88–300V DC
Inrush Current: ≤20A
Output Voltage: 24V DC
Output Current: 5A continuous
Ripple Noise: <100mV peak-to-peak
Isolation: 3kV AC
Overvoltage: Clamping at 28V DC

Transformer Module

Current Input: 1A or 5A AC
Voltage Input: 100-120V
Frequency: 50/60Hz (±5%)
Accuracy Class: 0.5%
Burden: <0.2VA (current)

Drive Board

Processor: 32-bit DSP
PWM Frequency: 2–16 kHz
Operating Voltage: 24V DC (±10%)
Power Consumption: ≤6W
Isolation: 1500V AC
Digital Inputs:24V DC
Analog Inputs:0–10V or 4–20mA
Relay Outputs:5A, 250V AC / 30V DC
