ABB

UNITROL 1010 Voltage Regulator

Generator Voltage:100–690V AC (50/60 Hz),
Field Voltage (Output):10–250V DC
Regulation Accuracy:±0.5%
Response Time:<30 ms
Auxiliary Supply:24/48/110/250V
Power Consumption:≤25 W (standby)

Handheld communicator

Mobility MFC Hand Held Configuration Device
Display:4.3" TFT LCD
Touchscreen:Capacitive (glove-friendly)
Processor:ARM Cortex-A8 @ 800 MHz
Memory:512 MB RAM, 4 GB Flash
Charging:AC adapter (100–240V)
Operating System:Linux-based RTOS

Power Voting Unit

Input Channels:24V DC signals
Response Time:<10 ms
Operating Voltage:24V DC
Power Consumption:≤ 5 W
Isolation:1.5 kV AC

POWER SUPPLY BOARD

Acs880/580 Series Inverter
Input Voltage: 1-phase/3-phase input
AC Input: 200–500 VAC
DC Input: 500–700 VDC
Frequency: 50/60 Hz
Output Power: ≤ 100 W
Output Voltage: Supplies +24 VDC
Load Capacity: 5 A @ 24 VDC

MC INTERFACE BOARD

Input Voltage: Typically 24V DC
Output Signals: Digital and analog signals for
motor control and feedback.
Current Consumption:100-500mA
Communication Voltage Levels: 3.3V or
5V logic levels for digital communication.

Touch screen

Screen Size: 7 inches (diagonal).
Resolution: 800 x 480 pixels.
Display Type: TFT LCD with vibrant colors and excellent contrast.
Touch Screen Type: Resistive touch for accurate and reliable input.
Brightness: 400 cd/m².
Colors: 65,536 colors for sharp and detailed visualization.
Viewing Angle: ±70° )

Main Control Board

DCS880
SDCS-CON-H01
Main Control Board
Operating Voltage:24 V DC (±10%)
Current Consumption:≤1.5 A
Digital I/O Channels:32 optoisolated DC I/O points
Analog I/O:±10 V DC / 4–20 mA

ACS880 AC Drive- 500V, 3PH, wall mount, regenerative

LV AC industrial wall-mounted regenerative single drive
Input Supply:3-phase 380–480V AC (±10%), 50/60 Hz
Output Power:5.5 kW (7.5 HP) @ 400V AC
Output Current:21 A continuous (40°C ambient)
Overload Capacity:110% for 60s, 150% for 2s
Output Frequency:0–500 Hz (motor-dependent)
Efficiency:>98% (at full load)
Power Factor:0.98 (min)

Terminal base

Terminal base
For AC500 V3. 1 slot for communication module.
2 Ethernet interfaces
1 serial interface
1 CAN interface (TB5610-2ETH)

Prog.Log.Control

Memory Size:142 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Analog Inputs:2
Analog Outputs:1
Number of Digital Inputs:8
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):230 V AC
Supply Voltage:100 … 240 V AC

Processor module

Processor module
Memory 80MB
Interfaces: 2 Ethernet
RS232/485, CAN.
Display (PM5650-2ETH)
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC
Memory Size: 369256 kB
Memory Type User Data:RAM

Harmony Electronic Module

Harmony Block I/O
Series: ABB Harmony HX
Function: 16-Channel Universal Input Module
Resolution:16-bit
Accuracy:±0.2% of full scale (25°C)
Sampling Rate:100 ms per channel
Input Impedance:>1 MΩ (voltage), 250 Ω (current)
Isolation Channel-to-channel: 300V AC
Power Supply:24V AC/DC (±15%), 5W max

Bay Control Display

Relion 670 series
Display:5.7" TFT LCD (320 × 240 pixels)
Input Method:6x tactile keys + navigation wheel
Operating Voltage:48–250V DC or 110–240V A
Power Consumption:≤ 15 W
Operating Temperature:-25°C to +70°C

PSR CONTROLLER

Rated Power: 22 kW (30 HP)
Supply Voltage:3-phase 208–690V AC (50/60 Hz)
Motor Voltage:220–690V AC
Rated Current:42
Starting Current:Adjustable: 1.5–5× FLC
Control Voltage:24V DC/110–240V AC
Max. Starts/Hour:10

Main Control Board

Processor:PowerPC 750GL @ 400 MHz
Memory:128 MB SDRAM
Control Capacity:Up to 60,000 function blocks
Operating Voltage:5V DC
MTBF:>500,000 hours
Mounting:AC 800M controller baseplate

Operating Panel

Display:2-line LCD with backlight
Control Keys:Navigation keys + Start/Stop/Jog buttons
Operating Voltage:24V DC
Power Consumption:≤ 5 W

Binary Input Module

Input Channels:16x
Input Voltage:24/48/110/125V DC
Input Threshold (ON);>60% of rated voltage
Input Current :3–8 mA
Response Time:<5 ms
Isolation:2.5 kV AC
Power Consumption:≤ 4 W

Relay Control module

Number of Channels: 8 independent channels
Number: 6 dedicated
Contact Rating: 24 V DC / 30 mA
Voltage: +24 V DC nominal
Power Consumption: < 5 W

GCOM Communication Interface

Power Consumption: 1.5 - 2.5 W
Isolation:500 V AC (ports to backplane)
ESD Protection:±15 kV (IEC 61000-4-2)

Industrial Control Module

Input Channels:16 (Grouped as 8+8)
Input Voltage:24 V DC (Nominal)
Voltage Range:19–30 V DC (Logic "1": ≥15 V)
Logic "0" Threshold:≤5 V DC
Input Current:6 mA per channel (typical)
Isolation:500 V AC (channel-to-channel)
Backplane Power :5 V DC (via P4 baseplate)

Transmitter Controller

Function:8-channel analog input (4-20mA)
Input Channels:8 (isolated)
Signal Range:4-20mA
Input Impedance:250 Ω
Accuracy:±0.1% FS (at 25°C)
HART Support:FSK modulation (1200/2200Hz) via same wires
Power Supply:24 V DC loop power
Isolation :500 V AC

Transmitter Controller

Functions:4x 4-20mA Input
Signal Range :4-20mA
Accuracy:±0.05% FS (23°C)
Loop Power:24 V DC
Isolation:500 V AC (channel-to-bus)
Max Devices:16 per segment
Power:9–32 V DC

Control Board

Hardware Generation:G4 (4th Gen)
Status:Discontinued (since ~2003)
Replacement:AC 800M Controller Series
Memory:4 MB DRAM + 2 MB Flash
Backup Battery:3.6 V Li (BR2325) for RAM retention
Cycle Time:≤100 ms
I/O Capacity:Up to 1024 I/O points
Supply Voltage:24 V DC ±10%
Power Consumption:15 W (max)

Control Board

Memory:2 MB SRAM
Profibus DP Ports:2x RS-485
Baud Rate:9.6 kbps – 12 Mbps
Max Devices:124 slaves per segment
Supply Voltage:5 V DC ±5% (via backplane)
Power Consumption:8 W max
Isolation:500 V AC (field-to-logic)

CIRCUIT BOARD

CIRCUIT BOARD
CONTACTOR CONTROL BOARD
3-PIN SCREW CLAMP TERMINAL
Application:Emax 2 Circuit Breakers
Supply Voltage:24–250 V AC/DC (self-powered via CTs)
Operating Current:0.05 A (standby)
Communication:Ports 1x RS-485 (Modbus RTU)
Protocol Support:Modbus RTU, IEC 60870-5-103
Measurement Accuracy:±1% (current), ±0.5% (voltage
