ABB

Procontrol System Coupling Module

Voltage: 24 VDC (±15%) or 110–240 VAC
Power Consumption: 5–10 W
Operating Temperature: -20°C to +60°C.
Humidity: 5–95% non-condensing.

Control Board

Analog I/O update rate: 1 kHz
Digital I/O update rate: 10 ms
Standard range: -20°C to +60°C
Extended range: -40°C to +70°C
Power consumption: Max. 10W
Humidity: 5% to 95% RH
16-bit resolution for analog inputs/outputs

CONVERTER PULSE BOARD

Input Voltage Range:5-30V DC (HTL)
Input Frequency:0-500kHz
Output Signal:Differential (RS422) or single-ended
Output Current:20mA max
Power Supply:24V DC ±10%
Power Consumption:5W typical
Resolution: Up to 4096 pulses/revolution
Signal Delay: <100ns

FIELD PROTECTION UNIT

Operating Time:<8ms for critical faults
Measurement Accuracy:±0.5% of reading
Sampling Rate:64 samples/cycle
Time Sync Accuracy:±1μs
Power Supply:48-125V DC or 90-264V AC
Power Consumption:15W typical
Isolation Voltage:2.5kV AC

LCDC Module

Supply Voltage: 24 VDC (±10%)
RS-232/RS-485 serial interface
Relay Outputs:0-24 VDC
Operating Temperature: 0°C to 55°C
Humidity: ≤95% non-condensing

I/O module

16 digital inputs (24V DC)
Configurable as sinking/sourcing
3ms debounce filtering
Channel-by-channel LED status
Voltage Range:5-30V DC
Current:3mA typical
Isolation:1500V AC

I/O Module

Analog Input :4-20mA/0-10V
Analog Output:4-20mA/0-10V
Digital Input:24V DC
Digital Output:24V DC, 0.5A
Resolution:16-bit
Accuracy:±0.1% of span
Input Impedance:250Ω
Input Voltage:24V DC (15-30V range)
Output Current:0.5A max per channel
Response Time:<1ms
Backplane Interface: Redundant S800 I/O bus
Update Rate: 10ms (all channels)

Mini Contactor Relay

Rated Current (Ie):6A (AC-1)
Rated Voltage (Ue):230V AC / 24V DC
Breaking Capacity:3A @ 400V AC (AC-3)
Contact Material:Silver alloy (AgSnO₂)
Coil Voltage:24V DC / 48V DC / 110V AC / 230V AC (selectable)
Power Consumption:2.2W (DC) / 3.5VA (AC)
Operate Time:≤15ms (DC), ≤20ms (AC)
Release Time:≤10ms (DC), ≤15ms (AC)

83SR06E Binary and Analog Control Module

Overload (49):20-100% of In
Short Circuit (50):2-15×In
Phase Loss (46):Fixed/Adjustable
Ground Fault (51G):20-40% of In
Rated Current (In):6A (CT 5-100A)
Control Voltage:24-240V AC/DC
Contact Rating:5A @ 250V AC (resistive)
Communication:RS-485

Analog Output Module

Accuracy:±0.1% of span
Galvanic isolation:1500V AC channel
Range:4-20mA / 0-20mA
Resolution:16-bit
Load Capacity:≤750Ω
Update Rate:10ms per channel
Power Supply:24V DC ±10%
Power Consumption:5W (max)
Isolation Voltage:1500V AC

81EU01 Universal Input Module

81EU01 Input Module universal
16 fold for Binary and Analog Transmitters
ValueUnavailable
16 Channels

Analog Output Module

Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Load Capacity:≤750Ω
Update Rate:5ms per channel
Power Supply:24V DC ±10%
Isolation:1500V AC

Control Module

Channels:16
Voltage/Current:24V DC, 0.5A
Isolation:1500V AC
Response Time:<1ms
Power Supply:24V DC ±10%
Power Consumption:8W (typical)

83SR11E Module

Power Supply:24V DC ±10%
Power Consumption:6W (typical)
Isolation:1500V AC
Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Load Capacity:≤750Ω
Update Rate:5ms per channel

Analog Output Module

Power Supply:24V DC ±10%
Power Consumption:4W (typical)
Isolation:1500V AC
Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.1% of span
Load Capacity:≤750Ω
Update Rate:10ms per channel

Control Board

Power Supply:24V DC ±10%
Analog Input:4-20mA / 0-10V
Digital Output:Relay, 5A @ 250V AC
Overcurrent:5-100A
Ground Fault;1-10A
Protocol: Modbus RTU (RS-485)
Baud Rate: 1200-19200 bps

Coupler Module

Application:Interfacing a computer
Transmission:Serial acc. to RS 232c
Transmission rate:300 - 19200 baud
Transmission distance, max.:20 m

Industrial Control Board

Processor:Dual-core PowerPC @ 800MHz
Memory:64MB Flash, 32MB RAM
Control Loops:Up to 128 PID loops
Ethernet: 2x 10/100BASE-T
Serial: 1x RS-485
Fieldbus: PROFIBUS DP
Digital Input:24V DC
Digital Output:Relay, 2A @ 30V DC
Analog Input:4-20mA/0-10V

Coupling Module

Power Supply:24V DC ±10%
Power Consumption:5W
Isolation:1500V AC
PROFIBUS Connector:9-pin D-sub
Protocol:PROFIBUS DP
Address Range:0-125
I/O Capacity:244 bytes input
Response Time:<1ms

Control I/O Module

Analog Input:4-20mA
Digital Input:24V DC, 3mA
Analog Accuracy:±0.1% of span
Digital Isolation:1500V AC
Update Rate:10ms (all channels)
Power Supply:24V DC ±10%
Power Consumption:8W (max)
Backplane Interface: S800 I/O bus

Analog Input Module

Power Supply:24V DC ±10%
Power Consumption:6W (max)
Isolation:1000V AC
Range:4-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Input Impedance:250Ω
Update Rate:10ms/channel

Analog Input Module

Power Supply:24V DC ±10%
Power Consumption:8W (max)
Current:0-20mA/4-20mA
Voltage:0-10V/±10V
RTD:Pt100/Pt1000
Sampling Rate:50Hz/channel
Common Mode Rejection:>120dB @ 50/60Hz
Normal Mode Rejection:>60dB
Input Impedance:250Ω (current)

Joystick assy

Operating Voltage:Typically 24V DC
Analog:0-10V
Digital :CANbus/DeviceNet
Current Consumption:<100mA
Degrees of Freedom:2 or 3 axes
Handle Material:Industrial-grade plastic/metal
Mechanical Life:>1 million cycles
Operating Force:3-10N

Coupling Module

Power Supply:24V DC ±10%
Power Consumption:5W (typical)
Isolation:1500V AC
Protocol:PROFIBUS DP
Data Rates:9.6kbps - 12Mbps
Address Range:0-125
Response Time:<1ms

Digital Output Module

Power Supply:24V DC ±10%
Power Consumption:4W (typical)
Isolation:500V AC (channel-to-channel)
Backplane Current:100mA (max)
Output Voltage:24V DC
Output Current:0.5A per channel
Switching Frequency:Up to 100Hz
